Page 1 Wireless Blood Pressure Monitor User Manual Rev 7 2015...
Page 2 All implied warranties are limited to 1 year from date of purchase. Batteries are excluded from the warranty. We will at our option, without charge repair or replace blip BP monitor or cuff covered by the warranty. This is the only remedy under the above warranty.
Page 3: Table Of Contents
Table OF CONTENTS Intended Use ................4 About Blood Pressure .............. 5 Button Layout and Display ............6 Setting Up ................. 7 How to Measure Your Blood Pressure ........12 Taking a Measurement ............15 Maintenance ................17 RF Statement ................. 22 Safety Statements ..............
Page 4: Intended Use
The blip BP is easy to set up, but before you connect to your home wireless network, take a minute to register your device. This gives you access to all of the features available through the web portal.
Page 5: About Blood Pressure
ABOUT BLOOD PRESSURE High Blood Pressure, or hypertension, is a medical condition in which the arterial JNC7 Classification Table blood pressure is elevated. High blood pressure can be classified as “primary”, Systolic Diastoli meaning that no medical cause can be found, or as “secondary”, meaning that it is ...
Page 6: Button Layout And Display
BUTTON L AYOUT A ND D ISPLAY Pressing U ser 1 o r U ser 2 Systolic pressure button o nce w ill S TART t o Diastolic inflate ...
Page 7: Setting Up
SETTING UP Before proceeding please read instructions for set up. A. Please register your blip Blood Pressure Monitor at http://www.blipcare.com using 555A12345678A your Device Serial Number located under the bar code at the bottom of your device.
Page 8 When batteries are installed in the search for available Wi-Fi networks that you to it. device (Refer to Page 36- " can connect to. Look for "blip Appendix A) it will enter AP mode Do NOT take readings in AP Mode. Home WiFi Internet access...
Page 9 Setting up contd. G. While you are still connected to "blip" and Blood Pressure Monitor is still in AP Mode, open any browser and go to http://192.168.101.1 This will take you to the Blip Configuration page where you will see a list of saved networks (if there are any).
Page 10 Setting up contd.: SCAN Clicking "Scan" will show you a list of active Wi-Fi networks that you can connect to. Look for your Wi-Fi network name. Enter your Wi-Fi network password into the “Credential” column and click “Connect”. If the Blood Pressure Monitor connects to the network a message will be displayed “Successfully Connected and Saved !”.
Page 11 Setting up contd.: If your router supports Wi-Fi Protected Setup (WPS) feature click "WPS-PushButton" on the blip configuration page then press the "WPS-PushButton" on your router to connect to your network. If the BP monitor connects to the network a message will be displayed indicating “Successfully Connected and Saved!”...
Page 12: How To Measure Your Blood Pressure
HOW TO MEASURE YOUR BLOOD PRESSURE Before taking a reading, you should sit quietly for around 10 minutes, and there should be an interval of at least 5 minutes between readings. While taking a measurement, you should stay calm and relaxed, and try not to talk. This will improve the accuracy of the readings.
Page 13 PUTTING ON THE ARM CUFF Rest your left arm on a table and relax your arm. Correct cuff placement Wrap the arm cuff snugly. You should be able to fit one finger between the cuff and your arm. Correct level Make sure the cuff is at heart level.
Page 14 PROPER POSTURE contd. Turn your left palm upward and place the edge of the arm cuff at approximately 1 inch above your elbow. The cuff should be tight enough on the arm to allow the insertion of one finger between the cuff and arm.
Page 15: Taking A Measurement
TAKING A MEASUREMENT 1. Push either the USER 1 or USER 2 button once to START the measurement. 2.”00” will blink on the LCD. 3. About 2-3 seconds later, the pressure will be reset. Then the cuff will begin to inflate and the pressure will be displayed. 4.
Page 16 TAKING A MEASUREMENT contd. After finishing a measurement, values for systolic pressure, diastolic pressure, and pulse rate will be displayed on the LCD as shown in the diagram. The blood pressure monitor will automatically transfer your measurement to the web portal via Wi-Fi wireless network. While transmitting a reading, the data transmission symbol will blink on and off.
Page 17: Maintenance
MAINTENANCE 1. Do not use an alcohol-based solvent or cleaning agent to clean the device. 2. Clean the device with a soft, dry cloth. 3. Do not immerse the device or cuff in water. 4. Do not bend the cuff or sleeve, and do not wrap the sleeve inside-out. 5.
Page 18: Reference To Standards
REFERENCE TO STANDARDS * COUNCIL DIRECTIVE 93/42/EEC of 14 June 1993 concerning medical devices as amended by Directive 2007/47/EC * IEC60601-1: 2005 + CORR. 1 (2006) + CORR. 2 (2007); EN 60601-1:2006+AC2010 Medical electrical equipment - Part 1:General requirements for basic safety and essential performance * EN1060-3:1997+A1:2005+A2:2009:Non-invasive sphygmomanometers, Part 3: Supplementary requirements for electromechanical blood pressure measuring systems * EN55022: 2006 + A2: 2010, Class B: Information technology equipment-Radio disturbance characteristics -Limits and...
Page 19 Reference to standards contd * EN ISO14971:2012: Medical devices - Application of risk management to medical devices (ISO 14971:2007, Corrected version 2007-10-01) * EN ISO 10993-1:2009 Biological evaluation of medical devices-Part 1: Evaluation and testing within a risk management process (ISO 10993-1:2009) * ANSI/AAMI SP10: 2002/A1 2003(R) 2008: Manual, electronic or automated sphygmomanometers * ANSI/AAMI/ISO 81060-‐2:2009 Non-‐invasive sphygmomanometers –...
Page 20 General Communications Commission (FCC) Statement 15.21 This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
Page 21 General Communications Commission (FCC) Statement 15.21 contd. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: this device may not cause harmful interference and this device must accept any interference received, including interference that may cause undesired operation of the device.
Page 22: Rf Statement
-The use of accessories and cables other than those specified may result in increased emissions or decreased immunity. -BP-700WF uses RF energy only for its internal function. Therefore, its RF emissions are very low and are not likely to cause any interference in nearby electronic equipment.
Page 23 EMC performance. -BP-700WF should not be used adjacent to or stacked with other equipment and that if adjacent or stacked use is necessary, which should be observed to verify normal operation in the configuration in which it will be used.
Page 24 RF STATEMENT contd Recommended separation distances between Medical Electrical Equipment needs Portable and mobile RF communications equipment and the ME equipment special precautions regarding EMC The Wireless Blood Pressure Monitor is intended for use in an electromagnetic environment in which radiated RF disturbances are and needs to be installed and put controlled.
Page 25 RF Statement contd. Declaration – e lectromagnetic e missions a nd i mmunity f or E QUIPMENT a nd S YSTEMS t hat a re n ot L IFE-‐SUPPORTING a nd a re s pecified f or u se o nly i n a s hielded l ocation ...
Page 26 transmitter. I nterference variations o n -‐70 % U T(30 % d ip mains i nterruptions, i t i s r ecommended t hat may ...
Page 27: Safety Statements
! SAFETY STATEMENTS Warning: No modification of this equipment is allowed 1. This unit will not serve as a cure for any symptoms of heart disease. The measuring data is only for reference. Always consult your physician for interpreting results. 2.
Page 28 BATTERY SAFETY Batteries may leak and damage the main unit. Please observe the following precautions: * Use only high quality alkaline AA batteries. * When you are not going to use the unit for a long period of time (approximately three months or more) take out the batteries.
Page 29 DISPOSAL Actuation of European directives 2002/95/EC, 2002/96/EC and 2003/108/EC, for reduction in use of dangerous substances in the electric and electronic device and for garbage disposal. The symbol applied on the device or its packaging means that at the end of its useful life the product must not be disposed of with domestic waste.
Page 30: Error Messages
ERROR M ESSAGES Error Cause Remedy Remove a nd r e-‐install n ew b atteries. I f t he p roblem p ersists, p lease c ontact t he Low ...
Page 31 1. A ir p ipe b locked. 2. I nflation c ontroller f ailure. Over s afety p ressure 3. P ressure s ensor f ault. R e-‐measure, c ontact m anufacturer i f t he p roblem p ersists. ...
Page 32: Troubleshooting
TROUBLESHOOTING Fault Remedy 1. C heck a nd c orrect t he b attery p olarities. Even t hough t he b atteries a re i nstalled, t here i s e ither n o 2. ...
Page 33 Remedy Fault 1. T he v ariation i s d ue t o t he d ifferent e nvironments. Under n ormal m easuring c ircumstances a r eading a t h ome 2. ...
Page 34: Symbols
SYMBOLS Symbol Meaning Systolic b lood p ressure, Diastolic b lood p ressure, SYS m mHg measured i n m illimeters o f DIA ...
Page 35: Specifications
SPECIFICATIONS Model BP-‐700WF B lood P ressure M onitor Electric p ower 4 t ype A A 1 .5 v olt a lkaline b atteries ...
Page 36: Appendix A-Installing And Replacing Batteries
07.060.001-UI01 Rev 7 © 2015 blipcare . All rights reserved. Appendix A: INSTALLING AND REPLACING BATTERIES 1. Press down and lift the battery cover in the direction of the arrows shown in the illustration to open the battery compartment. 2.
