Page 3: Welcome
Welcome Thank you for purchasing the world’s first fully integrated, 3D, see-through, smartglasses. This User Guide is available for download on the ODG Support website. Customer Support For questions, additional information not found within this guide, or to open a support ticket visit our Support site: support.osterhoutgroup.com... -
Page 4: Safety & Care
Safety & Care Your ODG R-7 device has been designed and manufactured to stringent quality and safety standards. You should, however, be aware of the following important precautions for the safe use of the smartglasses and accessories. Read and heed all of these instructions and warnings carefully. -
Page 5: Table Of Contents
Table of Contents Welcome ...........3 Safety & Care ........4 Table of Contents ......5 Included in the Kit ......6 Features Overview ......7 Main Controls ......... 8-9 Track Pad ........10 Input Modes ........10 System Menu ........11 Status Bar ........11 Launcher ........ -
Page 6: Included In The Kit
INCLUDED IN THE KIT R-7 Smartglasses Storage Case Magnetic USB Data & Power Cable Reticle Speed Mouse™ 2 Ear Buds (RSM) Head Strap Interchangeable Nose Bridges USB Power Adapter USB To Micro-USB Reticle Speed Mouse Charging Cable User Guide Lens Cleaning Cloth... -
Page 7: Features Overview
FEATURES OVERVIEW FRONT VIEW Flashlight Track Pad Camera Controls Magnetic Removable Earbud Port Shields TOP VIEW Track Pad Temples Magnetic USB Data Vibration Vibration & Power Port Feedback Feedback Removable Ear Horns... -
Page 8: Main Controls
MAIN CONTROLS POWER 12 sec 2 sec Power On Display Force (When device is off) Shutdown Shutdown Menu Displays On/Off (When device is on) VOLUME DOWN Hold Decrease Volume Continually One Step Decrease Volume VOLUME UP Hold Increase Volume Continually One Step Increase Volume LEFT TEMPLE... - Page 9 BOTTOM VIEW MULTI-FUNCTION You can program the multi-function button to perform various commands. To customize this button, go to Toggle Input Mode: Settings > Reticle > Temple Buttons Cursor/Selector (Default Setting) MENU Display System Menu BACK 3 sec Previous Go to Screen Launcher RIGHT TEMPLE...
-
Page 10: Track Pad
TRACK PAD The Track Pad is located on top of the right temple of the smartglasses, and there is another located on the Reticle Speed Mouse (See Diagram, Page 14). The Track Pad is an input device that allows the user to control the software interface by swiping with a fingertip. -
Page 11: System Menu
SYSTEM MENU Pressing the Menu button once will display the System Menu, providing access to frequently used features and settings. Icons at the top of the menu will launch the Calculator, Flashlight, Clock/Timer, or Camera apps. Notifications displays a list of any current system notifications. -
Page 12: Launcher
LAUNCHER The Launcher is the home screen of ReticleOS™ and will appear when the glasses power up. To return to the Launcher at any time either press the Back button repeatedly or press and hold the Back button for 3 seconds then release. -
Page 13: Launcher
LAUNCHER LAUNCHER MENU Selecting the Menu icon, located near far-right in the Launcher row, displays a menu of options. “Edit Row” allows the user to add or remove icons (see below), and “Edit Speed Buttons” or “System Settings” provide quick access to these related settings. -
Page 14: Reticle Speed Mouse
Page 11) then select Settings. Under the Bluetooth settings, select the RSM from the list of available devices (it will appear as “ODG Speed Mouse” in the list of devices). You can reset the RSM and make it forget any previous pairing by pressing and holding the Back and Menu buttons simultaneously for longer than 8 seconds. - Page 15 RETICLE SPEED MOUSE 2D Mode In 2D mode, you control the cursor by swiping your thumb on the Track Pad. 2D mode is ideal for situations requiring fine-grained control of the cursor, or in situations where you might be in motion, such as inside of a moving vehicle.
-
Page 16: Reticle Speed Mouse
RETICLE SPEED MOUSE Speed Buttons The four speed buttons at the top of the RSM provide one-button access to applications. Pressing a button launches the appropriate application that has been configured to that button. To configure the speed buttons, go to System Settings via the icon in the Launcher or by pressing and holding the Menu button. -
Page 17: Head Strap
HEAD STRAP The included Head Strap can be attached to secure the glasses to the wearer’s head. Follow instructions below to securely attach Head Straps. Head Strap Attachment To attach the strap, press the strap connectors into the oval hole in the Ear Horns. Then rotate the strap connectors 90°... -
Page 18: Removeable Ear Horns
REMOVABLE EAR HORNS The Ear Horns are removable. Please follow the below instructions to safely remove and re-attach the Ear Horns. The only tool you will need is a flat-head screwdriver. Fastener Removable Ear Horns Temples Circle indent, next to fastener, marks both the lock and unlock positions. - Page 19 REMOVABLE EAR HORNS Move fastener left and turn 180° to re-align with the circle indent and unlock Ear Horns. Gently pull Ear Horn out of socket to remove fully. Then replace the new Ear Horn into the socket. Move fastener right and re-align with the circle indent to lock Ear Horn in place.
-
Page 20: Earbuds
EARBUDS SIDE VIEW Magnetic Earbud Port Ear Bud x 2 To listen to audio, attach each of the supplied earbuds to the magnetic earbud ports located on the bottom of each temple. To adjust the volume, press the Volume Up or Volume Down buttons on the Reticle Speed Mouse or the bottom of the left temple on the glasses. -
Page 21: Charging
A charging status light located on the inside front of the glasses illuminates when the charging cable is plugged in. Note: Using supplied ODG power adapter ensures optimal charging efficieny. STATUS LIGHT COLORS CHARGING... -
Page 22: Interchangeable Nose Bridges
INTERCHANGEABLE NOSE BRIDGES There are three interchangeable nose bridges included in the kit. The nose bridges vary in sizes and attach magnetically. When removing the nose bridge place glasses down and pull the nose bridge up and away from the glasses. Do not move left and right as this can cause damage. -
Page 23: Technical Specifications
Framework Optimized for (2 x 650mAH) ODG Smartglasses 3 Replaceable Magnetic Nose Bridges Compatible with a Number of SDKs Removable Ear Horns (See ODG Website) Dual Haptic Feedback in Temples ReticleOS™ Developer Program OPTICS INCLUDED ACCESSORIES All accessories can be reordered Dual 720p Stereoscopic at shop.osterhoutgroup.com... -
Page 24: Important Notices
Important Notice Osterhout Design Group reserves all rights to the product and grants no other licenses, rights, or data of any kind. ODG prohibits the reverse engineering or deconstruction of the item for any purpose. Hereby, Osterhout Group, Inc. declares that the radio equipment type [designation of type of radio equipment] is in compliance with Directive 2014/53/EU. - Page 25 : (1) l’appareil ne doit pas produire de brouillage, et (2) satellites mobiles utilisant les l’utilisateur de l’appareil doit accepter tout brouillage mêmes canaux. radioélectrique subi, même si le brouillage est susceptible d’en compromettre le fonctionnement. R-7 GLASSES: FCC ID 2ADCMR7 RETICLE SPEED MOUSE: FCC ID 2ADCMRSM1...
- Page 26 Purposely Left Blank...
- Page 27 © Osterhout Group, Inc 2015-2017 Osterhout Group retains and reserves all rights. ODG Part #: 580-00032 | Rev 2.1.0 Aug 2017...
- Page 28 153 Townsend Street, Suite 570 San Francisco, CA 94107 (415)644-4000 osterhoutgroup.com SUPPORT: support.osterhoutgroup.com DEVELOPERS: developer.osterhoutgroup.com ODG Smartglasses are designed and engineered in California.
