CONTENTS
GENERAL FEATURES .................................................1
UNPACKING..................................................................2
OPTIONAL ACCESSORIES .........................................2
GETTING READY..........................................................2
DESCRIPTION...............................................................2
LCD PANEL ...................................................................4
OPERATION ..................................................................5
ADDITIONAL FUNCTION .............................................6
CHARGER AND BATTERY ..........................................7
SPECIFICATIONS .........................................................7
General Features
1.
Ultra compact design & size
(102 x 50 x 36mm, 310g with high capable battery)
2.
Heavy durable construction
3.
90 channels
4.
Alphanumeric LCD display up to 6 characters
5.
38 CTCSS/ 83 CDCSS
6.
PC Programmable, transferable by cloning
7.
Time-out timer (TOT)
8.
Busy channel lock-out (BCLO)
9.
Battery saving mode
10. Low battery alert
11. 2/5 tones programmable
12. 12.5KHz/25KHz channel spacing programmable
13. DTMF PTT-ID
14. Button lockable
15. Talking range to 5 miles
16. Transmit output power High/Low
17. DC7.5V Ni-MH battery
Advertisement
Table of Contents
Summary of Contents for Airtech Information & Communication Co., Ltd. AT-400 A/B
-
Page 1: Table Of Contents
CONTENTS General Features Ultra compact design & size (102 x 50 x 36mm, 310g with high capable battery) GENERAL FEATURES ..........1 Heavy durable construction UNPACKING..............2 90 channels OPTIONAL ACCESSORIES .........2 Alphanumeric LCD display up to 6 characters GETTING READY............2 38 CTCSS/ 83 CDCSS DESCRIPTION...............2 PC Programmable, transferable by cloning LCD PANEL ..............4... -
Page 2: Unpacking
Unpacking Getting Ready Unpack and check that all items have been enclosed. Installation, Removal Belt Clip Packing contents: radio antenna battery pack (1,350 Installation: align the belt clip with the plastic slots of the battery pack. mAH) belt clip hand strap charger user’s manual Slide the belt clip onto the battery... - Page 3 Select the desired channel with pressing Up and Down button, pressing and holding down more than 1 second makes the channel moving fast. And you can choose On or Off in function mode. PTT(Push To Talk) Button Hold down to transmit, release to receive. Function Button Refer to “OPERATION”...
-
Page 4: Lcd Panel
LCD Panel Abnormal Abnormal DISPLAY FUNCTION Sub-tone Program Scanning Transmitt output power Clone Beep sound Button lock Cloning finished Channel Cloning processing (moves rightward) PTT-ID... -
Page 5: Operation
Operation 3) mem 1ch > pri 1ch > pri 2ch > mem 2ch > ….. 1. Power Turn on / off and Volume Control The transceiver stops scanning after detecting a signal Rotate the Power on/off and Volume Control Switch and returns a receiving mode in the channel if the signal keeps for 2 seconds. -
Page 6: Additional Function
When you press Function Button once sign on LCD blinks. (in case of being selected button lock function on Additional Function blinks) Press Channel Select Button to select the beep 1. Time–Out Timer (TOT) sound on or off. Press PTT Button to finish selection. It limits the amount of time you can continuously transmit on 9. -
Page 7: Charger And Battery
Operating Voltage DC 7.5V Operating Temp. Charger and Battery -30 ~ 60 Battery Life (H/L) (based on 5% Tx: 5% Rx: 90% STBY) 1. Battery (Ni-MH) 720mAH Battery 6hrs/8hrs Voltage DC 7.5V 1,350mAH Battery 10hrs/15hrs Duty time HM-1350 Over 8 hrs Channels (5-5-90) HM-720... - Page 8 Land Mobile Radio (LMR) Model: AT-100 A/B AT-200 AT-400 A/B Airtech Information & Communication Co., Ltd. User’s Manual...
