Mazona Signet
Operation and Installation Manual
PLEASE ENSURE THIS MANUAL IS LEFT WITH THE HOME OWNER FOR FUTURE
REFERENCE
IMPORTANT
It is important that this manual is read by the installer in advance of installation. The
householder should familiarise themselves with the operation and maintenance sections of
the manual in advance of using the appliance. Incorrect installation of this stove can be
dangerous. The installation should be carried out by a trained competent person and in
accordance with local and national building regulations.
Imported and Distributed by Micon Distribution Ltd.
1a Hallstown Road, Ballinderry Upper, Lisburn BT28 2NE
Mazona Brand exclusively owned by Micon
1
Advertisement
Table of Contents
Summary of Contents for Mazona Signet
- Page 1 The installation should be carried out by a trained competent person and in accordance with local and national building regulations. Imported and Distributed by Micon Distribution Ltd. 1a Hallstown Road, Ballinderry Upper, Lisburn BT28 2NE Mazona Brand exclusively owned by Micon...
-
Page 2: Table Of Contents
CONTENTS INTRODUCTION MAINTENANCE De-ashing UNPACKING INSTRUCTIONS Baffle Plate Glass Cleaning Door BEFORE INSTALLATION Paintwork Summer Storage and Non Usage WARRANTY Flue / Chimney cleaning DIMENSIONS INSTALLATION TECHNICAL INFORMATION Ventilation Flue / Chimney Hearth Construction SPARE PARTS LIST 9/10 Safe Distance From Combustibles PREPARING THE STOVE FOR INSTALLATION Fitting Legs... -
Page 3: Introduction
Mazona Stoves will not be responsible for any consequential or incidental loss or injury however caused. -
Page 4: Installation
The hearth should be able to support the weight of the stove and its chimney if the chimney is not independently supported. SAFE DISTANCE FROM COMBUSTIBLES Distance from Side Distance from back Hearth Temperature Signet 100°C... -
Page 5: Preparing The Stove For Installation
PREPARING STOVE FOR INSTALLATION Fitting legs Rest the stove on its back and screw 2 bolts with washers into the base of the stove to secure each leg. Seek assistance lifting the stove up on to its feet. Flue collar and blanking plate setup Depending on the flue option selected, either top or rear, the flue collar blanking plate should be fitted for the desired option. -
Page 6: Fire Guard
Fire Guard A suitable fire guard should be used especially when the appliance is to be used were young children or the old or infirm may be present. Lighting the stove Open the door and ensure the air wash on the top of the door is opened fully. On first lighting we recommend using 2 -3 firelighters along with wood kindling built in a pyramid above the firelighters to obtain a good fire bed. -
Page 7: Controlling Stove
Controlling the stove When burning wood the stove should be controlled with the airwash control knob at the top of the stove. The primary air control knob should be set to closed (left) position as wood does not need air from below to burn effectively. -
Page 8: Paintwork
DIMENSIONS Height Width Depth Weight Flue Collar Centre of Centre of Maximum flue to floor flue to back log length Signet 250mm TECHNICAL INFORMATION Burning Beech wood Output Efficiency Emissions Flue gas kW (Nominal) CO at 13% temperature °C Signet 0.31... -
Page 9: Spare Parts List
SPARE PARTS LIST Description Image Bottom Grate Inner Bottom Grate Baffle Plate Side Brick (2) Back Brick Glass Door Handle Ashpit Handle... - Page 10 Air wash control knob Operator tool Ash pan Flue Collar Blanking Plate Should you require any further information, or wish to view our other products available please view at www.mazonastoves.com...
