Installation Instructions(C and Ku band Applicable)
1 The antenna property
1.1 Electric property
1.1.1 frequency：
1.1.2 Gain：
1.1.3.Beamwidth( 3dB)：Tansmission:1.89°
1.1.4．Sidelobe envelope: 29-25LOG(θ) dBi(1°≤θ≤20°)
1.1.5 Power capacity: 1000W
1.1.6 Interface:
1.1.7 Cross polarization isolation：≥35dB(Axial)
1.1.8 Voltage standing wave ratio：≤1.25：１(reception、transmission)
1.1.9 TX-RX isolation：＞85dB
1.2 Mechanical features
1.2.1
Antenna configuration form：azimuth—elevation configuration form
1.2.2
The coaxial duplexer：disassemble coaxial duplexer
1.2.3 The driving mode: manual
1.2.4
Azimuth range: ±90°
Elevation range：0°～90°
1.2.5
Operational Wind Speed： 20m/s
1.2.6
Anti-Seismic Capacity： Horizontal: 0.3G's
1.2.7
Temperature：-30 ～+55
1.2.9
Gross weight：80Kg
2 Antenna composition
SinoAero 1.8M Flyaway Antenna
Transmission: 5.925～6.425GHz
Reception: 3.7～4.2GHz
Transmission: 39.5 dBi
Reception:35.7 dBi
Reception:2.95°
Transmission: CPR-137G/F
Reception: CPR-229G/F
Vertical: 0.1G's
Advertisement
Summary of Contents for SinoAero 1.8m Flyaway
- Page 1 SinoAero 1.8M Flyaway Antenna Installation Instructions(C and Ku band Applicable) 1 The antenna property 1.1 Electric property 1.1.1 frequency： Transmission: 5.925～6.425GHz Reception: 3.7～4.2GHz 1.1.2 Gain： Transmission: 39.5 dBi Reception:35.7 dBi 1.1.3.Beamwidth( 3dB)：Tansmission:1.89° Reception:2.95° 1.1.4．Sidelobe envelope: 29-25LOG(θ) dBi(1°≤θ≤20°) 1.1.5 Power capacity: 1000W 1.1.6 Interface:...
- Page 2 1 The coaxial duplexer 2 The feed bracket 3 The panels (six) 4 The tripod Fig.1 1 The reflector bracket 2 The azimuth adjustment mechanism 3 The azimuth Turntable 4 The elevation adjustment mechanism 5 The foundation dish Fig. 2...
- Page 3 As shown in Figure1 and Figure 2(The configuration of the antenna), the antenna is composed of the feed system(the feed, the coaxial duplexer, the feed bracket),the reflector(the main reflector, the reflector bracket),the and the foundation(the elevation adjustment mechanism, the azimuth Turntable, the azimuth Turntable, the tripod, the foundation dish).
- Page 4 3.3.2 Installation Steps 1) First ,open the casing box ,then take the feed system, the reflector,the foundation dish ,the standard screw and the others out from the casing box. 2) The connection of the foundation：First, connect each end of the three main knightheads to the the main pole which is under the the azimuth Turntable,and the other end connect with the foundation dish.
- Page 5 first, connect longitudinal bracket to the the feed bracket by eight M10 bolt. and then connect the the landscape orientation bracket to the longitudinal bracket by four M10 bolt.then connect the abdomen board to the one side of the landscape orientation bracket by twelve bolt,the other side is same.
- Page 6 1 The reflector bracket 2 Semicircle Clasp 3 Transition Chassis 4 The feed 5 The feed bracket Fig.5 the configuration of the feed system 6) Antenna adjustment a. Adjustment of antenna elevation angle: According to calculated antenna elevation angle， preset antenna reflector to calculated position by rotating large knob of elevation lead screw (refer to elevation scale), then trim elevation lead screw through knob to align antenna toward satellite.
- Page 7 The step of the installation The installation of the foundation the installation of the oblique knighthead the installation of the the azimuth thread the installation of the bracket and the feed bracket...
- Page 8 the installation of the main reflector put the reflector on the bracket of the antenna the installation of the feed and the coaxial duplexer...
- Page 9 the overall figure of the antenna...
