Wireless LAN WL-850FJB 802.11g

User's Manual

Version 1.0

Table of Contents

Summary of Contents for ViewSonic WL-850FJB

Page 1 Wireless LAN WL-850FJB 802.11g User's Manual Version 1.0...
Page 2 Copyright statement No part of this publication may be reproduced, stored in a retrieval system, or transmitted in any form or by any means, whether electronic, mechanical, photocopying, recording, or otherwise without the prior writing of the publisher. April 2004 User’...
Page 3: Table Of Contents
Contents 1. Introduction ____________________________________________________ 3 2. Wireless LAN WL-850FJB Basics ___________________________________ 4 3. Installation for Windows platform ___________________________________ 5 3.1. Installation Overview____________________________________________ 6 3.2. Install Procedure for Windows XP __________________________________ 7 3.3. Install Procedure for Windows 98/ME/2000 ___________________________ 9 4. Configuration Utility ____________________________________________ 17 4.1 Link Information________________________________ 錯誤! 尚未定義書籤。...
Page 4: Introduction
The CD contains drivers and Configuration Utility program that is used for managing the Wireless LAN WL-850FJB Adapters and establishing the wireless connection with your Local Area Network. Note: This manual is valid for all Wireless LAN WL-850FJB 11g Series products, such as PC Card, USB, mini-USB, PCI adapter, mini-PCI… etc.
Page 5: Wireless Lan Wl-850Fjb Basics
This mobility supports productivity and service opportunities not possible with wired networks. • Installation Speed and Simplicity - Installing a wireless LAN WL-850FJB system can be fast and easy and can eliminate the need to pull cable through walls and ceilings.
Page 6: Installation For Windows Platform
The following section will assist you in installing wireless LAN WL-850FJB Adapter successfully. You will first install software (Utility) and then insert / attach the Wireless LAN WL-850FJB Adapter to your system, and finally set the network properties to accommodate resource sharing and select the type of wireless network that you wish to install.
Page 7: Installation Overview
Install the Access Point at first. AP is needed in case of Infrastructure network mode. l Install the software using the Install CD. l Install the Wireless LAN WL-850FJB Card (WIRELESS LAN WL-850FJB 802.11g Adapter). l Install the network protocol(s) required to communicate on your network. Most likely you will need the TCP/IP protocol.
Page 8: Install Procedure For Windows Xp
Windows XP has incorporated this by default. The rest of the OS must installed 3er party’ s client software such as Funk ODySSey. Note: Do not insert the WLAN WL-850FJB Adapter until you are asked to do so, failure of which may result in unsuccessful installation of your WLAN WL-850FJB device.
Page 9 Once your system detected the driver, Microsoft will show a warning message as below. Click “ Continue Anyway ” for next step. After copy the file to your system, then the setup is finish. User’ s Guide...
Page 10: Install Procedure For Windows 98/Me/2000
3.3. Install Procedure for Windows 98/ME/2000 Note: Do not insert the WLAN WL-850FJB Adapter until you are asked to do so, failure of which may result in unsuccessful installation of your WLAN WL-850FJB device. Please follow the following steps one by one in order to install the WLAN WL-850FJB Adapter successfully.
Page 11 4. Accept the license agreement. Accept the license agreement. Click Yes to accept. Click Yes to finish the setup. User’ s Guide...
Page 12 5. Insert / attach Wireless LAN WL-850FJB 802.11g Adapter to your system Windows will recognize the WLAN WL-850FJB adapter and auto detect the driver, if the system did not find the driver automatically, please install the driver manually. Click Yes to finish the installation.
Page 13 6. Click the right button of mouse on My Computer à Properties à HardwareàDevice Manager. Check whether it has WLAN WL-850FJB adapter in one of the sockets or not. If you find Wireless Network PC Card in one of the sockets, it means the card is detected properly.
Page 14 8. Select Properties from the pop up menu. For Windows 98 the network’ s properties box appears. * For Windows ME and 2000, please select the Local Area Connection’ s properties to check the following menu. 9. Click on the General tab and then click on the Install button. Select Network Component Type box appears.
Page 15 10. Select Network Protocols box appears. From the list of network protocols list, select NetBEUI, then click OK. 11. The NetBEUI protocol is now installed. After clicking on OK return back to Network Component Type box. 12. Repeat the step 9 and 10 to add IPX/SPX protocol. User’...
Page 16 13. Click on the TCP/IP option for setting the IP address for your computer. You can select either Obtain an IP address automatically or Use the following IP address setting. If your choice is the second one then enter the IP value, Subnet masking, DNS, Domain/ Workgroup name, and Gateway Address values.
Page 17 Uninstall Procedure Step 1: If you want to uninstall the WLAN WL-850FJB adapter, just simply click Start Menu à Program à Wireless Network à Uninstall, it shall uninstall all related programs. Step 2: Restart your Computer. User’ s Guide...
Page 18: Configuration Utility
4. Configuration Utility Wireless LAN WL-850FJB 802.11g Wireless LAN WL-850FJB adapter uses its own management software. All functions controlled by user are provided by this application. Usually this application starts automatically, or click icon from Start Menu to start the Utility application.
Page 19: Link Information
4. 1 Link Information This field is used to display the current status of connection. When the state shows “Connected to Network“ means normal flow of operation in Infrastructure mode. The PC is connected to access point. Networking is available. A state of “Scanning”...
Page 20 In these circumstances, the OEM integrator will be responsible for re- evaluating the end product (including the transmitter) and obtaining a separate FCC authorization. ViewSonic declares that WL-850FJB ( FCC ID: GSS-WL850FJB ) is limited in CH1~CH11 for 2.4 GHz by specified firmware controlled in U.S.A.
Page 21 End Product Labeling This transmitter module is authorized only for use in device where the antenna may be installed such that 20 cm may be maintained between the antenna and users (for example: Digital Media Adapter, Router, AP… etc.). The final end product must be labeled in a visible area with the following: “Contains TX FCC ID: GSS-WL850FJB”.
Page 22 Manual Information That Must be Included The OEM integrator has to be aware not to provide information to the end user regarding how to install or remove this RF module in the users manual of the end product which integrate this module. The users manual for OEM integrators must include the following information in a prominent location “...
