GP-710/GP-712 Wireless VoIP Gateway
User Manual
Gempro Technology Inc.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GP-710 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gempro Technology GP-710

  • Page 1 GP-710/GP-712 Wireless VoIP Gateway User Manual Gempro Technology Inc.

  • Page 2: Table Of Contents

    INDEX Introduction............................2 Instruction ............................4 Setup Your Bluetooth Mobile......................4 Status of LED ........................... 4 IVR Interface ............................ 5 Setup the GP-71X by Web Browser....................6 Login............................6 System Information........................6 Route............................7 System ............................8 Network ............................. 9 LAN Settings ...........................

  • Page 3: Introduction

    Introduction VoIP and 2.4G The GP-71X is a revolutionary and innovative product. It Integrates Bluetooth technically in a device, this not only offers high cost-effectiveness in mobile communication for mobile user but also offers very high flexibility in re-building systems. Feature VoIP and Bluetooth Mobile full integration.
  • Page 4 Bluetooth Specification V2. Carrier Frequency 2400MHz to 2483.5MHz Modulation Method GFSK,1Mbps,0.5BT Gaussian Output level, class 2 10 meters working range Package Bluetooth VoIP Gateway：147mm X 108mm X 27mm GP-710: 2.4GHz Antenna＊1 GP-712: 2.4GHz Antenna＊2 Power Supply：Input100-240VAC 50-60Hz Output12VDC 1000mA 1.8m Network Cable...

  • Page 5: Instruction

    Bluetooth mobile pairs successfully that users turn on GP-71X, Bluetooth on your mobile phone and search Audio Device, it will find “GP-710(GP-712-1 and GP-712-2) ” on your searching list then enter the password ”0000” to connect with. It finishes pairing that BT/1 LED on GP-71X is on for 0.1 seconds and off for 0.9 seconds.

  • Page 6: Ivr Interface

    GP-712 status of LED： ON LED： When power on, ON LED will light. ‘1’ LED： First Channel Ready：it is on for 0.1 seconds and off for 0.9 seconds. Set Mode: it is on for 0.9 seconds and off for 0.1 seconds. Ringing：it is on for 0.1 seconds and off for 0.1 seconds.

  • Page 7: Setup The Gp-71X By Web Browser

    Setup the GP-71X by Web Browser The GP-71X provides a built-in web server. You can use Web browser to configure the GP-71X. First please input the IP address in the Web page. In the end of IP address. Default setting is:192.168.0.249.

  • Page 8: Route

    Route 6.3.1.1Uplink Route Fix Number ： After dialing to BT(Bluetooth Mobile) successfully,it will dial appointed sip account or IP. You can add number in front of or behind the number you will dial. Free Dialout ： two-staged dialing.After dialing to BT successfully,you hear a tone then dial sip account or IP.

  • Page 9: System

    System Status It can display the Bluetooth,the status of GP-71X and the last 10 records of communicating Phone No：You can choose Phone1 or Phone2 to set up Setting Volume Adjust the volume of VoIP Gain ： Adjust to gain the volume of input Uplink ：...

  • Page 10: Network

    Network In Network you can check the Network status, configure the Network Settings and DDNS settings. Network Status ： You can check the current Network setting in this page. WAN Settings ： You can configure the WAN setting in this page. The TCP/IP Configuration item is to setup the LAN port’s network environment.

  • Page 11: Lan Settings

    DDNS Setting ： You can configure the DDNS setting in this page. You need to have the DDNS account and input the informations properly. You can have a DDNS account with a public IP address then others can call you via the DDNS account. But now most of the VoIP applications are work with a SIP Proxy Server.

  • Page 12: Sip Settings

    SIP Settings In SIP Settings you can setup the Service Domain, Port Settngs, Codec Settings, Codec ID Setting, RTP Setting, RPort Setting and Other Settings. If the VoIP service is provided by ISP, you need to setup the related informations correctly then you can register to the SIP Proxy Server correctly. In Service Domain Function you need to input the account and the related informations in this page, please refer to your ISP provider.
  • Page 13 Port Settings ： you can setup the SIP and RTP port number in this page. Each ISP provider will have different SIP/RTPport setting, please refer to the ISP to setup the port number correctly. When you finish the setting, please click the Submit button. Codec Settings ：...

  • Page 14: Nat Trans

    RPort Function ： you can setup the RPort Enable/Disable in this page. To change this setting, please following your ISP information. When you finish the setting, please click the Submit button. Other Settings ： you can setup the Hold by RFC, Voice/SIP QoS and SIP expire time in this page. To change these settings please following your ISP information.

  • Page 15: Authority

    Authority. In System Authority you can change your login name and password. 6.10 Save In Save Change you can save the changes you have done. If you want to use new setting, You have to click the Save button. After you click the Save button, the GP will automatically restart and the new setting will effect.

  • Page 16: Reboot

    In Default Setting you can restore to factory default in this page. You can just click the Restore button, then will restore to default and automatically restart again. 6.12 Reboot Reboot function you can restart.

  • Page 17: Q&A

    Q&A Q.1 Why does NOKIA mobile just dial in not dial out after pairing? Because dial out command in NOKIA can not add ‘;’ behind dial code.You just write on the option of Downlink. Q.2 Why does it just have the function of Last number? Few of Bluetooth mobiles have this function,please change your mobile Q.3 Why doesn’t one of you hear the sounds from another one? Maybe it is baffled by firewall,please open STUN and refer to the website of...

  • Page 18: Appendix

    Appendix: Federal Communications Commission (FCC) Statement RADIO FREQUENCY INTERFERENCE BTATEMENT This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 19 Gempro Technology Inc. 6F,No.314,Sec. 3,Fusing Rd.,Taichung,Taiwan(R.O.C.) TEL:886-4-22292128 FAX:886-4-22298778 E-mail: service@gempro.com.tw webs: http://www.gempro.com.tw...
  • Page 20 FCC ID:XTA0800V2B27012 FCC Compliance and Advisory Statement This device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions:(1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, according to Part 15 of the FCC rules.
  • Page 21 CE Statement Hereby, Gempro Technology Inc. declares that this GP-712 is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
