VT-7108 Users manual
name
: Technical Instructions
NO. : VT1.7108.000CS
: 01
: Luoxiangrong
:
:
signet
Advertisement
Summary of Contents for Videotek VT-7108
- Page 1 Videotek Company Limited VT-7108 Users manual Document name : Technical Instructions Document NO. : VT1.7108.000CS Version : 01 Compiler : Luoxiangrong Checker Authorizer Commencement date: On November 8,2013 Distribution NO. : signet All rights reserved, the pirate edition investigates necessarily!
-
Page 2: Technical Instructions
Technical Instructions Volume : Volume Two Total Pages : 5 Pages Total Volume : One Volume Product NO. ：VT-7108 Product name : Wireless Transmission Product drawing NO.: VT1.7108.000CS Compiler : Luoxiangrong Checker Authorizer On November 8,2013 Videotek Company Limited... -
Page 3: External View
External View... - Page 4 1.Subject matter and Applications The instructions stated the series of VT-7108 is made up of WIFI image transmission;HD cameras,etc.It is a remote wireless monitoring transmitter contains image collection ,compression storage transport functions. The technical requirements include features;technical parameter;operation manual etc.The series of product of VT-7108 will display the image on the andriod/iphone/ipad etc.smart phone thru WIFI.
- Page 5 3.Technical Data Wireless transmitter It is made of super compressive engineering plastic ,high efficiency power and high resolution camera etc. 3.1 Video input:Composite Video,1V(p-p)+or-20% 75 Ohms 3.2 Dimensions:IPHONE or Android etc.Varies of smart phone 3.3 System: Above Android 2.3 or IOS 6.0 3.4 wireless parameter: Frequency range:2412-2472MHz Wireless transmit operation mode:ieee802.11b/g/n...
- Page 6 3.14 Operating temp:-15ºC-- +65ºC 3.15 Storage temp:-20ºC-- +70ºC 2hours, 30seconds to turn it on 3.16 Whole dimension:279mm(length)×152mm(wide)×167mm(high) 3.17 maximum transmission distance:80M 4.7108 Operating instructions 4.1 OSD instructions CONNECT NOW (Connect video and display image) SYSTEM STEP CHANGE WIFI NAME CHANGE WIFI PASSWORD FACTORY Default BACK LIBRARY (Photos or video skinning)
- Page 7 3.Power switch,short pressing to turn it on;Long pressing more than 2 seconds to turn it off;3times short pressing to reset. 4.Video port.To connect the video with varies of same ports. 4.3 FISHphone WIFI wireless monitoring operation manual 1.Make sure the camera have connected with the WIFI equipment.As shown below: 2.turn on the power of WIFI equipment,the equipment include a rechargeable battery,when insert the special charger in the DC...
- Page 8 system. 3.On the mobile phone standby mode shown as below ,click “settings”and set the “WIFI”. 4.Click “WIFI”select the name of the wireless router.As shown below:...
- Page 9 5.select “FISHPhone”WIFI net,when there is a “√”on the fishphone,wireless router has selected,then click “home”back. 6.On the mobile phone standby mode shown as below,click “FISHPone”and enter. 7.Appeared as shown below:...
- Page 10 (In the official version of the software, only the first time using this software will appear the following screen) Click “click here”for end user license agreement and will show the following page,and click “back”key back.
- Page 11 Click “ View Usage Warnings” and will turn to following page,and click “back”key back.
- Page 12 Click “ I agree” and will turn to following page,(In the official version of the software, only the first time using this software will appear the following screen) Click “ ” and will turn to following page,...
- Page 13 When the equipment is normal connection,the LED light will flash rapidly,it means the system is on normal operation. B.click the screen of monitoring enter the full screen monitoring...
- Page 14 Click “ ” and show the following page.then it can set the “WIFI name”and “passwords” Click “ Change WIFI name” and show the following page...
- Page 15 OLD WIFI NAME will recognize automatically, generally don't have to set. NEW WIFI NAME to modify the NAME, input the NEW NAME. CONFIRM after input the name click this button to CONFIRM the modification. Cannel for the cancel button, that is, cancel and return to the interface of a changed.
- Page 16 7.click “ ”and enter the monitoring screen to take photos,as it is shown below,when the button become red,it means monitoring photos have been taken. 8.Click “ ”and enter the monitoring screen to record videos,as it is shown below,when the button become red,it means recording the monitoring video.click“...
- Page 17 9.9.click “ ”and turn off the LED light of camera.click and adjust the brightness of LED light. 10.Click “ ”and enter the function of browsing photos.then click “camera roll”and browsing the photos.
- Page 18 13.click one photo and show below, Click “Cancel”back to “camera roll”interface,click “choose”back to monitoring interface.
