Proware PW-MN427_34I User Manual

150mbps wireless n usb module
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
PW-MN427_34I
150Mbps Wireless N USB Module

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PW-MN427_34I and is the answer not in the manual?

Questions and answers

Summary of Contents for Proware PW-MN427_34I

  • Page 1 PW-MN427_34I 150Mbps Wireless N USB Module...

  • Page 2: Fcc Statement

    FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may c ause ha rmful interference t o r adio c ommunications.

  • Page 3: Ce Mark Warning

    CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. National restrictions This device is intended for home and office use in all EU countries (and other countries following the EU directive 1999/5/EC) without any limitation except for the countries mentioned below: Country Restriction...

  • Page 4: Chapter 1 Introduction

    TKIP, AES，WPA and WPA2 encryption to prevent outside intrusion and protect your personal information from being exposed. Featuring high performance transmission rates, s imple installation and adaptability, as well as strong security, the PW-MN427_34I 150Mbps Wireless N USB Module is the perfect solution for small office and home needs. Main Features 150Mbps wireless transmission rate ...

  • Page 5: Chapter 2 Installation Guide

    Chapter 2 Installation Guide 2.1 Hardware Installation PW-MN427_34I has USB interface(4-PIN connector,2.0mm pitch), and it is mainly d esigned to provide stability wireless function and performance for your system. For installation, you must be sure to connect this module to your device or system with a connecting wire first.
  • Page 6 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Figure 2-1 Start The Installation Choose Update Driver Software, You’ll see the screen as below. You should choose the second item and click Browse my computer for driver software. Figure2-2 Update Driver Software...
  • Page 7 PW-MN427_34I 150Mbps Wireless N USB Module User Guide 3. In the following screen, browse for driver software on your computer. Choose the destination location and click Next. Figure2-3 Browse For Driver 4. You will see the next screen as below, installing will appear.
  • Page 8 PW-MN427_34I 150Mbps Wireless N USB Module User Guide 5. Wait for a moment , and you will see Windows has successfully update your driver software. Figure2‐5 Driver Is Installed 6. After you installing the driver，please restart your computer then the hardware you installed will work, go to the Device Manager and check that 802.11n USB Wireless LAN Card is...

  • Page 9: Uninstall Software

    PW-MN427_34I 150Mbps Wireless N USB Module User Guide 2.3 Uninstall Software 2.3.1 Uninstall the driver software from your PC 1. On the Windows taskbar, click the Start button, and then click Control Panel. Click the System icon, click on the Hardware tab in the System window.

  • Page 10: Chapter 3 Example For Application

    Please ensure the software and hardware environments are well established before configuring. For hardware, at least a PC, a PW-MN427_34I 150Mbps Wireless N USB Module and a PSP device are needed. For software, the PW-MN427_34I Module driver should be properly installed.
  • Page 11 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Right-click “My Computer” and select Management. In the prompt page, click Device Step 5. Manager, then right-click “Wireless N Client Module “and select Properties. Then set the value of “PSP Xlink Mode” as Enable following the red marked instruction in the figure.
  • Page 12 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Figure 3-4 In the prompt page shown below, select Use the Following IP Address, and set the IP Step 8. and Subnet mask. After completing setting, click OK. Figure 3-5  Note: Please set the IP address in different network segment with the other network card to avoid conflict.
  • Page 13 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Figure 3-6 Click the icon on the right top corner to enter the Arena Mode, highlight the arena of Step 11. your wanted game, and then join or start a new game.
  • Page 14 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Hardware installation example Figure 3-8 - 13 -...
  • Page 15 PW-MN427_34I 150Mbps Wireless N USB Module User Guide Appendix A: Glossary 802.11b The 802.11b standard specifies a wireless networking at 11 Mbps using direct-sequence sp read-spectrum (DSSS) technology a nd operating in the unlicensed radio spectrum at 2.4GHz, and WEP encryption for security. 802.11b networks are also referred to as Wi-Fi networks.
  • Page 16 PW-MN427_34I 150Mbps Wireless N USB Module User Guide WEP (Wired Equivalent Privacy) - A data privacy mechanism based on a 64-bit or 128-bit shared key algorithm, as described in the IEEE 802.11 standard. Wi-Fi A trade name for the 802.11b wireless networking standard, given by the Wireless Ethernet Compatibility Alliance (WECA, see http://www.wi-fi.net), an industry standards group...

  • Page 17: Appendix B: Specifications

    PW-MN427_34I 150Mbps Wireless N USB Module User Guide Appendix B: Specifications General Interface USB 2.0 (4-PIN connector,2.0 pitch) Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b Operating System Windows XP/ Vista/ 7 , Linux OS, Android Safety & Emission FCC, CE 2.4-2.4835GHz...
