Summary of Contents for Sonorix A1
-
Page 2: Table Of Contents
Clipping the A1 onto Sun Visor OLED Display Charging the Battery Switching the A1 ON/OFF Echo & Noise Cancellation Pairing and Connecting A1 with Bluetooth Devices Using A1 for Handsfree Operations Audio Tuning A1 with My Cell Phone Specifications Safety Instructions Check the laws and regulations on the use of mobile phones and handsfree equipments in areas you intend to use. -
Page 3: Introduction
Introduction The sonorix Bluetooth Handsfree Kit A1 is a state-of-the-art device for handsfree operations at its best. It functions as 'Car Handsfree Kit' or 'Portable Speakerphone' when linked to Bluetooth phones supporting Headset or Handsfree profiles. Uniquely designed to be portable and versatile, A1 provides you with maximum comfort and satisfaction for all of your handsfree needs whether you use the device in car, outdoor or in office. -
Page 4: Description Of Parts
Microphone USB Port Power Switch (only charging) Clipping the A1 onto Sun Visor Mount the clip onto the back of A1 and slide the clip onto sun visor as shown below. OLED Display Bluetooth Connection Status Mode Indicator Hold Indicator... -
Page 5: Charging The Battery
(The USB port is used for charging only.) Switching the A1 ON/OFF To switch on A1, slide the power switch to O. With a boot tone, it will first display the sonorix logo followed by connection state icons and battery level indication. -
Page 6: Echo & Noise Cancellation
A1 onto sun visor. On the other hand, if A1 is used as ‘Speakerphone’ mode, it doesn’t matter in which direction the A1 is placed as noise signals generated from... -
Page 7: Pairing And Connecting A1 With Bluetooth Devices
Pairing mode lasts for 3 minutes, after this sonorix A1 Mode period A1 returns to standby mode. Note : A1 can be paired with up to 3 devices. To 00150E001A05 delete all pairing information, long click MFB while A1 is in pairing mode. -
Page 8: Using A1 For Handsfree Operations
MUTE/HOLD button Mic. Muted Mute during talk mode. To cancel mute function, short click MUTE/HOLD button. Call During talk mode, to transfer call from A1 to phone Call Transfer Transfer or vice versa, long click MUTE/HOLD button. - Page 9 Function Action Display During talk mode, if you receive another call, long click MFB to hold the 1 call and answer 2 call. To toggle between calls, long click MFB. During Call Waited talk mode, by short clicking MFB, you can end the 3 Way Call current call to continue with the next call.
-
Page 10: Audio Tuning A1 With My Cell Phone
A1, if you encounter such problems, you can calibrate the speaker and microphone settings of your A1 device. To be able to adjust the microphone setting, A1 has to be in talk mode. During talk mode long click [+] or [-] button. Followed by a beep tone, the following icon will then be displayed. -
Page 11: Specifications
Specifications Standards Bluetooth Specification V2.0 RF Frequency Range 2402 ~ 2480 MHz Profiles Supported Headset, Handsfree Transmission Power 0.25 ~ 2.5mW (Class 2) Distance 10m (in open space) Audio Output > 1W Standby > 400 hrs Battery Life Continuous Talk Time > 15 hrs Charging Time <... - Page 12 Product Warranty Disclaimer Notice The manufacturer shall not be liable for errors OpenBrain Technologies warrants this contained herein incidental product against all defects in material consequential damages in connection with and workmanship for a period of one the furnishing, performance or use of this year from the date of purchase by end material.
