Page 2: Introduction
POTS (Plain Old Telephone Service) land-line replacement service. TX241G is designed to provide a simple, cost effective dial tone service at a home or business. The TX241G is powered by an AC adapter with a 1600mAh rechargeable battery backup to provide continued functionality in the event of a power outage. -
Page 3: Features
FEATURES CDMA2000 1x-Advanced Voice Services (backward compatible to IS-95 A/B) 800/1900 MHz Dual Band OMA-DM HFA Activation and FUMO Support AGPS for E911 Service Support TTY/TDD Telephone Support 5 Multiple LED Indicators (Power, Battery, Voicemail Waiting Indicator, Mode, CDMA) 2 RJ-11 Bridged Ports to Connect to POTS Phones Dial-Tone and DTMF Generation Call Waiting, Three-way Calling,... -
Page 4: Table Of Contents
TABLE OF CONTENTS INTRODUCTION Setting Up Your Voicemail Overview Making Callls Features Answering Calls Safety Precautions Default Reset Package Contents Factory Reset TTY/TDD-Mode Setting BASIC INSTALLATION Battery Installation OPTIONAL FEATURES Setting Up The Device Caller ID E911 Information Setting Caller ID Mode Call Waiting GETTING TO KNOW THE TERMINAL 3-Way Calling... -
Page 5: Safety Precautions
- The power cord is damaged. - The adapter has been damaged in any way. 7. Use only the AXESSTEL provided power adapter. Do not use the AXESSTEL power adapter for any other purpose. 8. Use only the AXESSTEL provided antenna. Do not use the antenna for any other purpose. - Page 6 11. Do not use the terminal near water, for example, near a bathtub, sink, wet basement, or swimming pool. NOTE: The input voltage and the shape of the power plug may vary from country to country. NOTE: Use wired or cordless telephones compatible to FCC part 68 only. Non-compliant telephones may not work properly.
-
Page 7: Package Contents
After opening the package, check to make sure that you have all the parts shown below. If any item is missing or broken, please call your service provider’s support center. ① Axesstel 1x-Advanced Fixed Wireless Terminal ② CDMA Dipole Antenna ③... -
Page 9: Basic Installation
BASIC INSTALLATION BATTERY INSTALLATION The TX241G operates on either AC current or its internal battery. However, you should use AC power whenever possible, reserving the battery for power outages. 1. Open the battery cover on the bottom of the device. -
Page 10: Setting Up The Device
SETTING UP THE DEVICE 1. Connect the antenna by screwing it into the connector on the back of the device. 2. Connect a wired or cordless telephone to the device using the supplied RJ-11 phone cord. 3. Plug the power adapter cable into the device. 4. -
Page 11: E911 Information
E911 INFORMATION Your device features an embedded Global Positioning System (GPS) chip necessary for utilizing E911 emergency location services where available. During the emergency call, all the LEDs on the terminal will blink and your location can then be determined by the 911 operator. IMPORTANT: Always report your location to the 911 operator when placing an emergency call. -
Page 12: Getting To Know The Terminal
GETTING TO KNOW THE TERMINAL LED INDICATOR LIGHTS Item Color Status Description POWER Green Solid BATTERY Green Solid Battery is sole source, power above mid-voltage Green Blinking AC is sole source, battery charging Solid Battery is sole source, voltage low Blinking AC is sole source, no battery CDMA... - Page 13 VOICEMAIL Solid Voicemail in the system No new voicemail E911 Call All LEDs Blinking All LEDs blink during emergency call...
-
Page 14: Audio Signals Heard On Phone
AUDIO SIGNALS HEARD ON PHONE Sound Description Remarks Normal Dial Tone Standard dial tone Your device is working properly. When you receive voice messages you will hear this tone. The Voicemail LED Voicemail Message will be red. If you have a voicemail Wavering beep Tone message waiting when you need to make... -
Page 15: Basic Operation
Basic Operation POWER ON/OFF ACTIVATION SETTING UP YOUR VOICEMAIL MAKING CALLS ANSWERING CALLS DEFAULT RESET FACTORY RESET TTY/TDD-MODE SETTING... -
Page 16: Power On/Off
4. Turn device off by pushing power button on top of device for several seconds, then release. The green light will turn off. ACTIVATION To activate your TX241G using Over the Air Service Provisioning (if supported by your carrier): 1. Turn on your device. 2. The device will begin its initiation process and start to acquire the network. -
Page 17: Setting Up Your Voicemail
SETTING UP YOUR VOICEMAIL You should set up your voicemail and personal greeting as soon as your device is activated. Always use a password to protect against unauthorized access. Please check with your service provider for the voicemail access number. Your device automatically transfers all unanswered calls to your voicemail, even if your device is in use or turned off. -
Page 18: Answering Calls
1. Lift the handset on any connected phone to answer a call. DEFAULT RESET If you want to clear any changes you have made to your TX241G’s settings and reset it to the default settings: 1. Lift the handset on any connected phone. -
Page 19: Tty/Tdd-Mode Setting
TTY/TDD-MODE SETTING Configure your device for TTY use. The default setting is OFF. 1. Lift the handset on any connected TTY/TDD phone and choose one of the following options: □ □ □ □ □ □ • Press # for TTY Full Mode. □... -
Page 20: Optional Features
Optional Features CALLER ID SETTING CALLER ID MODE CALL WAITING 3-WAY CALLING... -
Page 21: Caller Id
2. Enter your phone number. SETTING CALLER ID MODE If the phone you have connected to your TX241G has an LCD display, the caller’s number will appear by default. To change this setting: 1. Lift the handset of any connected phone. -
Page 22: 3-Way Calling
3-WAY CALLING With 3-Way Calling you can talk to two people at the same time. When using this feature, the normal airtime rates will be charged for each of the two calls. To use 3-way calling: 1. Call the first party. 2. -
Page 23: Miscellaneous
Miscellaneous TROUBLESHOOTING SPECIFICATIONS SAFETY INFORMATION... -
Page 24: Troubleshooting
3. Check the phone cord to make sure it is properly connected. 4. Try connecting the TX241G to a different telephone. 5. If you perform all of the above steps and still can’t make a call, contact your service provider. - Page 25 3. Check the antenna to make sure it is tightly connected. 4. Next move the TX241G to another location in your home. 5. If after taking the above steps you still don’t have a dial tone and the CDMA LED is off, contact your service...
-
Page 26: Specifications
SPECIFICATIONS Item Description Remark Air Interface CDMA2000 1X-Advanced RF Frequency 800MHz/1900Mhz Dual band - 5 Multiple LEDs LED Indicator - POWER, BATTERY, VOICEMAIL WAITING INDICATOR, Green, Red, Off MODE, and CDMA - 2 RJ-11 Ports (bridged), Max 4 REN - DC power Jack Interface - Power ON/OFF Button - TNC Connector for CDMA antenna with GPS antenna... - Page 27 Tone Dial, No Service, Howler, Stutter, Menu OK, Menu NOK Hook Flash Call Waiting Call feature Call Forwarding 3-Way Calling - Li-ion rechargeable battery - Capacity :1600mAh (Standard) Battery * Stand by time: 15 Hrs * Talk time:1.5 Hr - Input: AC100-240V, 50/60Hz Power Adapter - Output:5V/ 2A - Size: 174 X 128 X 34 (mm)
-
Page 28: Safety Information
SAFETY INFORMATION This device complies with Part 15 of the FCC Rules. Its operation is subject to the following two conditions: 1. This device may not cause harmful interference, and 2. This device must accept any interference received, including interference that may cause undesired operation. Note: This product has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 29 FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. Radiation Exposure Statement: This device meets the government's requirements for exposure to radio waves.
- Page 30 AXESSTEL INC. 6815 Flanders Drive Ste. 210 San Diego, CA 92121, USA www.axesstel.com © Axesstel Inc, All Rights Reserved...
