ASSEMBLY AND OPERATION INSTRUCTIONS CHARCOAL SPIT
Model: KYQ-C001
Thank you for buying a TASTY TROTTER Charcoal Spit Roast, we trust it will give you
many years of service and many successful catering events
FOR OUTDOOR USE ONLY
PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY
RETAIN THIS MANUAL FOR FUTURE REFERENCE
1
Advertisement
Related Manuals for Tasty Trotter KYQ-C001
Summary of Contents for Tasty Trotter KYQ-C001
- Page 1 ASSEMBLY AND OPERATION INSTRUCTIONS CHARCOAL SPIT Model: KYQ-C001 Thank you for buying a TASTY TROTTER Charcoal Spit Roast, we trust it will give you many years of service and many successful catering events FOR OUTDOOR USE ONLY PLEASE READ INSTRUCTIONS CAREFULLY BEFORE ASSEMBLY...
- Page 3 WARNING ● This charcoal spit may only be used outdoors, NEVER INDOORS. ● Never leave the charcoal spit unattended while in use. ● Do not use in high winds. ● Charcoal spit should be kept in a level position at all times. ●...
- Page 4 WARNING ● Never modify this rotisserie as damage and injury may occur, and this will void your warranty. ● Read and understand all instructions. ● DO NOT touch hot surfaces. Use handles or knobs. ● The use of accessory attachments is not recommended by the appliance manufacturer as it may cause injuries.
- Page 5 Please refer to the parts list and assembly diagram as necessary. Assembly of the barbecue involves many large components, it is advisable to have two people assemble the unit. NOTICE: Make sure all the plastic protection rip off before assembling! Exploded view: KYQ-C001...
- Page 6 Part List: KYQ-C001 Description C001 Spit Shaft left bracket Counterweight shaft Counterweight Spit shaft 4 Prong Meat Retainer U Meat Retainer U Meat Retainer Plate R Clip Spit Shaft right bracket Motor support Motor Motor fixed bracket Cooking grill Charcoal tray...
- Page 7 Ref # 15 Ref # 16,17,18 Ref # 16,17,18 Ref # 1 Ref # 9,10,11,12...
- Page 8 Ref # 13 Ref # 14 Ref # 4 Ref # 5 Ref # 6,7,8 Ref # 5 Ref # 2,3...
- Page 9 Firstly, lower the height of the left bracket, so that the left bracket is in line with the hole on the bottom of the right bracket. Put the shaft on it (Picture 8). Secondly, use the rotisserie and retainers to attach the food and adjust the counterweight accordingly, so that the shaft can balance.
- Page 10 NOTE FOR CONSUMER: Retain for future Reference This charcoal spit is designed for use OUTDOORS, away from any flammable materials. It is important that there are no overhead obstructions and that there is a minimum distance of 1.5 m from the side or rear of the appliance. It is important that the ventilation openings of the appliance are not obstructed.
- Page 11 2. Fit a rainproof cover over the charcoal spit when it is not in use. VERY IMPORTANT INFORMATION CARE AND PROTECTION OF STAINLESS STEEL SURFACES Your BBQ features Stainless Steel components, using moderate grade Stainless Steels. All Stainless Steel grades require a level of care and protection to retain their appearance. Stainless Steels are not immune to corrosion and neither are they maintenance-free, contrary to popular public perception.
- Page 12 Tasty Trotter Ltd. UK Bridge Street Clay Cross Derbyshire S45 9NU Tel: +44(0)1246 866800 Email: info@tastytrotter.com Website: www.tastytrotter.com...
