Summary of Contents for Eastic Tech W801
- Page 1 WiFi Intelligent Wireless Visible Door Bell...
- Page 2 1 Product introduction WiFi Intelligent Wireless Visible Door Bell could link with wireless router or directly with the cable for use, the handset includes mobile phone, tablets to connect with the bell, when visitors press the bell, handsets could make video and voice calls with the bell, unlock, take photos and record videos. It has P2P cloud service pushing function.
- Page 4 4.Installation diagram Accessories Location choice for door machine: installation height of 1.5m, the location should have few barrier with WiFi router 1. Use four screws to fix the rain-proof cover on the wall; 2. Use one screw to fix the bell bottom; 3. The installation is finished.Bell matching 5.1.1 Join WLAN to link the doorbell (ignore this for cable use) 1.Press call button for over 5secs, operate by the voice instruction 2.
- Page 5 4. click ‘add doorbell’ in the main interface of the APP on phone or tablets; Press take-picture button click the automatic monitoring 5.fishish the adding by manual, 2D code scanning to add ID; to take picture, check in on the bell (online) in the the main interface picture;...
- Page 6 Match the doorbell the bell into the router (ignore this for cable use) Press unlock button to unlock 6.2 Unlock Talk-listen switch...
- Page 7 1. When visitors press the bell, answer and hang up 2. When any handset is answered, other handsets would automatically hang up, video recording, picture taking and unlocking would be done within the calling, press end to hang up; 7. now you can change name, ID, user name and password, click finish to submit;...
- Page 8 10. In the bell setup interface, click wifi setup, and click manage wifi network when it’s connected; 11. The device will list the found effective router, please select target router (SSID); 12, input password, click ‘finish’ to submit, then the bell would restart, after one min, the handset would find the bell online check past visited pictures, video list could directly play visitors’...
- Page 9 1. Navigate to the sub-interface to maintain the installed doorbell; 2. Select and single click ‘delete’ to batch-delete the selected device; Click to set up bell ringtone, Check past visitor calls, alarming, 3. Directly edit the doorbell name, ID, login, username, password, finish and alarming tone, software received calls and un-received calls, click finish button...
- Page 10 1. Administrator could add new user, delete current user, common user could only change their password, same user could not log on different phones 2. Change user password; 1.Click on the icon to make parameter setup 3. Add new user. 2.System setup interface NOTE: This equipment has been tested and found 5.3.1...
- Page 11 to comply with the limits for a receiver is connected. Class B digital device, pursuant to part 15 of the -Consult the dealer or an experienced radio/TV FCC Rules. These limits are technician for help designed to provide reasonable protection against harmful interference in a Changes or modifications not expressly approved residential installation.
