This document specifies the important information to use this product correctly and
safely and the License Agreement of Attached Software for YFGW510 Field Wireless Ac-
cess Point.
Before use the product, be sure to read this document first.
The configuration of the field wireless system is described in User's Manual of the
YFGW410 Field Wireless Management Station (IM 01W02D01-01EN). Read that document
first.
Contents
Introduction ...................................................................................................2
Safety Precautions .......................................................................................4
Explosion Protected Type Specifications .............................................. 13
FM Approval ......................................................................................... 15
Control Drawing (Doc. No. NFM027-A14) .................................... 17
CSA Certification .................................................................................. 19
ATEX Certification ................................................................................ 23
IECEx Certification ............................................................................... 30
Ground Cable Connection .................................................................. 37
How to Use Online Manual ....................................................................... 38
Preparation to Use YFGW510 Attached Software ................................. 38
Copyright and Trademark Notices .......................................................... 39
Patent Notice ............................................................................................. 39
Open Source Software ............................................................................. 40
About User's Manual ................................................................................ 40
Information of User's Manual Revision .................................................. 41
YFGW510 Software License Agreement ................................................. 42
YFGW510
Field Wireless Access Point
Read Me First
IM 01W02E01-11EN
IM 01W02E01-11EN
8th Edition

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YFGW510 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for YOKOGAWA YFGW510

Summary of Contents for YOKOGAWA YFGW510

  • Page 1: Table Of Contents

    IM 01W02E01-11EN This document specifies the important information to use this product correctly and safely and the License Agreement of Attached Software for YFGW510 Field Wireless Ac- cess Point. Before use the product, be sure to read this document first.

  • Page 2: Introduction

    This manual (IM 01W02E01-11EN) describes the safety precautions, explosion protected type specifications and the license agreement of attached software for the YFGW510. There are three documents including this one for the YFGW510 listed below. Read them along with this manual.
  • Page 3 <Read Me First> ATEX Documentation This is only applicable to the countries in European Union. F01.ai IM 01W02E01-11EN...

  • Page 4: Safety Precautions

    If any protection or safety circuit is required for the system controlled by the product or for the product itself, prepares it separately. Be sure to use the spare parts approved by Yokogawa Electric Corporation (hereafter simply referred to as Yokogawa) when replacing parts or consuma- bles.
  • Page 5 If these instructions are not heeded, the protec- tion provided by this instrument may be impaired. In this case, Yokogawa cannot guarantee that the instrument can be safely operated. Please pay special attention to the following points: (a) Installation •...
  • Page 6 If you need to repair or modification, please contact the nearest Yokogawa office. (f) Modification • Yokogawa will not be liable for malfunctions or damage resulting from any modificationmade to this instrument by the customer. (g) Product Disposal •...
  • Page 7 Yokogawa shall have neither liability nor responsibility to any person or entity with respect to any direct or indirect loss or damage arising from using the product or any defect of the product that Yokogawa can not predict in ad- vance.
  • Page 8 Yokogawa Electric Corporation. Radio Equipment Directive Hereby, Yokogawa Electric Corporation declares that the radio equipment type YFGW510 is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is avail- able at the following internet address: http://www.yokogawa.com/fld/...

  • Page 9: Fcc Compliance

    <Read Me First> FCC compliance YFGW510 contains transmitter module • FCC ID: SGJ-WFC006 (All Model) • FCC ID: SGJ-WFC008 (Wireless LAN Single Model) • FCC ID: SGJ-WFC009 (Wireless LAN Redundant Model) Co-located: This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
  • Page 10 <Read Me First> Industry Canada (IC) compliance YFGW510 contains transmitter module • IC: 8999A-WIC003 (All Model) • IC: 8999A-WIC007 (Wireless LAN Single Model) • IC: 8999A-WIC008 (Wireless LAN Redundant Model) This Class A digital apparatus complies with Canadian ICES-003. Cet appareil numérique de la classe A est conforme à la norme NMB-003 du Canada.
  • Page 11 <Read Me First> RF Exposure Compliance: This equipment complies with IC radiation exposure limits set forth for an uncontrolled environ- ment and meets RSS-102 of the IC radio frequency (RF) Exposure rules. This equipment has very low levels of RF energy that it deemed to comply without maximum permissive exposure evaluation (MPE).
  • Page 12 （Hg） （Cd） （Cr(VI)） （PBB） （PBDE） 壳体 × ○ ○ ○ ○ ○ 基板组件 × ○ ○ ○ ○ ○ YFGW510 现场无线接入点 电缆 × ○ ○ ○ ○ ○ 天线组件 × ○ ○ ○ ○ ○ ○：表示该部件的所有均质材料中的有害物质的含量均在GB/T26572 标准中所规定的限量以下。 ×：表示至少该部件的某些均质材料中的有害物质的含量均在GB/T26572 标准中所规定的限量以上。 环保使用期限：...

  • Page 13: Explosion Protected Type Specifications

    <Read Me First> Explosion Protected Type Specifications Optional Specifications (For Explosion Protected Type) Item Description Code Factory FM Nonincendive Approval Mutual Applicable standards: Class 3600:2011, Class 3611:2004, (FM) Class 3810:2005, NEMA 250:2003 Nonincendive for Class I, Division 2, Groups A, B, C and D; alternatively for Class I, Zone 2, Groups IIC.

  • Page 14: Installation Of An Explosion Protected Instrument

    If a customer makes a repair or modification to an explosion protected instrument and the instru- ment is not restored to its original condition, its explosion protected construction may be com- promised and the instrument may be hazardous to operate. Please contact Yokogawa before making any repair or modification to an instrument.

  • Page 15: Fm Approval

    FM Approval Caution for FM Nonincendive Approval (1) Technical Data Note 1. Model YFGW510 Field Wireless Access Point with optional code FN17 is applica- ble for use in hazardous (classified) locations. • Applicable standards: Class 3600:2011, Class 3611:2004, Class 3810:2005, NEMA 250:2003 •...
  • Page 16 <Read Me First> (4) Electrical Connection • The type of electrical connection depends on the marking below on YFGW510. Marking The type of electrical connection Note M20 (ISO) M20 X 1.5 1/2 NPT 1/2-14 • This marking is incused at the back side of the electrical connection block.

  • Page 17: Control Drawing (Doc. No. Nfm027-A14)

    <Read Me First> (5) Control Drawing F04.ai IM 01W02E01-11EN...
  • Page 18 <Read Me First> F05.ai IM 01W02E01-11EN...

  • Page 19: Csa Certification

    <Read Me First> CSA Certification Caution for CSA Non-incendive Certification (1) Technical Data Note 1. Model YFGW510 Field Wireless Access Point with optional code CN17 is applica- ble for use in hazardous area. • Certificate: 2655412 • Applicable standards: C22.2 No.0-10, CAN/CSA-C22.2 No. 0.4-04, CAN/CSA-C22.2 No.
  • Page 20 • This marking is incused at the back side of the electrical connection block. Marking F06.ai (4) Installation Hazardous Location Hazardous Location Nonhazardous Location Zone 2 / Division 2 Electrical Equipment YFGW510 (e.g.) “d”, “i”, “Type n” equipment Field Wireless Access Point Control Equipment 2 Antenna Antenna (*1) (*1)
  • Page 21 <Read Me First> WARNING • POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE INSTRUCTIONS • DANGER POTENTIEL DE CHARGES ÉLECTROSTATIQUES – VOIR INSTRUCTIONS • DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE MAY BE PRESENT • NE PAS OUVRIR SI UNE ATMOSPHÈRE EXPLOSIVE PEUT ÊTRE PRÉSENTE •...
  • Page 22 Style code. SUPPLY: Specified supply voltage and wattage. NO.: Serial number and year of production *1. YOKOGAWA TOKYO 180-8750 JAPAN: The manufacturer name and the address *2. Production year and month are shown as yyyy.mm. For example, 2013.01 denotes January 2013.

  • Page 23: Atex Certification

    • POTENTIAL ELECTROSTATIC CHARGING HAZARD. (1) Technical Data a. Caution for ATEX Type n declaration Note 1. Model YFGW510 Field Wireless Access Point with optional code /KN27 is appli- cable for use in hazardous area. • Applicable standard: EN60079-0: 2012+A11:2013, EN60079-11: 2012, EN60079-15: 2010 •...
  • Page 24 Care should be taken to avoid multi-point earthing since the equipment is not galvanically isolated from the power supply. • YFGW510 does not have a power switch inside. Prepare a dedicated breaker for the exter- nal power line to turn ON/OFF the device.
  • Page 25 <Read Me First> b. Caution for ATEX Flameproof Certification Note 1. Model YFGW510 Field Wireless Access Point with optional code KF27 is applica- ble for use in hazardous locations. • Certification: DEKRA 15ATEX0042 X • Applicable Standards: EN 60079-0:2012+A11:2013, EN 60079-1:2007, EN 60079-1:2014, EN 60079-11:2012 •...
  • Page 26 Care should be taken to avoid multi-point earthing since the equipment is not galvanically isolated from the power supply. Note 4. Control Drawing Hazardous Location Hazardous Location Nonhazardous Location Zone 1 Electrical Equipment YFGW510 Field Wireless Access Point Control Equipment 2 Antenna Antenna (*1) (*1)
  • Page 27 • They do not contain any means of increasing voltage or current, such as DC-DC converters. • They are not separated from the earth and must earthed together with YFGW510 in accordance with EN 60079-14. • They have metallic enclosures and no risk for electrostatic discharges.
  • Page 28 <Read Me First> (2) Electrical Connection • The type of electrical connection depends on the marking below on YFGW510. Marking The type of electrical connection Note M20 (ISO) M20 X 1.5 A or N ANSI 1/2 NPT 1/2-14 NPT This marking is incused at the back side of the electrical connection block.
  • Page 29 Style code. SUPPLY: Specified supply voltage and wattage. NO.: Serial number and year of production YOKOGAWA TOKYO 180-8750 JAPAN: The manufacturer name and the address Production year and month are shown as yyyy.mm. For example, 2013.01 denotes January 2013. “180-8750” is a zip code which represents the following address.

  • Page 30: Iecex Certification

    IECEx Certification (1) Technical Data a. Caution for IECEx Type n Certification Note 1. Model YFGW510 Field Wireless Access Point with optional code SN27 is applica- ble for use in hazardous area. • No. IECEx DEK 14.0028 • Applicable standards: IEC60079-0:2011, IEC60079-11:2011, IEC60079-15:2010 •...
  • Page 31 <Read Me First> Note 3. Installation WARNING • POTENTIAL ELECTROSTATIC CHARGING HAZARD – SEE INSTRUCTIONS • DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE MAY BE PRESENT NOTE • The equipment must be installed in accordance with IEC 60079-14 and local electrical codes.
  • Page 32 F16.ai *2: Surge Arrester may not be installed. b. Caution for IECEx Flameproof Certification Note 1. Model YFGW510 Field Wireless Access Point with optional code SF27 is applica- ble for use in hazardous locations. • Certification: IECEx DEK 15.0021 X •...
  • Page 33 • From the safety point of view, the intrinsically safe circuit of the Field Wireless Access Point model YFGW510 shall be assumed to be connected to earth. Note 3. Installation WARNING •...
  • Page 34 *2: Surge Arrester may not be installed. WARNING • AFTER DE-ENERGIZING, DELAY 1 MINUTE BEFORE OPENING • POTENTIAL ELECTROSTATIC CHARGING HAZARD (2) Electrical Connection • The type of electrical connection depends on the marking below on YFGW510. Marking The type of electrical connection Note M20 (ISO) M20 X 1.5...
  • Page 35 • The instrument modfication or parts replacement by other than authorized Representative of Yokogawa Electric Corporation is prohibited and will void the certification. When opening the cover, the enclosure must be dry and clean to prevent from ingress water or dust.
  • Page 36 Style code. SUPPLY: Specified supply voltage and wattage. NO.: Serial number and year of production YOKOGAWA TOKYO 180-8750 JAPAN: The manufacturer name and the address Production year and month are shown as yyyy.mm. For example, 2015.01 denotes January 2015. “180-8750” is a zip code which represents the following address.

  • Page 37: Ground Cable Connection

    For details of the connection, see C5.1 Power Supply Cable Connection of IM 01W02E01-01EN. 2) External grounding terminal To connect the grounding cable to YFGW510 directly, use the ground terminal on the right side of the housing. For details of the connection, see C5.2 Grounding Cable Connection of IM 01W02E01-01EN.

  • Page 38: How To Use Online Manual

    <Read Me First> How to Use Online Manual It is necessary to install Adobe Acrobat Reader to read the instruction manual (YFGW510 Field Wireless Access Point: IM 01W02E01-01EN). Install the following Adobe Reader by the administrator authority. • Adobe Reader 9.3 or later Adobe Reader can be downloaded from the Web site of Adobe Systems Incorporated.

  • Page 39: Copyright And Trademark Notices

    Trademark Acknowledgments • CENTUM, PRM, FieldMate, STARDOM and VigilantPlant are either trademarks or regis- tered trademarks of Yokogawa. • Microsoft, Windows, Windows Server, Windows Vista, Visual Basic, VisualC++, VisualC#, VisualStudio and Microsoft .NET Framework are either registered trademarks or trademarks of Microsoft Corporation in the United States and/or other countries.

  • Page 40: Open Source Software

    The following printed user’s manual is attached to YFGW510 hardware. • IM 01W02E01-11EN: YFGW510 Field Wireless Access Point Read Me First The following online user’s manual is stored in the attached DVD-ROM for YFGW510. • IM 01W02E01-01EN: YFGW510 Field Wireless Access Point...

  • Page 41: Information Of User's Manual Revision

    <Read Me First> Information of User’s Manual Revision Material Name: YFGW510 Field Wireless Access Point Read Me First Material Number: IM 01W02E01-11EN Edition Date Page Revised Item 1st Edition August 2012 New Issue 2nd Edition June 2013 Add ATEX Type n declaration...

  • Page 42: Yfgw510 Software License Agreement

    Yokogawa or licensors to Yokogawa. Ownership of and all the rights in the Software Product shall be retained by Yokogawa or the licensors and none of the rights will be transferred to you hereunder.
  • Page 43 Software Product is installed. 4.4 The above warranties shall not be applied to and Yokogawa shall not be liable for the defect or noncompliance which is subject to any of the following circumstances: a) the hardware on which the Software Product is installed has ceased to be covered by the warranty or maintenance contract of the hardware supplier;...
  • Page 44 Yokogawa out of court. The foregoing obligation and indemnity of Yokogawa shall be subject to that i) you promptly notify Yokogawa of the Claim in writing as provided above, ii) you grant to Yokogawa and its designees the full authority to control the defense and settlement of such Claim and iii) you give every and all necessary information and assistance to Yokogawa upon Yokogawa's request.
  • Page 45 10. Audit; Withholding 10.1 Yokogawa shall have the right to access and audit your facilities and any of your records, including data stored on computers, in relation to the use of the Software Product as may be reasonably necessary in Yokogawa's opinion to verify that the requirements of this Agree- ment are being met.
