Summary of Contents for Actia ComXS-320
-
Page 1: User Manual
User Manual ComXS-320 ACTIA I+ME GmbH Dresdenstrasse 17/18 38124 Braunschweig Germany Tel.: + 49 (0) 531 38701-0 Fax: + 49 (0) 531 38701-88 www.ime-actia.com User Manual ComXS-320 IR14618B User Manual ComXS-320 11.05.2017 Page 1/12... - Page 2 Reason for amendment 08.02.2017 Drafting of the document 07.03.2017 Minor corrections and updates 15.03.2017 Updated CE declaration 11.05.2017 Updated Antenna Information and RF exposure warning added © 2017 ACTIA I+ME GmbH. All rights reserved IR14618B User Manual ComXS-320 11.05.2017 Page 2/12...
-
Page 3: Table Of Contents
REGULATORY STATEMENTS................. 9 CE ....................... 9 FCC......................9 5.2.1............10 END PRODUCT LABELING INSTRUCTION IC ......................10 5.3.1................12 END PRODUCT LABELLING 5.3.2. É IC ..........12 TIQUETAGE DU PRODUIT FINAL CONFORME À IR14618B User Manual ComXS-320 11.05.2017 Page 3/12... -
Page 4: Scope Of This User Manual
COPE OF THIS ANUAL This User Manual contains all the information that is required to use the ComXS-320 module in the intended manner. It also provides information about usage and storage conditions, and gives an overview of the authorisations and certifications. -
Page 5: Safety Instructions
WLAN module, please contact ACTIA I+ME GmbH. Changes or modifications to the product not expressly approved by ACTIA I+ME GmbH will void the user's authority to operate the equipment. Any changes or modifications NOT explicitly APPROVED by ACTIA... -
Page 6: General Product Description
RODUCT ESCRIPTION EATURES The embedded WLAN DUALBAND CPU MODULE ComXS-320 enables powerful mobile WLAN applications in the consumer and industrial area. It adds powerful networking capability to all compatible products, including but not limited WLAN 802.11 a/b/g/n, 2x2 MIMO, up to 300Mbit USB 2.0 HighSpeed, device mode... -
Page 7: Characteristics
Connector: Industrial temperature grade (Operating: -40°C to 85°C, Temperature: Storage: -40°C to 85°C) Dimension: 41.50mm x 50.95mm x 4.7mm Mounting Hole: 2 x 2.60 mm ROHS Compliance FCC-ID: XB7-COMXS320 Regulatory IDs IC-ID: 7474A-COMXS320 IR14618B User Manual ComXS-320 11.05.2017 Page 7/12... -
Page 8: Antenna Information
End-users and installers must be provide with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. IR14618B User Manual ComXS-320 11.05.2017 Page 8/12... -
Page 9: Regulatory Statements
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: IR14618B User Manual ComXS-320 11.05.2017 Page 9/12... -
Page 10: Fcc End Product Labeling Instruction
FCC-ID and/or this statement, the FCC-ID and the statement shall be also included in the end-product manual. For an end product using the ComXS-320 there must be a label containing, at least, the following information. - Page 11 à une utilisation en intérieur pour réduire le risque d'interférences nuisibles à la co-canal systèmes mobiles par satellite, le gain d'antenne maximal autorisé pour les appareils dans les bandes 5250-5350 MHz et 5470-5725 MHz doit se IR14618B User Manual ComXS-320 11.05.2017 Page 11/12...
-
Page 12: Ic End Product Labelling
1. this device may not cause interference, and 2. this device must accept any interference, including interference that may cause undesired operation of the device. For an end product using the ComXS-320 there must be a label containing, at least, the following information. This device contains IC: 7474A-COMXS320 5.3.2.
