Alpinter S 5088015 Assembly Instructions Manual

MUlti PURPOsE 42 m
Meeting / School / Warehouse
A 22 x PIPE - (171 cm)
B 15 x FOOT POLE (one spare)
C 6 x PIPE - (47 cm)
D 16 x CROSS PIECE
(one spare)
E 8 x BOTTOM PIPE - (171,5 cm)
L 2 x GABBLE (FRONT & REAR)
BOX B
OPTION : INNER LINER W/O GROUNDSHEET - SHADE NET - INNER CABIN - LIGHTNING KIT
ASSEMBLY
INSTRUCTIONS
2
BOX a
F 4 x BOTTOM GABLE PIPE - (221 cm)
I 4 x DOOR ARCH CONNEXION
X 20 x PEG - (± 40 cm)
M 1 x ROOF - (6 x 7 m)
N 2 x SIDE WALL - (7 m)
O 1 x GROUND SHEET 42 m
tent
S 5088015 - UN 271 62 581
www.alpinter.com/downloads.html

Packing list

1 x HAMMER
UN 271 62 580

Needed to assemble this tent :

2
