A380 Quick Start Manual
1. Features and main functions:
Games: Play games in 8 bit/16bit/32bit. Simulate PS/MAME/games, support thousands
of GBA\SFC\ FC\NES \MD\ NEOGEO\CPS1\CPS2 \GBC\ SMS\GG games.
Wireless: With 2.4GHz wireless receiver module built‐in, equipped with specialized
2.4GHz wireless game controller (F‐16 controller). Support two wireless controllers.
Support 2‐player gaming wirelessly.
G‐sensor: Gravity sensing effect while playing flying and car games.
Display: TFT 3.2" WQVGA LCD(16:10), resolution 400X240.
AV‐out : AV‐out technology gives you DVD output quality. Console can be connected
with TV thus you can either enjoy playing games or watching movies.
Video player: Support RMVB, RM, AVI, WMV, FLV, MPEG, DAT, MP4, ASF formats.
MP3 player: Supports MP3, WMA, APE, FLAC, M4a audio format. Synchronous lyrics
display function, multiple EQ options,3D virtual sound field, surround sound effect and
play mode options.
FM radio: User Can save up to 40 channels.
Audio Recorder: Hi‐Fi voice recording. Support MP3, WAV formats.
Image Browser: Image browsing formats includes JPG, BMP GIF, PNG, with zoom, rotate
and image slide show function.
E‐book: Txt, html, doc, rtf formats supported. Further functions include bookmark, auto
browsing, font sizing, TTS oral reading.
Applet: Calculator, stopwatch,.
USB2.0 Transmission Interface: Support WIN2000/XP/VISTA/MAC/WINDOWS7 Operation
System.
Capacity: 4GB internal memory, support insert Micro SD(TF) card to expand capacity(up to
32GB).
2. Location of buttons and functions:
Side buttons:
1
Advertisement
Summary of Contents for DINGOO DIGITAL A380
- Page 1 A380 Quick Start Manual 1. Features and main functions: Games: Play games in 8 bit/16bit/32bit. Simulate PS/MAME/games, support thousands of GBA\SFC\ FC\NES \MD\ NEOGEO\CPS1\CPS2 \GBC\ SMS\GG games. Wireless: With 2.4GHz wireless receiver module built‐in, equipped with specialized 2.4GHz wireless game controller (F‐16 controller). Support two wireless controllers. Support 2‐player gaming wirelessly. ...
- Page 2 3. Function operation Push the power switch button to pause a few seconds to open up the player display after the boot screen, enter the main menu interface. Press [LEFT] / [RIGHT] keys to choose “Game rooms”, “Music”, “Video”, “ Radio”, “Record”, “Applet”, “Picture”, “Recorder”, “Browser .Then press [A] key to enter the selected menu interface, as shown "game rooms" menu interface for example. ...
- Page 3 current state of progress of each game can be saved at any time. Loading game progress: in the game menu, select "Instant read file" option. You can restore saved game state. Voice switch: in the game options ,you can choose open or close the current game sound. Game action: AB game keys corresponding to keys, four navigation keys correspond to up, down, left and right. Exit: In the Game menu, choose "Exit Game" option to exit the game. Note: Open some large game time may be slightly longer, please to be patient. 2‐player mode: Only some CPS1、 CPS2、 NEOGEO、 MD games support 2‐player mode. Two players chosen the same simulation game, then press [A] button and will appear a picture like below. If you choose “single mode” then just allow 1 player to play. If choose “ Creating a server” or “search server”, then 2 players can play at the same time. One ...
- Page 4 Another player use another console to search the sever( this console is subordinate console). Press [A] button then appear below picture. If the subordinate console searched a sever, it shows as “Online Success”. For the master console, it shows: “Players to join, press A button to start” then both of them press [A] to enter the game and both players choose 2 player mode to play the game. Note: 1, The creating server is mater server which can control the process and quit and game. 2, The most far distance is 5M in an open field. Not allowed person or thing to obstruct, otherwise the game will be locked. If locked, you should hold on for several seconds then can continue to play. ...
- Page 5 When video is playing, press [B] to exit and back to the play list. When video is playing, press [A] to adjust the proportion. There are normal, full screen and adapted screen 3 options. Press [A] to open or close the “Continue” function. Press [B] to quit. When quit, the console will save the changing. 6. Radio When you listen to radio, need to wear the earphone. Thus the earphone is equal to an antenna. Select " Listen radio" option. If you want to listen to the radio listed in the list, press [LEFT] or [RIGHT] ...
- Page 6 In the main interface, choose Ebook, press [A] to enter to the related TXT reader, RTF reader, HTML reader or DOC reader. When reading E‐book, press [UP] or [DOWN] button to switch previous or next page, press [LEFT] or [RIGHT] button to switch up or down line. Press [A] to pop up the set up menu(Go to, bookmark, zoom, color, TTS voice, Auto browse), press [B] to return to the previously menu. In ...
- Page 7 Backlight settings Select “System” option, choose “Backlight settings”, press [A] to enter the options(lever 1‐5), press [UP] or [DOWN] to choose the option, then press [A] to save. G‐sensor set Select “System” option , choose “G‐sensor set”, press [A] to open. After that, there will be a label on the right top of the screen. Then move left and right and you can enjoy gravity sensing in the car, flying games. ...
- Page 8 How to use a TF card. TF card will be inserted according to the player's card slot. If you want to unplug the TF card first ensure that the players currently on the card is not operating. Gently press your card, it will pop up automatically. If not pop up automatically, there is a slot as shown in below picture, you can remove it by hand. You can format your TF card when the console is connecting with PC. Please ensure that the file format is FAT32 format, since the system is fully compatible with FAT32 file format. Note: In order to avoid data missing, please insert or remove TF card when the console is power off. ...
- Page 9 FCC Statements: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ...
