Horizontal Meter

6.1.2
The horizontal meters show greater detail for two pairs of channels on the Aurora
indicators make this a useful tool for calibration and troubleshooting.
Press the Select button to choose which sources drive both sets of meters:
All I/O Meter on an Aurora
All I/O Meter on an Aurora
All I/O Meter on an Aurora
Pressing the Select button changes the All I/O Meter
to the Digital I/O (if available).
Pressing Select again switches to
Thunderbolt/USB/Dante/HD.
20
(n)
with 16 analog i/o.
(n)
with 24 analog i/o.
(n)
with 32 analog i/o.
(n)
. Level markers and clip
