K3C

AC 1900 Smart Wi-Fi Router

Quick Installation Guide

Table of Contents

Need help?

Do you have a question about the AC 1900 and is the answer not in the manual?

Questions and answers

Summary of Contents for K3C AC 1900

Page 1 AC 1900 Smart Wi-Fi Router Quick Installation Guide...
Page 2: A Quick Look
A quick look Power button Press to power on/off the router. USB 3.0 port Insert USB devices as external storage. WAN port Insert a RJ-45 cable to establish Internet connection. LAN ports 1-3 Insert RJ-45 cables to establish LAN connection. Power port Insert AC adapter connector for power supply.
Page 3: Connecting The Devices
Connecting the devices Connect the power adapter into an electrical outlet, connect the other end to the router, and turn on the router. Connect your modem to the WAN port on the router using a RJ-45 cable.  Make sure your modem has proper Internet connection.
Page 4 complete the router setup. Connect your computer to the LAN port on your router with a RJ-45 cable. If you are using a wireless device, turn on WLAN and connect to @PHICOMM_XX or @PHICOMM_XX_5G (XX represents the last two digits of the router's MAC address).
Page 5: Led Diagnostics
LED Diagnostics You can use the LED indicator located at the bottom edge of the front panel to diagnose the connectivity status of your router. LED behavior WLAN Internet Solid √ √ √ Blue Blinking √ √ × Solid √ ×...
Page 6 Configuring router via web browser 1. On your web browser, enter p.to or 192.168.2.1 and click Start Setup to run the setup wizard. 2. Create a password for your router and click Next. 3. Select your time zone and click Next.
Page 7 4. Specify your Internet connection type, enter the relevant account information as required and click Next. Contact your Internet Service Provider (ISP) if you are not sure about this step. 5. Set SSID and password for your wireless network or use the default settings.
Page 9 Configuring router via PhiWiFi To manage your home network with your smartphone, scan the barcode below to download the PhiWiFi app from Apple App Store or Google Play.
Page 10: Ce Mark Warning
CE Mark Warning This is a class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. Operating Frequency 2.4G: 2402 - 2482 MHz / 5G: 5150 - 5250 MHz Maximum Transmit Power 2.4G: 20 dBm / 5G: 23 dBm This device may be operated in all EU countries (and other countries...
Page 11: Safety Precautions For Power Supply Unit
applications. Neither will Phicomm (Shanghai) Co., Ltd. provide support to customers who use these third-party software and applications nor be responsible or liable for the functions of these third-party software and applications. Third-party software and application services may be interrupted or terminated at any time. Phicomm (Shanghai) Co., Ltd. does not guarantee that any content or service would be maintained for any period during its availability.
Page 12: Safety Precautions For Direct Sunlight
This product can only be connected to the power adapter provided by Phicomm (Shanghai) Co., Ltd. Phicomm (Shanghai) Co., Ltd. is not liable for any device breakdown or safety accident arising from unauthorized power source. SAFETY PRECAUTIONS FOR DIRECT SUNLIGHT Keep this product away from excessive moisture and extreme temperatures.
Page 13: Interference With Medical Equipment Functions
as microwave ovens, sound speakers, TV and radio. Use only original manufacturer-approved accessories.  Use of non-original manufacturer-approved accessories may  violate your local RF exposure guidelines and should be avoided. INTERFERENCE WITH MEDICAL EQUIPMENT FUNCTIONS This product may cause medical equipment to malfunction. The use of this device is forbidden in most hospitals and medical clinics.
Page 14: Mounting Accessories
HEED SERVICE MARKING Except as explained in the user manual, do not repair any product yourself. Service needed on components inside the device should be done by an authorized service outlet or provider. Phicomm (Shanghai) Co., Ltd. is entitled to use new or reconditioned replacements parts or boards for repairs under warranty, provided they have the same functionality as the parts to be replaced.
Page 15 Hereby, Phicomm (Shanghai) Co., Ltd. declares that the radio equipment type K3C is in compliance with the RED Directive 2014/53/EU. The full of the EU declaration of conformity is available at the following internet address: www.phicomm.de...
