GSM TELEPHONE
GSM TELEPHONE
GT-E2652W(GT-E2652 Common)
3. Product Function
9. Reference data
Notice :
All functionality, features, specifications and other
product information provided in this document inclu
ding, but not limited to, the benefits, design, pricing,
components, performance, availability, and capabiliti
- es of the product are subject to change without
notice or obligation. Samsung reserves the right to
make changes to this document and the product
described herein, at anytime, without obligation on
Samsung to provide notification of such change.
CONTENTS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT-E2652W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung GT-E2652W

Summary of Contents for Samsung GT-E2652W

  • Page 1: Table Of Contents

    - es of the product are subject to change without notice or obligation. Samsung reserves the right to make changes to this document and the product described herein, at anytime, without obligation on...

  • Page 2: Safety Precautions

    ― Don't use as you pleases after change other material than replacement registered on SEC System. Otherwise engineer in charge isn't charged with problem that you don't keep this rules. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 3 ― You must maintain electric contact between ESD and place due to be set up until ESD is connected completely to the proper place or a circuit board. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 4: Specification

    2. Specification 2-1. GSM General Specification G SM 90 0 DCS1800 PCS190 0 Ph ase 1 Ph ase 1 Fr eq. 8 80~915 17 10~178 5 18 50~191 0 Ba nd[MHz] 9 25~960 18 05~188 0 19 30~199 0 Up link/ Do wnl ink ARFCN ran ge 0~1 24 &...

  • Page 5: Gsm Tx Power Class

    Speclflcation 2-2. GSM Tx Power Class TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 33±3 dBm 30±3 dBm 30±3 dBm 31±3 dBm 28±3 dBm 28±3 dBm 29±3 dBm 26±3 dBm 26±3 dBm 24±3 dBm 27±3 dBm 24±3 dBm 25±3 dBm...
  • Page 6 Speclflcation 2-3. GSM EDGE TX power class Only in Master TX Power TX Power TX Power GSM900 DCS1800 PCS1900 control level control level control level 27±3 dBm 26±3 dBm 26±3 dBm 25±3 dBm 24±3 dBm 24±3 dBm 23±3 dBm 22±3 dBm 22±3 dBm 20±3 dBm 20±3 dBm...

  • Page 7: Operation Instruction And Installation

    • FM Radio • Bluetooth v2.1 + EDR • WIFI • 2.6'' QVGA 262k LCD • 1.3M CMOS Camera • MP3 Player • 3.5mm EAR-JACK SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 8: Exploded View And Parts List

    4-1. Cellular phone Exploded View QME03 QKP01 QFR01 QLC01 QMP01 QCR72 QAR01 QMO01 QME01 QCA01 QSP01 QBR05 QSM01 QCK01 QVO01 QCK02 QRF06 QRE01 QCR03 QST01 QBA01 QBC00 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 9: Cellular Phone Parts List

    QST01 ASSY STYLUS PEN GH98-19114A QRE01 ASSY CASE-REAR GH98-19020A QRF06 PMO COVER-USB GH72-62435A QCK02 PMO KEY-HOLD GH72-62437A QVO01 PMO KEY-VOLUME GH72-62438A QCK01 PMO KEY-HOT GH72-62439A SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 10: Main Electrical Parts List

    U304 1203-005244 U302 1203-005580 U307 1203-005855 U300 1203-006604 U305 1205-003517 U102 1205-003931 U500 1205-003998 U502 1205-004030 UCP200 1205-004076 U101 1404-001224 TH200 THERMISTOR 1405-001298 C502,C503,C504,C505 VARISTOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 11 2007-007001 R308 R-CHIP 2007-007015 2007-007136 R503,R504,R516 R-CHIP R206 R-CHIP 2007-007142 R311,R320 R-CHIP 2007-007798 2007-007875 R315 R-CHIP R306 R-CHIP 2007-008780 R525,R526 R-CHIP 2007-009315 2007-009794 R111 R-CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 12 2203-005395 C221 C-CERAMIC,CHIP 2203-005480 2203-005481 C158,C203,C219 C-CERAMIC,CHIP C228,C229 C-CERAMIC,CHIP 2203-005483 C401 C-CERAMIC,CHIP 2203-005682 2203-006048 C145,C200,C201,C205 C-CERAMIC,CHIP C209,C213,C218,C225 C-CERAMIC,CHIP 2203-006048 C234,C237,C310,C400 C-CERAMIC,CHIP 2203-006048 2203-006048 C408,C409,C418,C501 C-CERAMIC,CHIP SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 13 2203-007693 C106,C300,C423,C602 C-TA,CHIP 2404-001381 2409-001172 BAT200 CAPACITOR L123 INDUCTOR-SMD 2703-000213 L104 INDUCTOR-SMD 2703-001180 2703-001723 L112 INDUCTOR-SMD L105 INDUCTOR-SMD 2703-001729 L190 INDUCTOR-SMD 2703-001747 2703-001752 L100 INDUCTOR-SMD SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 14 3711-005456 BTC600 CONNECTOR-HEADER 3711-007393 3711-007446 HDC601 CONNECTOR-HEADER HEA500 CONNECTOR-HEADER 3711-007478 ANT100,ANT101 CONNECTOR 3712-001348 3722-003115 IFC400 JACK-PHONE EAR400 JACK-PHONE 3722-003197 F105 RF-MODULE 4709-001615 4709-001905 F103 RF-MODULE SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 15 SC100,SC101,SC102 ONBOARD-CLIP-9 GH70-04443A SC103,SC104,SC105 ONBOARD-CLIP-9 GH80-03320A R211 PB-SHORT-1005 Please consult the GSPN website (Samsung Portal) for the most recent version of the product's part list. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 16: Level 1 Repair

    • JIG Cable (GH39-01339A) • Adapter (GH99-38251A) • Serial Cable • Binary files ※ Settings Connect to ANYWAY JIG BOX & JIG CABLE (Phone to JIG) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 17 ■ Load the binary download program by executing the " Flash tool_E2 " ← enter this file. 1. Select the connected serial port and the rate of speed. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 18 Level 1 Repair 2. Select communication driver as Infineon USB driver. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 19 Level 1 Repair 3. Select the Binary in sequence of _bin, _cds, .dffs. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 20 Level 1 Repair 4. Press the "Start" button. 5. Press Start USB1 and connect the Handset. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 21 Level 1 Repair 6. When downloading is complete, you can see green bar. 7. Confirm the downloaded version name and etc. : *#1234# Full Reset : *2767*3855# SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 22: Level 2 Repair

    1) Be care of scratch and molding damage. 1) Be care of scratch and molding damage. 2) Be care of the LCD & TSP FPCB damage. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 23 CAMERA MODULE from the PBA ASS'Y. （ Caution （ Caution 1) Be care of scratch and PBA damage. 1) Be care of CAMERA SOCKET damage & CAMERA MODUL E scratch. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 24 PBA. 1) Separate the RECEIVER FPCB & the MOTOR From PBA. （ Caution 1) Be care of the RECEIVER FPCB and the MOTOR wire damage. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 25 1) Be care of scratch and PBA damage. （ Caution 1) Be care of damage to INTENNA PATTERN and PBA. 2) Torque : 1.0 ~ 1.2 Kgf·cm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 26 1) Assemble the LCD CONNECTOR. （ Caution （ Caution 1) Be care of scratch and molding damage 1) Be care of damage to the LCD MODULE. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 27 1) Screw 6 points. 1) Screw 6 points. （ Caution 1) Be care of scratch and molding damage. 2) Torque : 1.0 ~ 1.2 Kgf·cm SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 28: Level 3 Repair

    FM_LNA_OUT FM_ANT RCV_N FM LNA 3.5 PI EARJACK EAR_S W EAR_KE Y EARKE Y EAR_KEY_D IRECT 3.5_DETECT EAR_MIC_P EAR_MIC_N MIC_BB_P MIC_BB_N MIC_RCV_P MIC_SPK_P MIC_RCV_N MIC_SPK_N SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 29 R208 G502 C219 CN200 C315 C204 C203 L300 C220 R206 L118 L112 L116 L110 F104 F102 C509 R305 C610 C602 L100 RFS100 G508 G500 G505 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 30 Level 3 Repair 8-2-2. Bottom D301 ZD402 MIC_400 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 31 ※ presetting methods for checking TP - GND & TP(exp. VBAT= C602, C603, C604 ) using Oscilloscope - look over the coming out signal. ← Oscilloscope SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 32 - EX) to look up the TP, shunt Cap. - if checking the GND, you can listen "beep" if checking the Signal, you can't listen it. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 33 Check the Clock at (to lookover the Chip damage) UCP200 A11pin (CLK26M)=26MHZ (TP : OSC201 1,3pin / look over the (TP:OSC201 1,3pin) waverform using the oscilloscope) SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 34 FMRIN FMRINX C227 CLK26M_BT_BB FSYS1 FSYS2 FSYS_EN BT_CLK_REQ EAR_L_AMP OSC201 EAR_R_AMP VDD_1.8V L201 ONOFF ONKEY SD1SW SD1_FB C230 L100 ADV_N ADVn RST_BB_J TRSTn RST_BB WAITn SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 35 8-3-2. Initial Initial Failure TP:RST_BB > 1.7V? Check the circuit related to reset using the oscilloscope GND & SHORT PAD. Check the 16bit data signals. SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 36 CS0n_NOR _CER _OER _WER RST_BB _RESETR TP_CS1n_RAM CS1n_RAM C225 R311 R309 R310 C606 TP_CS1n_RAM C213 C607 C212 C511 C510 UME200 C512 TP_MEM_CLK TP_ADVn MEM_INT TP_CS0n_NOR SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 37: Charging Part

    Resolder R304 R304 > 4.9V ? (be possible that it's not soldering well) Check the Q301 pin4 Replace Q301 using a Heatgun >4.9V ? 8-10 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 38 R301 R303 R304 VBAT VCHG R307 Q301 R306 R414 C418 C420 C421 R413 C415 ZD405 C416 Q300 R301 R303 C417 R405 R307 R304 SC104 8-11 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 39 (Because of not soldering well) (method : wiring pin 3 and checking its waveform using an oscilloscope) Check the SIM Card (look over if it get damaged.) 8-12 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 40 Level 3 Repair VSIM1_3.0V R512 SIM1_IO SIM500 R519 SIM1_RST C506 C507 C508 C509 SIM1_CLK C509 C610 C602 8-13 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 41 (Because of not soldering well) (method : wiring pin 3 and checking its waveform using an oscilloscope) Check the SIM Card (look over if it get damaged.) 8-14 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 42 17 17 SIM2_IO SD_DATA(1) 19 19 20 20 R602 C609 ZD601 C605 C606 C607 C608 R602 ZD601 C501 C606 R530 C607 C511 C510 UME200 C512 8-15 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 43 (not work if those is not connected.) Check the MAIN MIC sample. Replace an another MAIN MIC (it be possible the problem things) (because of being possible the problem) 8-16 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 44 V_MIC_2.2V R400 C400 MIC_SPK_N MIC_BB_N MIC_SPK_P MIC_BB_P MIC_RCV_N MIC_SEL MIC_RCV_P V_MIC_2.2V MIC_400 POWER POWER GND1 MIC_RCV_N GND2 L402 R402 MIC_RCV_P SHORT C401 ZD400 ZD401 8-17 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 45 (not work if those is not connected.) Check the SPK MIC sample. Replace an another SPK MIC (it be possible the problem things) (because of being possible the problem) 8-18 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 46 PCM_SYNC I2S1_WA0 PCM_CLK I2S1_CLK0 V_MIC_2.2V R400 C400 MIC_SPK_N MIC_BB_N MIC_SPK_P MIC_BB_P MIC_RCV_N MIC_SEL MIC_RCV_P V_MIC_2.2V MIC_401 R401 MIC_SPK_P SHORT MIC_SPK_N C402 C403 C404 ZD402 8-19 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 47: Speaker Part

    Voice Call ringtone) Change Speaker Is Speaker working? (be possible of SPK Problems (Listening through the or not inserting it right.) speaker) 8-20 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 48 Level 3 Repair L502 L500 SPK500 SPK_P L503 L501 SPK_N C513 C514 L118 L112 L116 L110 F104 F102 R305 L100 8-21 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 49: Key Data Input

    (be possible of soldering not well or being UCP a bad sample) All of the key doesn't work Replace the U502 except POWER ON KEY ? 8-22 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 50 C517 ZD601 C501 C606 TP_CS1n_RAM R530 C213 C607 C212 C511 C510 UME200 C512 TP_MEM_CLK TP_SIM_RST TP_SIM_CLK TP_SIM_IO TP_ADVn TOUCH_RST C517 MEM_INT U502 R521 TP_CS0n_NOR 8-23 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 51 Is R319 = 1.8V ? (with an soldering iron) (Wiring U305 pin4, #2 : Repalce LCD Module EN_LCD_BL) (to check if it has the problem) 8-24 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 52 D302 VBAT L300 U305 LED+_12V VOUT EN_LCD_BL LED- C315 R320 R319 C314 C200 C217 R207 R208 C219 CN200 C315 C204 C203 L300 C220 R206 8-25 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 53 (Click the Touch Screen) (be possible that the sample has the problem) #2 : Replace the HEA500 (be possible that the sample has the problem) 8-26 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 54 TOUCH_INT TOUCH_RST TOUCH_RST NRST TOUCH_SCL TOUCH_SDA TSP_X+ TSP_X- TSP_Y+ TSP_Y- ZD500 HEA500 TSP_Y- TSP_X- TSP_X+ TSP_Y+ 10 10 NC NC NC NC 12 13 8-27 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 55 2. Connetion Type : select Auto(GSM), BLER(GPRS) 3. BCH Parameter : select measuring band (DCS or EGSM) 4. Cell power : -60dBm (Tx setting) 8-28 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 56 1. After setting, prepare the call setup Display 2. Using an Originate Call, make a call. 3. Confirm the display "connected" 4. start the measuring 8-29 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 57 - spectrum analyzer : testing method = the way using an Osciliscope - 8960 : connect using RF Cable between 8960 & RF Connector in board. 8-30 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 58: Gsm850 Receiver

    -68dBm Check ANT Switch pin20=L, pin19=H (TP:C136 using control circuit specturm analyzer) Resolder PAM100 TCXO CLOCK CHECK? Resolder OSC201 26MHz @ OSC201 Check UCP200 8-31 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 59: Gsm900 Receiver

    -68dBm Check ANT Switch pin20=L, pin19=H (TP:C191 using control circuit specturm analyzer) Resolder PAM100 TCXO CLOCK CHECK? Resolder OSC201 26MHz @ OSC201 Check UCP200 8-32 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 60: Dcs Receiver

    -68dBm Check ANT Switch pin20=L, pin19=H (TP:C131 using control circuit specturm analyzer) Resolder PAM100 TCXO CLOCK CHECK? Resolder OSC201 26MHz @ OSC201 Check UCP200 8-33 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...

  • Page 61: Pcs Receiver

    -68dBm Check ANT Switch pin20=L, pin19=H (TP:C129 using control circuit specturm analyzer) Resolder PAM100 TCXO CLOCK CHECK? Resolder OSC201 26MHz @ OSC201 Check UCP200 8-34 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 62 C217 R207 R208 C219 CN200 C315 C204 C203 L300 C220 R206 L118 L112 L116 L110 F104 F102 C509 R305 C610 C602 L100 RFS100 G508 8-35 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 63 C116 < 3.3V? circuit. PAM100 Pin14 ≥ 30dBm Resolder PAM100 (TP:L105 using spectrum analyzer) Check the RFS100 Resolder RFS100. connection with PCB? Antenna re-solder or change 8-36 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 64 C116 < 3.3V? circuit. PAM100 Pin14 ≥ 30dBm Resolder PAM100 (TP:L105 using spectrum analyzer) Check the RFS100 Resolder RFS100. connection with PCB? Antenna re-solder or change 8-37 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 65 C217 R207 R208 C219 CN200 C315 C204 C203 L300 C220 R206 L118 L112 L116 L110 F104 F102 C509 R305 C610 C602 L100 RFS100 G508 8-38 SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 66 ― QPSK: Quadrature Phase Shift Keying ― RS : Reed-Solomon ― SI : Service Information ― TDM : Time Division Multiplexing ― TS : Transport Stream SAMSUNG Proprietary-Contents may change without notice This Document can not be used without Samsung's authorization...
  • Page 67 SAMSUNG CONFIDENTIAL THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS SAMSUNG ELECTRONICS CO’S PROPERTY. DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG. Service Schematic RFS100 VDD_IO1_1.8V ANT100 ANT101 C100 C101 VBAT R102 C102 C103 C190...
  • Page 68 PROPRIETARY INFORMATION THAT IS VDD_NEG_1.3V VDD_IO1_1.8V VDD_IO1_1.8V VDD_1.8V VBAT V_MIC_2.2V VSIM_2.85V VUSB_3.1V SAMSUNG ELECTRONICS CO’S PROPERTY. VDD_TRX_1.4V DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG. Service Schematics VDD_TDC_1.3V C202 C203 C204 C205 C200 C201 VDD_IO2_1.8V VDD_1.8V VDD_RF2_2.5V VDD_NEG_1.3V...
  • Page 69 SAMSUNG CONFIDENTIAL THIS DOCUMENT CONTAINS CONFIDENTIAL PROPRIETARY INFORMATION THAT IS Service Schematics SAMSUNG ELECTRONICS CO’S PROPERTY. Q300 DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG. VBUS_5V_OUT VDD_IO1_1.8V VSHNT VBAT_IF VBAT_IF VBAT VDDCHG R301 R302 R300...
  • Page 70 SAMSUNG CONFIDENTIAL THIS DOCUMENT CONTAINS CONFIDENTIAL V_MIC_2.2V PROPRIETARY INFORMATION THAT IS Service Schematics SAMSUNG ELECTRONICS CO’S PROPERTY. DO NOT DISCLOSE TO OR DUPLICATE FOR OTHERS EXCEPT AS AUTHORIZED BY SAMSUNG. R400 C400 MIC_SPK_N V_MIC_2.2V V_MIC_2.2V MIC_BB_N MIC_SPK_P MIC_BB_P MIC_RCV_N MIC_SEL...
  • Page 71 Service Schematics VTOUCH_1.8V VTOUCH_1.8V VDD_IO1_1.8V C500 R501 R502 R500 U500 C501 VDD_IO1_1.8V NIRQ TOUCH_INT TOUCH_RST NRST TOUCH_RST DSDS_SCL TOUCH_SCL VSIM1_3.0V TOUCH_SDA DSDS_SDA TSP_X+ VSIM_2.85V TSP_X- R530 R512 TSP_Y+ TSP_Y- R532 TP_SIM_IO SHORT SIM_IO SIM1_IO R531 TP_SIM_CLK ZD500 RST_BB RESETX SIM_CLK SIM500 TP_SIM_RST SIM_RST...
  • Page 72 Service Schematics VCAM_A_2.8V VCAM_IO_1.8V VCAM_CORE_1.5V VDD_IO1_1.8V SOC600 VDD_2.9V CAM_SDA HDC601 CAM_SCL CAM_RST R600 CAM_MCLK_OUT SHORT LCD_D1(7) TP_FLM LED+_12V LCD_D1(6) LCD_D1(5) CAM(5) 10 10 LED- LCD_D1(4) CAM(6) C600 LCD_RST_O LCD_D1(3) 13 13 14 14 LCD_D1(2) CAM(4) LCD_D1(1) 17 17 18 18 LCD_D1(0) CAM(7) LCD_WR_O...
