Heckler AV
Assembly & Installation
Watch Assembly Video
tinyurl.com/HecklerAVCart
Limited Warranty
Heckler Design warrants your product hardware to be free from defects in material and workmanship
throughout the life of the product, and electronic components for a period of one year from the original
date of purchase. If you discover a defect in a product covered by this warranty, we will repair at our
option using new or refurbished components, or if repair is not possible, replace the item. We reserve the
right to request order numbers, receipts, and other supplemental order information as proof of purchase
to validate warranty claims.
H489 R03
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Heckler Design H489
-
Page 1: Limited Warranty
Assembly & Installation Limited Warranty Heckler Design warrants your product hardware to be free from defects in material and workmanship throughout the life of the product, and electronic components for a period of one year from the original date of purchase. If you discover a defect in a product covered by this warranty, we will repair at our Watch Assembly Video option using new or refurbished components, or if repair is not possible, replace the item. - Page 2 Vertical Arm & Rear Leg Assembly Screw (2 3/4 inch) F515 Multi Shelf Installation Screw F522 Zip Tie Anchor Installation Screw F533 3/8” Inch Hex Key-AV Cart F516 5mm Hex Key-MultiShelf Installation Tool Keep your special assembly tool in a safe place. To purchase a replacement, please contact service@hecklerdesign.com.
- Page 3 M8 Display Mounting Hardware F521 M6 TV Set Screw F589 Zip Tie Mount - Leg F532 Zip Tie Mount - Vertical Arm F531 Zip Tie F530...
- Page 4 Front Braking Casters (not to scale) F562 Rear Non - Braking Casters (not to scale) F563 Phillips Head Screwdriver VESA 400 hole pattern display required MAX display size: 75 inches MAX load weight: 250 pounds Two-Person assembly Do not overtighten display mounting screws...
- Page 5 1 Unpack large parts onto soft surface 2 Assemble legs to base F515 F516...
- Page 6 3 Pop the wheels out of casters F562 F563 4 Install casters F562 F563...
- Page 7 5 Pop the wheels back Assemble vertical arms to base F515 F516 Do not tighten arm assembly screws.
- Page 9 7 Install Multi Shelves F522 F523...
- Page 10 8 Tighten the arm assembly screws F522 F523...
- Page 11 9 Select correct display-mounting screws M6 Display Mounting Hardware 1. Transfer rubber spacers from 2. Slide rubber spacers on to the the M8 set screws. M6 set screws.
- Page 12 11 Install display mounting hardware...
- Page 13 8 Install display to vertical arms...
- Page 14 9 Install zip tie mounts in legs and vertical arms F533 F532 F531...
- Page 15 10 Place Zip Ties F530...
- Page 16 11 Route cables...
