RFID Reader User's Guide
Version
V11.11
Author
R & D Dept.
This User's Guide is for salesperson, installing and technical support person of RFID Reader, in order to
make them understand the installing and testing of our readers clearly. Before operating the reader,
please read the guide carefully.

Advertisement

Table of Contents
loading

Summary of Contents for MAXTEK Q-1000

  • Page 1 RFID Reader User’s Guide Version V11.11 Author R & D Dept. This User’s Guide is for salesperson, installing and technical support person of RFID Reader, in order to make them understand the installing and testing of our readers clearly. Before operating the reader, please read the guide carefully.

  • Page 2: Table Of Contents

    CATALOG BRIEF INTRODUCTION ..........................2 .......................... 2 RODUCT ERFORMANCE INSTALLATION & CONNECTION ......................3 & P ......................3 NSTALLATION OWER UPPLY PC & C ......................3 ONNECT TO ONTROLLER WORKING MODE ............................4 ..........................4 ASTER LAVE ........................4 RIGGER UTOMATIC COMMUNICATION PORT ..........................

  • Page 3: Brief Introduction

    Brief Introduction RFID Reader is one of our developed RFID Readers for UHF Electronic Tags. It supports ISO18000-6B and EPC Class1 Gen2 protocol so that to read and write the relative tags. With perfect performance and easy operation, it can be integrated in many applications listed below: Application Examples Description...

  • Page 4: Installation & Connection

    Installation & Connection The reader must be installed and connected correctly before operating. First you should connect power supply and antenna before connecting PC or controller. Installation & Power Supply The reader can be simply installed. Please adjust the fixture to a suitable angle according to your application.

  • Page 5: Working Mode

    Working Mode The reader can identify working modes automatically and make corresponding response. Master-Slave Mode Under Master-Slave working mode, readers must be controlled by host machine (PC or controller). It receives the command from host, executing read/write actions on tags, and responsing the data to the host.

  • Page 6: Communication Port

    Communication Port The reader has kinds of communication ports. It can communicate with PC or controller that has standard RS232,RS485 or Wiegand port. The communication ports of the reader include: Port Name Port Type Port Qty. Application TRIGGER 1 Pcs Connect Reader to outer Relay RS-485 A+,B-...

  • Page 7: Connect To Pc

    Connect to PC The reader can be connected to PC by RS232 or LAN. RS232 The reader has a DB9 RS232 port which is usually connected to PC for communication. Directly connect RS232 of reader to the COM port of PC with DB9 Female cable. The inner connecting relationship is illustrated below: Connect to Controller The reader can be connected to controller by RS485 or WIEGAND.
  • Page 8 GPIO Note: By default we do not give GPIO, user may ask us to customize them if needed. In GPIO connection, you should connect GPO(Output) and GPI(Input) to the outer equipment. The GPO could be connected to outer equipment(eg. Relay) to drive the barrier or light.

  • Page 9: Faq

    The frequent asked questions and the resolutions are listed below: Failure Possible Reason Solution Tag unreadable Tag is too far from antenna Move the tag close to antenna Tag direction does not match the antenna Please face tag to antenna, and keep the correct polarization polarization Tag has been damaged...
