Summary of Contents for ActiveEye K9504L-W

Page 1 Net Video Recorder Instructions NVR Operation Manual...
Page 2 Net Video Recorder Instructions Welcome Sincere thanks for purchasing our products. Please contact us to discuss any problem or requirement. This manual is issued in respect of the network video recorder. This user manual may contain incorrect place in technology, place not matching with product function or operation, or printing mistake.
Page 3: Table Of Contents
Net Video Recorder Instructions Directory Directory ................................2 1.Introduction ..............................4 1.1 Production Introduction ........................4 1.2 Main functions: ..........................4 1.3 Open-package check： ........................4 2.Hardware ..............................5 2.1 Front Panel Description ........................5 2.2 Rear Panel Description ........................5 3.
Page 4 Net Video Recorder Instructions 4.6.2 Record Plan ........................... 21 4.6.3 Alarm setup..........................21 4.7 Playback ............................22 4.8 Video backup ........................... 23 4.9 Video Detect ............................ 24 4.9.1 Motion Detect ........................24 4.9.2 Video loss ..........................24 4.10 General setup ..........................25 4.10.1 General setup ........................
Page 5: Introduction
1.Introduction 1.1 Product Introduction K9504L-W NVR support WIFI network video. This series NVR is designed specially for the security field and is an outstanding digital surveillance product. It introduces embedded LINUX operating system which is more stable. It also supports 720P wireless real-time video preview, video encoding and playback operations.
Page 6: Hardware
Net Video Recorder Instructions 2.Hardware 2.1 Front Panel Description 1．POW：POWER light 2．HDD：HARD DISK light 2.2 Rear Panel Description 3. Installation 3.1 Environment Please place and use the NVR between 0℃ and 40℃. Avoid direct sunlight. Stay away from heat source. Do not install the NVR in damp environment.
Page 7 Net Video Recorder Instructions between NVR and IPC, the maximum distance is 60 meters. 2.Install the HDD. Please note make sure already cut off the power when install the HDD. Install Steps: (1) Remove the screw of the DVR. (2) Connect the HDD cable and power line. (3) Assemble the screw, and fix the HDD in the bottom of NVR (4) Close the cover and fix it 3.Install the antenna for the camera and NVR.
Page 8: Wifi Camera Location
Net Video Recorder Instructions (3) Click “video manage”-> click “Match Code”-> start to match code. (4) When one camera is matched code successful, take out the network cable for next camera with same operation. You can take out or ignore the network cable after all cameras is matched code. 6、Format the HDD The NVR will recording automatic after the HDD be formatted.
Page 9 Net Video Recorder Instructions The signal coverage of Antenna is similar to a round circle. Antenna located in center of the round circle, signal of surrounding is much stronger, but much weaker if antenna endpoints back off direction. According to the signal divergence of antenna, and in order to guarantee the video quality, IPC antenna should try to keep in parallel or tangent with NVR antenna.
Page 10: Software Operation
Net Video Recorder Instructions 4. Software Operation 4.1 Turn on/off/Log in/Reboot 4.1.1 Turn on  Confirm that AC voltage accessible matches with DVR. Ensure that the DVR power outlet connect with a good middle ground grounding. After switching power, the device started,【POWER】light is on. Turn into system, if the pane l status light flashing, it’s normal conditions.
Page 11: Reboot
Net Video Recorder Instructions 4.1.4 Reboot right click “Exit System”-> click “Reboot” 4.2 Settings Right click the blank of main interface: In preview mode you can right click mouse to get a desktop shortcut menu. Right click the blank of main interface -> click “System setup” Set the system parameters such as General, Encode, Network, Add IPC，System time，Video standard，...
Page 12: Introduction
Net Video Recorder Instructions Match code Introduction：Refresh, then add the device by matching code. Step： 1.Introduction： The code is matched NVR and IPC. Sending NVR WiFi name and password to IPC, so that the IPC will connect to NVR automatically. Before match Code, Delete the channel which you don’t need to use. 2.How to match code：...
Page 13: Delete Device
Net Video Recorder Instructions Introduction: IPC can be placed between NVR and the other IPC to send and receive signals, when NVR and IPC is too far to increase signal. Right click the blank of main interface -> click “video manage”-> click “Repeater”. Step: 1.After connect the device, we can change the settings in repeater according to the rate.
Page 14: Manual Edit
Net Video Recorder Instructions 4.3.3.Manual Edit Right click the blank of main interface -> click “video manage”->click “Manual Edit” 4.3.4.Encode setup Right click the blank of main interface -> click “video manage”-> click “Channel setup”  Note: Combine encode introduces video compression technique which combines and compresses multi-channel’s video to a special channel.Applying for multi-channel playback simultaneously, Dial-up multi-channel real-time monitor, mobile monitor and so on.
Page 15: Network Setup
Net Video Recorder Instructions 4.4 Network setup 4.4.1.Network setup Step： 1、Insert the network cable to the recorder WAN port from your router. 2、Right click the blank of main interface -> click “System setup”-> click “Network setup”-> click “Network setup” 3、Tick DHCP and Cloud (P2P). 4、Click“Apply”and save settings.
Page 16: Ddns
Net Video Recorder Instructions Used to transmit video and signals in a Web page,PC clients and mobile Web port network. phones use. Default: 80 DHCP server Obtain IP automatically 4.4.2.DDNS Introduction：It is the abbreviation of dynamic domain name server. Step： 1、Right click the blank of main interface ->...
Page 17: E-Mail
Net Video Recorder Instructions 2、DDNS Function:Choose Enable. 3、Fill in information.Provide the account and password registered by DDNS. 4、Click“Test”and “Apply”. 4.4.4.E-Mail Introduction：If the alarm is turned on or the alarm linkage photos are taken, send a notification about the alarm information to the appointed email address. Step：...
Page 18 Net Video Recorder Instructions Name Description SMTP Server Email server address. It could be an IP address or domain name. Port 25 (Most of then are 25, please check from your mail server) Username Your full Email address Password Your Email password Choose SSL.(Default setting is none, if you click the 'test' failure, Encryption Type please change to SSL)
Page 19 Net Video Recorder Instructions  After E-Mail setup and test，you also need to set up in the alarm and the video detection. Select "Motion Detection", "Video Loss" or "Video Mask", check "E-Mail Notice", and click on "E-Mail" to select the type of detection you want to perform E-Mail triggering. OK, as shown below: Alarm detection Trigger E-Mail, the main interface right-click "System Settings"...
Page 20: Pppoe
Net Video Recorder Instructions 4.4.5.PPPoE Introduction：After PPPoE dialing successfully look up the IP address in the [IP address] and obtain the current IP address. Then use this IP address to visit the NVR through user port. Step： 1、Right click the blank of main interface -> click “System setup”-> click “Network setup”-> click “PPPOE” 2、...
Page 21: Record
Net Video Recorder Instructions Right click the blank of main interface -> click “System setup”-> click “Channel setup”-> click “PTZ setup” Note： 1. Decoder A(B)line connects with NVR A(B)line. Make sure the connection is right before use. 2. The PTZ functions are decided by the PTZ protocols. 2.PTZ control 1.Right click the blank of main interface ->...
Page 22: Record Plan
Net Video Recorder Instructions 4.6.2 Record Plan Introduction：Set the recording parameters in the surveillance channel. The system is set 24 hours consecutive recording in the first start up. You can enter [main menu]> [record mode] to set. Step： 1、Right click the blank of main interface -> click “System setup”-> click “Record setup”-> click “Record Plan”...
Page 23: Playback
Net Video Recorder Instructions 2、Choose the set motion detect channel. 3、Work mode choose disable,means that the motion detect function is on. 4、【EMAIL Notice】【Buzzer】【Alarm】,Choose the Settings as you needed. 5、Click“Apply”,Finish.  Note:Set in the [Net service] and send email. 4.7 Playback 1.Right click the blank of main interface ->...
Page 24: Video Backup
Net Video Recorder Instructions  Playback progress can be controlled。  Playback speed can be changed 4.8 Video backup Introduction：Video backup to USB. 1、Right click the blank of main interface -> click “Video backup” 2、Choose channel and Record mode. 3、Then search time. 4、The system will search the recording data according to the condition.
Page 25: Video Detect
Net Video Recorder Instructions 4.9 Video Detect 4.9.1 Motion Detect Introduction：When system detects the motion signal that reaches the set sensitivity, the motion detect alarm is on and the linkage function is turned on. Right click the blank of main interface -> click “System setup”-> click “Record setup”-> click “Record Plan” 【Sensitivity】Choose in the options according to the sensitivity.
Page 26: General Setup
Net Video Recorder Instructions 2、Then choose Alarm duration. 3、Click“Apply”. 4.10 General setup 4.10.1 General setup Right click the blank of main interface -> click “System setup”-> click “General setup” 4.10.2 Time setup Right click the blank of main interface -> click “System setup”-> click “General setup”-> click “Time setup”.
Page 27: Screen Setup
Net Video Recorder Instructions 4.10.3 Screen setup Introduction：VGA resolution setup. Right click the blank of main interface -> click “System setup”-> click “General setup”-> click “Screen setup”. Name Description OSD Alpha change the transparency of the interface. VGA resolution Set display resolution and mode. Auto Switch Patrol time 4.10.4 HDD setup...
Page 28: System Admin
Net Video Recorder Instructions Right click the blank of main interface -> click “System setup”-> click “System Admin”-> click “HDD info”.  If the user need to change the damaged hard disk, you must shut down the NVR and take up all the damaged hard disks,then install a new one.
Page 29: User Admin
Net Video Recorder Instructions  Users need to provide the corresponding version information in the maintenance. System log： Introduction：Look up system log according to the set mode. Right click the blank of main interface -> click “System setup”-> click “System Admin”-> click “System log”. ...
Page 30: Factory Setting
Net Video Recorder Instructions Page1 2.appear the page2 and you can reset the password Page2 4.11.3 Factory setting 1、Right click the blank of main interface -> click “System setup”-> click “System Admin”-> click “Factory setting”. 2、Change the Settings as needed.than click“Apply”. 4.11.4 System maintenance Introduction：include system maintenance and system upgrade.
Page 31: Web
Net Video Recorder Instructions 1、Right click the blank of main interface -> click “System setup”-> click “System Admin” System maintenance: System upgrade: 2、Change the Settings as you need.than click “Start”. 3、After upgrading,the device will reboot.  Do not turn off the power when upgrading, otherwise it will not start. 5.
Page 32: Access In Wan
Net Video Recorder Instructions If the software cannot be loaded, need to enable the plug-in settings on the browser: ->Internet Tools Options - > Security - > Custom Level ->Actice X controls and plug-ins are selected as enabled, and finally click "ok" Step 3:Once access successfully,can get video Tips: Please make sure video recorder and computer in same network segement 5.2 Access in WAN...
Page 33 Net Video Recorder Instructions Before you start, please make sure your router is enabled DHCP and connected to Internet. Search APP: No.1: Go to APP store —Search Eseenet/ IP-pro —Input APP ID and password —Click download No.2: Go to http://www.dvr163.com/help/download.php in mobile, — software download — install Scan two-dimension code：...
Page 34: Hard Drive Capacity Unit
Net Video Recorder Instructions 7. Hard drive capacity unit Capacity unit for operating system Capacity unit for the NVR (OS) 1 B ＝ 8 b 1 B ＝ 8 b 1 MB ＝ 1000 KB 1 MB ＝ 1024 KB 1 GB ＝...
Page 35 Net Video Recorder Instructions  A=required hard disk capacity, B=code rate, N=the number of video channels, D=the number of recording days...
