Page 1: Installation Manual
Installation Manual AI-VODSV-02-1 Audio and Video-on-Demand Server Document # 540210 7300 Industry Drive, North Little Rock, AR 72117 Phone: 501-955-2929 Fax: 501-955-2988 www.audiointl.com... -
Page 2: Document Revision History
12-14 PROPRIETARY NOTICE: Despite any other copyright notice, this document and information disclosed herein contains confidential, proprietary designs owned by Audio International, Inc. Neither this document nor the data contained herein shall be reproduced, used, or disclosed to anyone without the written authorization of Audio International, Inc. -
Page 3: Table Of Contents
Audio International, Inc. AI-VODSV-02-1 Installation Manual Table of Contents Section Description Page General Information ……………………………………………. Introduction ……………………………………………………….. Purpose of the Equipment ………………………………………. Optional Equipment ……………………………………………… Application ……………………………………………………….. Introduction………………………………………………………… Block Diagram – Typical Application……………………………. Installation ……………………………………………………….. Prior to Installation ……………………………………………….. Unpacking and Inspection ………………………………………. -
Page 4: General Information
Ethernet network, PCs, and/or Electronic Control Units (ECUs). 1.2.3 Capability of receiving periodic entertainment content updates. 1.2.4 PA and briefer key selection is provided to the AI-VODSV-02-1 server via independent discrete ground inputs. Optional Equipment Audio International, Inc. offers a comprehensive family of Cabin Control Modules. -
Page 5: Application
A typical audio and video content library may consist of 25 video streams. 2.1.3 The AI-VODSV-02-1 provides for the following system interfaces: • AI proprietary RS-485 and RS-232 data bus interface • 100 Mbps Ethernet • ARINC 429 (2 transmit / 2 receive) •... -
Page 6: Installation
• Convenience for user interface (if applicable) • Access for service repair (if applicable) 3.1.2 The AI-VODSV-02-1 shall be installed to conform to the standards designated by the customer, installing agency, and existing conditions as to the unit location and type of installation. -
Page 7: Wiring Requirements
Audio International, Inc. AI-VODSV-02-1 Installation Manual 3.3.2 DO NOT connect or disconnect the monitor while power is applied. 3.3.3 DO NOT remove any factory-installed screws. Damage to the units may result and void any warranties. 3.3.4 NO scheduled maintenance is required to ensure continued airworthiness 3.3.5 ESD (Electro Static Discharge) guidelines shall be followed. -
Page 8: Ai's Proprietary Rs-485 Data Bus
MIL-DTL-27500 or equivalent. AI’s Proprietary RS-485 Data Bus 3.5.1 The AI-VODSV-02-1 is designed to interface with other Audio International equipment via AI’s proprietary RS-485 serial data bus. The data bus shall be implemented using a twisted shielded pair cable in accordance with the standard military specification of MIL-DTL-27500 or equivalent. -
Page 9: Electrical Characteristics
Audio International, Inc. AI-VODSV-02-1 Installation Manual Electrical Characteristics Electrical Specifications: Electrical Power 115 VAC, 400 Hz 20 concurrent MPEG streams A/V Distribution @ 2.0 mbps Ethernet 100 Mbps Operating 10° to 50° C Temperature 150 Watts, MAXIMUM Power Dissipation 100 Watts, NOMINAL... -
Page 10: Pinout Assignment Descriptions
Audio International, Inc. AI-VODSV-02-1 Installation Manual Pinout Assignment Descriptions Section J1B Section J1A Pin # Function Pin # Function 115 VAC / 400 Hz HI + 28 VDC 115 VAC / 400 Hz LO Power Ground Chassis Ground Chassis Ground... -
Page 11: 3.10 Post-Installation Test
Audio International, Inc. AI-VODSV-02-1 Installation Manual 3.10 Post-Installation Test The following LED’s verify good Ethernet connections: 3.10.1 Verify adequate power connections by viewing the Power Status LED (Green) located on the front panel. 3.10.2 Verify adequate discrete connections by viewing the Discrete Active LED (Red) located on the front panel. -
Page 12: Troubleshooting Chart
Audio International, Inc. AI-VODSV-02-1 Installation Manual Troubleshooting Chart Problem Possible Cause Solution Ø Lack of power being • No distribution of Check Power Status LED audio/video supplied to unit (Green). This LED streams should be active. If not, push Switch #2 (Power Reset Switch) located on the front panel. -
Page 13: Reference Drawings
Audio International, Inc. AI-VODSV-02-1 Installation Manual Reference Drawings The following diagrams show the unit dimensions, mounting locations, and connector locations for the AI-VODSV-02-1. Side View Document # 540210, Rev IR, 04/2001 Page 12 of 14... -
Page 14: Rear View
Audio International, Inc. AI-VODSV-02-1 Installation Manual Rear View Document # 540210, Rev IR, 04/2001 Page 13 of 14... -
Page 15: Front View
Audio International, Inc. AI-VODSV-02-1 Installation Manual Front View Top View Document # 540210, Rev IR, 04/2001 Page 14 of 14...
