- Page 1 Clarity ® TV Listener C120 User Guide...
-
Page 2: Table Of Contents
CONTENTS Parts checklist ..................3 Quick Reference Guide ..............4 Features ....................5 Clarity Power Control ..............5 Telephone ring notification .............5 Public IR address usage ..............5 Setup Guidelines C120 Transmitter ................6 C120 Headset................9 Troubleshooting ................12 Safety Information................. -
Page 3: Parts Checklist
3. TV Microphone 4. Rechargeable Battery 5. Power Supply 6. RCA Cable (dual red and white plugs) 7. RCA - 3.5mm Cable 8. Flathead Screwdriver 9. User Guide C120 Headset AC wall charger C120 Transmitter Rechargeable battery Microphone RCA stereo cable... -
Page 4: Quick Reference Guide
Quick Reference Guide C120 C120 STEREO / MONO L/MONO STEREO / MONO STEREO RCA JACKS L (WHITE) DC12V LINE PHONE STEREO MONO R (RED) TV BACK VIEW Alternate Mono cable (provided) (if TV only has one sound jack) QUICK START GUIDELINES 1. -
Page 5: Features
The C120™ not only can be used for enjoying at home, but can be used outside the home in places like the movies, conventions, museum tours, and sporting events (where a public infrared system is offered). -
Page 6: C120 Transmitter
SETTING UP THE C120™ TRANSMITTER Important Setup Guidelines The C120™ TV Listener transmitter may be placed on top of a television or shelf. This product uses infrared light. This type of signal can be blocked by solid objects. Do not place objects in between the transmitter base and the headset receiver. - Page 7 3.5mm jack. (Fig. 4) A 3.5mm jack is the size found on a pair of headphones. This can be used to connect the C120™ to devices with 3.5mm ports, such as CD players, radios and other small electronics. See Figures 6-9.
- Page 8 This mode should be used if the television (or other audio equipment) has only one audio RCA or a 3.5mm jack. This enables the C120™ to be used with FIG. 5 computers, CD players, stereos, mp3 players, and other related products.
- Page 9 C120 OPERATION Telephone The C120™ has the ability to produce an audible indicator heard through the headset when the telephone rings. The following step is necessary if telephone ring notification is desired. First, plug the telephone cord coming from the wall into the jack on the rear of the base labeled “LINE.”...
- Page 10 If there is FIG. 16 no audio signal being detected by the C120™ for one and a half minutes, it will power down. Note: The infrared sensor that communicates...
-
Page 11: C120 Headset
A small screwdriver will be needed to adjust this control. Tone Controls There are two controls for tone, one for each earphone (left and right). A small screwdriver will be needed to adjust these controls. FIG. 18 C120 Headset INCLUDED HOME AWAY Secondary battery charging... -
Page 12: Troubleshooting
4. Ensure that the line of sight from the transmitter base to the headset receiver is clear. 5. Check the battery in the C120™ Headset to see if it is fully charged. 6. Check to see if the infrared sensor on the base is facing the headset and make sure the headset sensor is facing the base. -
Page 13: Safety Information
SAFETY INFORMATION Hearing Safety The C120™ is designed to be used as an assisted listening device. This pro- duct is intended to amplify sounds to a high volume. This means that damage to hearing ability is a possibility if used improperly. To prevent any possible hearing damage, please observe the following guidelines. -
Page 14: Technical Specifications
Weight: 5.2 oz (147g) Power Supply: 100-240V, 50/60 Hz, 0.15 Amps Charging Docks: Charges one (1) C120™ Headset and two (2) additional batteries in the auxiliary docks. Auto Off Power: Transmitter turns off after it has not detected audio signal for 1.5 minutes. -
Page 15: Regulatory Compliance
RENs should warranty information, please con- not exceed five (5.0). To be certain of tact Clarity, 1-800-552-3368. If the the number of devices that may be equipment is causing harm to the connected to a line, as determined... - Page 16 REGULATORY COMPLIANCE g) This telephone equipment is not Part 15 of FCC Rules intended to be repaired and it Information contains no repairable parts. Open- This device complies with Part 15 of ing the equipment or any attempt the FCC Rules. Operation is subject to perform repairs will void the to the following two conditions: (1) warranty.
-
Page 17: Technical Specifications
REGULATORY COMPLIANCE receiver with respect to the with the above conditions may not telephone equipment. (This prevent degradation of service in increases the separation between some situations. Repairs to certified the telephone equipment and equipment should be made by an the receiver.) authorized Canadian maintenance facility designated by the supplier. - Page 18 fication/registration number only signifies that the Industry Canada technical specifications were met.) The party responsible for regulatory compliance: Clarity, A Division of Plantronics, Inc. 4289 Bonny Oaks Drive, Suite 106 Chattanooga, TN 37406 Phone: 1-800-552-3368 Battery Disposal Information The rechargeable batteries in the C100™...
- Page 19 Chattanooga, TN 37406 1-800-552-3368 www.clarityproducts.com ©2006 Clarity, a Division of Plantronics, Inc. All Rights Reserved. Clarity, the amplification device, Clarity and the amplification device combined, Amplifying Your Life, Clarity Power and C120 are trademarks or registered trademarks of Plantronics, Inc.
