- Page 1 Slot-in Electric Cooker INSTALLATION AND USER INSTRUCTIONS Model Number. E297 Read these instructions prior to using the cooker and retain them for future reference.
- Page 2 GLEN by belling Brand E 297 Model A - More efficient G - Less efficient 0,98 Energy consumption (KWh) 52,9 Time (min) Conventional Usable volume (litres) Large Medium Small The area of the largest baking sheet (cm2) 1 420...
- Page 3 The appliance was designed and made in accordance with the European standards listed below: EN 60 335-1 and EN 60 335-2-6 (electrical) plus relative amendments • The appliance complies with the prescriptions of the European Directives as below: 73/23 + 93/68 EC concerning electrical safety (BT). •...
-
Page 4: Table Of Contents
Contents Introduction………………………………………………... Instructions for Installer..........………… Technical Data...........……………. For Your Safety............... 9-10 Know your cooker............…. 11-12 Using The Hob………………………………....…… Using The Hob – General Notes………………....…. 14-15 Grilling.................…… Using The Oven………………………………………..… 17-18 Cooking Guide……………………………………………….. Cleaning and Maintenance ........….. 20-21 Is There Something Wrong With Your Cooker ? ....Service................….. -
Page 5: Introduction
Introduction Your Cooker Thank you for purchasing a new Belling electric Cooker. Its stylish and practical design will enhance your kitchen and make cooking a pleasure. It features a large oven with a light, a grill and a hob with four sealed hotplates. Even if you have used an electric cooker before, it is important that you read these instructions thoroughly before starting to cook, as there may be many new features not featured on your previous cooker. -
Page 6: Instructions For The Installer
Instructions for the installer TECHNICAL INFORMATION • All installation and maintenance must only be carried out by qualified personnel. The manufacturer cannot be held responsible for any damage to persons or property resulting from an incorrect installation of the appliance. •... -
Page 7: Electrical Connection
Instructions for the installer LEVELLING THE COOKER The appliance is supplied with four plastic feet, which must be screwed into the corners of the oven base prior to installation. These feet are used to level the oven and adjust its height in relation to the surrounding cabinetry. - Page 8 Instructions for the installer Connection Using a screwdriver open the connector cover at the rear of the appliance. The cover is released by releasing the two locks located at either side of the connector bottom. Pass the supply cable through the cable clamp and connect to the appropriate terminals shown in the diagram below, checking that the terminal links are in the correct position.
- Page 9 Instructions for the installer POSITION Refer to the diagram below. Allow sufficient cable length for the cooker to be pulled out for cleaning, but ¤ ¥ £ £ do not let it hang closer than 50mm (2”) £ to the floor. The cable can be looped if ¢...
-
Page 10: Technical Data
Technical Data DIMENSIONS Height 900 - 915mm Width 498mm Depth 605mm (excluding handle and knobs) GENERAL Supply Voltage 230 - 240V A C ~ 50 Hz Total Wattage 7.35 kW Left Hand Front Hotplate Wattage (1) 2.0 kW Left Hand Rear Hotplate Wattage (2) 1.0 kW Right Hand Front Hotplate Wattage (4) 1.0 kW... -
Page 11: For Your Safety
For Your Safety When used properly your Belling cooker is completely safe, but as with any electrical appliance there are some precautions you must take in its use. ALWAYS • ALWAYS make sure you understand the controls before using the cooker. •... - Page 12 For Your Safety NEVER • NEVER allow anyone except an authorised Belling Service Agent to service or repair your cooker. • NEVER line the shelves, sides or floor of the oven with aluminium foil as overheating and damage will result. •...
-
Page 13: Know Your Cooker
Know your cooker Control Panel Oven / grill thermostat Oven function selector Oven preheat neon Cooker ‘on’ neon Hotplate controls Function Select The cooking function is selected by turning the appropriate control (2) to the desired position. Cooking functions available are as follows, Variable Grill Conventional Oven (Top and Base heat) Base heat only... - Page 14 Know your cooker Thermostat The Thermostat (1) is used to set the desired cooking temperature, and is used in conjunction with the function selector. Temperature is set by turning the control clockwise to the desired setting, with a range between 50ºC and approximately 250ºC being available The oven indicator light (3) will immediately come on and remain on until the oven reaches the set temperature.
-
Page 15: Using The Hob
Using The Hob The hob is equipped with four sealed hotplates, one of which is a rapid boil plate, indicated by a red mark. The plates are controlled by a 7 - position switch (5). Switch on the plates by turning the knob to the required position. Use of Hotplates Each control can be used to select one of six temperature settings from a minimum at position 1 to a maximum at position 6. -
Page 16: Using The Hob - General Notes
Using The Hob – General Notes SAFETY REQUIREMENTS FOR DEEP FAT FRYING IMPORTANT – As with any cooking appliance there could be some fire risk attached to the heating of oil, particularly for deep fat frying, cooking utensils containing oil must not be left unattended on or in close proximity to the cooking zones. - Page 17 Using The Hob – General Notes Remember… 1. Purchasing will necessarily mean it will have a flat base, always check before buying. 2. Using the correct pans and utensils will result in maximum contact with the hob and maximum efficiency as with any type of electric hob.
-
Page 18: Grilling
Grilling WARNING: DURING USE THE APPLIANCE BECOMES HOT. CARE SHOULD BE TAKEN TO AVOID TOUCHING HEATING ELEMENTS INSIDE THE OVEN. IMPORTANT! GRILLING MUST ALWAYS BE CARRIED OUT WITH THE OVEN DOOR CLOSED NEVER allow young children near the appliance when the grill is in use as the surfaces get extremely hot. -
Page 19: Using The Oven
Using The Oven The oven is controlled by first selecting a cooking function with the function selector knob (2) then turning the thermostat (1) to the required temperature. When operated an indicator light (3) will immediately come On, and will go out when the desired temperature is reached, subsequently switching On and Off at intervals to indicate that the correct temperature is being maintained. - Page 20 Using The Oven To prepare Meat and Poultry for Roasting in your Oven (a) Wipe the meat or poultry, dry well and weigh it. Meat which has for been stored in a refrigerator should be allowed to come to room temperature before cooking, and frozen meat or poultry must be completely defrosted before placing in the oven.
-
Page 21: Cooking Guide
Cooking Guide When cooking on one shelf only, generally use the shelf position 2 up and shelf positions 1 and 3 when cooking on 2 shelves. MEAT Preheat Thermostat Time (approximate) Setting (ºC) Beef / Lamb 170 / 190 35 mins per 450g (1 lb) (slow roasting) + 35 mins over Beef / Lamb... -
Page 22: Cleaning And Maintenance
CLEANING AND MAINTENANCE In the interests of both safety and hygiene your Belling electric cooker needs to be kept clean. A build-up of grease or fat from cooking could cause a fire hazard. WARNING! For your own safety, always switch off your cooker at the mains supply and allow to cool before cleaning. - Page 23 CLEANING AND MAINTENANCE Cooker Exterior Wipe over with a damp cloth wrung out in warm soapy water and polish with a dry cloth. Do not use cream cleaners, oven cleaners or abrasive powders for cleaning the plastic knobs as damage may occur. Oven Door Seal The oven door seal guarantees the correct functioning of the oven.
-
Page 24: Is There Something Wrong With Your Cooker
Is There Something Wrong With Your Cooker? Before contacting your Service Centre or Installer, check the guide below, there may be nothing wrong with your cooker. Problem Check Nothing works Is the main cooker wall switch turned on? Selected function doesn’t Work Has a temperature been selected? oven doesn’t... -
Page 25: Service
Service Please check your guarantee card for who to contact for service. Remember that service agents may charge for visits (even during the guarantee period) if nothing is found to be wrong with the appliance, so always check the instructions to make sure you have not missed anything. - Page 26 Belling Appliances Ltd., Mexborough, South Yorkshire S64 8AJ ES E297 / 021107...
