Handlink R-300NP User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
R-300NP
Wireless Router

User Manual

無線路由器
(WIFI)
Handlink
Handlink Technologies Inc.
6830607-0010G EN V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R-300NP and is the answer not in the manual?

Questions and answers

Summary of Contents for Handlink R-300NP

  • Page 1: User Manual

    R-300NP Wireless Router User Manual 無線路由器 (WIFI) Handlink Handlink Technologies Inc. 6830607-0010G EN V1.0...
  • Page 2 Copyright Notice Copyright © 2014-2023 Handlink Technologies Inc. All rights reserved. No part of this document may be copied, reproduced, or transmitted by any means, for any purpose without prior written permission. Disclaimer We shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from furnishing this material, or the performance or use of this product.

  • Page 3: Table Of Contents

    1-5 Technical Specifications ------------------------------------------------------------------------------------------------ 8 1-5-1 Hardware Specifications -------------------------------------------------------------------------------------- 8 1-5-2 Software Specifications --------------------------------------------------------------------------------------10 Installation -----------------------------------------------------------------------------------------------------------------12 2-1 Installation Requirements ----------------------------------------------------------------------------------------------12 2-2 Hardware Setup ----------------------------------------------------------------------------------------------------------13 Configuring the R-300NP ----------------------------------------------------------------------------------------------14 3-1 Wizard Setup --------------------------------------------------------------------------------------------------------------14 3-2 Advanced Setup ----------------------------------------------------------------------------------------------------------22 3-2-1 System ------------------------------------------------------------------------------------------------------------23 3-2-2 WAN/LAN --------------------------------------------------------------------------------------------------------25 3-2-3...
  • Page 4 3-3 System Status ------------------------------------------------------------------------------------------------------------49 3-3-1 System ------------------------------------------------------------------------------------------------------------49 3-3-2 Current User ----------------------------------------------------------------------------------------------------51 3-3-3 DHCP Clients ---------------------------------------------------------------------------------------------------52 3-3-4 Session List -----------------------------------------------------------------------------------------------------52 3-4 System Tools --------------------------------------------------------------------------------------------------------------52 3-4-1 Configuration ----------------------------------------------------------------------------------------------------53 3-4-2 Firmware ---------------------------------------------------------------------------------------------------------54 3-4-3 System Account ------------------------------------------------------------------------------------------------56 3-4-4 PING Command------------------------------------------------------------------------------------------------56 3-4-5 Restart ------------------------------------------------------------------------------------------------------------57 3-4-6 Logout ------------------------------------------------------------------------------------------------------------57 Appendix A Regulations/EMI Compliance -------------------------------------------------------------------------------58 Appendix D LIMITED WARRANTY ----------------------------------------------------------------------------------------60...

  • Page 5: Introduction

    Introduction R-300NP is the best WiFi solution provider for venue owner and its customers. Using our system, the venue owner could be able to provide the free WiFi service that is safe and legally compliant. The Venue Owner can use R-300NP and Coolbee WiFi service to promote the store to customer.

  • Page 6: Outlook

    1-4 Outlook Figure 1 Outlook 1-4-1 Front Panel The front panel of the R-300NP is shown as below. Figure 2 Front Panel LED Indicators State Description The device is not receiving electrical power. The device is receiving electrical power. The device status is defective.

  • Page 7: Rear Panel

    The LAN has a valid 10/100Mbps network connection. Blinking The LAN is sending or receiving packet. 1-4-2 Rear Panel The rear panel of R-300NP is shown as below. Figure 3 R-300NP Rear Panel 1. Antenna 2. LAN Ports (1-4) 3. WAN/PoE port 4.

  • Page 8: Technical Specifications

    IEEE802.11g Wireless LAN ANSI/IEEE 802.3 NWay auto-negotiation Wi-Fi Compatible Connectors Four LAN Ports (10BaseT/100BaseTX Auto cross-over) One WAN Port (10BaseT/100BaseTX Auto cross-over) External Antenna Type 4dBi (Max) Dual detachable diversity antenna with reverse SMA LED Indicators One POWER LED R-300NP...
  • Page 9 One WAN 10/100M Link/Activity LED Four LAN 10M/100M Link/Activity LEDs One Wireless Link/Activity LED One System LED Power Requirement R-300NP: External Power Adapter: Power input: 12V, 1A Power consumption: Under 5 Watts PoE: Power input: 48Vdc, 0.4A, IEEE 802.3at Compliance...

  • Page 10: Software Specifications

    Restricted Destination Filtering IP/URL  Anti-DDOS Management  Administrator / Front Desk Access Management  Access Control List Management (ACL)  Remote Browser-based Configuration and management  Firmware Upgrade (RFC 1350) via HTTP/TFTP  Backup/Restore/Factory Default Setting  Port Forwarding R-300NP...
  • Page 11 System Information Table  Real-time Current User List / DHCP Clients List /  Session List / Account List  Syslog  Bandwidth control per device  Session control per device  Session Trace  SNMP (Read Only)  Ping Command R-300NP...

  • Page 12: Installation

    Installation The followings are instructions for setting up the R-300NP. Refer to the illustration and follow the simple steps below to quickly install your R-300NP. 2-1 Installation Requirements Before installing the R-300NP, make sure your network meets the following requirements.

  • Page 13: Hardware Setup

    2-2 Hardware Setup 1. Connect the R-300NP WAN port to modem by Ethernet cable.(Usually, the ISP will provide one Ethernet cable along with the modem) 2. Connect the R-300NP LAN port to PC by Ethernet cable. 3. Install the antennas.

  • Page 14: Configuring The R-300Np

    Username and Password can consist of up to 20 alphanumeric characters and are case sensitive.  If for some reason your password is lost or you cannot gain access to the R-300NP Configuration Program, please press the reset button to load the device to manufacturer defaults.
  • Page 15 The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP. If your xDSL/Cable comes with this feature, please enable Use DHCP Client. Figure 9 Internet Connection Setting Screen—DHCP Client Setting R-300NP...
  • Page 16 Secondary Empty Enter the secondary DNS server IP address for the xDSL/Cable DNS Server connection (provided by your ISP). If the primary DNS Server IP were not available, meanwhile, Secondary DNS Server IP would start in the same time. R-300NP...
  • Page 17 Enter the service name provided by your ISP. Connect on Demand and Max Idle Time Connect on You can configure your R-300NP to cut your connection with your ISP Enable Demand after a specified period of time (Max Idle Time). If you have been...
  • Page 18 Enter the user password provided by your ISP. MTU (Maximum Transfer Unit) specifies maximum PPP MTU Setting 1460 transmission unit size. MSS (Maximum Segment Size) specifies maximum segment TCP MSS Setting 1400 size. Connection ID/Name Empty Enter the connection ID or connection name. R-300NP...
  • Page 19 Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your R-300NP to cut your connection with your ISP after a specified period of time (Max Idle Time). If you have been disconnected due to inactivity, Connect on...
  • Page 20 No Authentication - Subscriber can direct access to the Internet without enter username and password. Social Media Authentication - R-300NP provides Built-in Authentication for service provider to build up an Internet service with Coolbee WiFi service. Note: If you want to active Social Media Authentication by Coolbee WiFi, please refer to Appendix A.
  • Page 21 Enter the Time Zone for the system. Server IP/Domain time.nist.gov Enter NTP Server IP or Domain Name 1 Server IP/Domain www.nist.gov Enter NTP Server IP or Domain Name 2 Update Time 24 hours Enter the number of hours for update time. R-300NP...

  • Page 22: Advanced Setup

    The system time won’t be effected by daylight saving. Daylight Saving Disable Time If you set the Daylight Saving Time (DST) on the R-300NP. Please adjust the start date and end date. Secure This function allows remote user to management the Administrator IP device.

  • Page 23: System

    3-2-1 System Define the R-300NP System configuration. Figure 17 System Setting Screen Figure 18 System Setting Screen R-300NP...
  • Page 24 Enter the number of hours for update time. Disable Enables or disables Daylight Saving Time (DST). Daylight Saving Time Set the Daylight Saving Time (DST) on the R-300NP. Month/Day Adjust the start date and end date. NAT (Network Address Translation) Enable Enables or disables NAT Address Translation function.

  • Page 25: Wan/Lan

    WAN MAC Address Figure 21 WAN MAC Address Setting Item Default Description WAN MAC Default The default MAC address is set to the WAN physical interface on Address device. WAN MTU 1500 You could set the MTU in this column. Setting R-300NP...
  • Page 26 The device can work as a DHCP client. This allows the device to obtain the IP address and other TCP/IP settings from your ISP. If your xDSL/Cable comes with this feature, please enable Use DHCP Client. Figure 23 DHCP Client Setting Screen R-300NP...
  • Page 27 ISP). Secondary DNS Server A secondary DNS server IP address for the xDSL/Cable connection (provided by your ISP). If the primary DNS Server IP were not available, the secondary DNS Server IP would start in the same time. R-300NP...
  • Page 28 Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your R-300NP to cut your connection with your ISP after a specified period of time (Max Idle Time). If Max Idle Time 10 Minutes...
  • Page 29 Enter your PPTP password. PPP MTU Setting 1460 MTU (Maximum Transfer Unit) specifies maximum transmission unit size. TCP MSS Setting 1400 MSS (Maximum Segment Size) specifies maximum segment size. Connection ID/Name Empty Enter the connection ID or connection name. R-300NP...
  • Page 30 Connect on Demand and Max Idle Time Connect on Demand Enable You can configure your R-300NP to cut your connection with your ISP after a specified period of time (Max Idle Max Idle Time 10 Minutes Time). If you have been disconnected due to inactivity,...

  • Page 31: Server

    The DHCP pool size range is 1 to 253. Lease Time The DHCP lease time. Primary DNS Server 168.95.2.1 Enter the IP address of primary DNS server. Secondary DNS Server Empty Enter the IP address of secondary DNS server. Click “Apply” button to save the new settings. R-300NP...

  • Page 32: Authentication

    No Authentication No Authentication - Subscriber can direct access the Internet without enter username and password. Social Media Authentication - R-300NP provides Built-in Authentication for service provider to build up an Internet service with Coolbee WiFi service. “ ” Click Apply button to save the new settings.
  • Page 33 128Kbps Specify the amount of downstream bandwidth. You can set the range by drop list ： 64K, 128K, 256K, 384K, 512K, 1.5Mbps, 3Mbps, 5Mbps, 10Mbps and 20 Mbps. Or key in by yourself, the range is from 64 ~20480Kbps R-300NP...

  • Page 34: Filtering

    HTTP Message The Web Site Enter the http message. The maximum character of the HTTP to display when a is blocked by message is 200. The warning page show as Figure 32. website is System blocked Figure 32 Warning screen R-300NP...
  • Page 35 Select the check boxes and click ‘Delete’ to delete the filtering Delete Disable address(s). Click “Add to List” button to add a new entry. Click “Apply” button to save the new settings. Click “Delete All & Apply” button to delete all entries. R-300NP...

  • Page 36: Port Forwarding

    3-2-7 Port forwarding Administrator can set an entry of R-300NP which translating the address or port number of a packet to a new destination Figure 33 Port Forwarding Setting Screen Item Default Description Device Name Empty The LAN device name. The system could support up to 20 date at one time.
  • Page 37 Disable Enables or disables the syslog server function. Server Syslog on LAN Enter syslog server’s IP address. The R-300NP will send all of its Server IP Address Empty logs to the specified syslog server. Enter the syslog server’s MAC address. The R-300NP will send Server MAC Address Empty all of its logs to the specified syslog server.
  • Page 38 Enter your second e-mail address to receive the logs. Click “Apply” button to save the new settings. After click “Apply” button, the dialog box will appear as below. Click “Back” button to return to Syslog setting screen. Figure 35 Success Dialog Box R-300NP...
  • Page 39 The time could be set from 5 to 60 minutes. Click “Apply” button to save the new settings. After click “Apply” button, the success dialog box will appear. Click “Back” button to return to Logs setting screen. Figure 37 Success Dialog Box R-300NP...

  • Page 40: Session Trace

    Disables or enables this function Primary TFTP Server IP Empty Enter the IP address of the primary TFTP server. Address Secondary TFTP Server Empty Enter the IP address of the second TFTP server. IP Address E-mail Server Disable Disables or enables this function R-300NP...
  • Page 41 Enter your second e-mail address to receive the logs. Send Session Trace log 10 minutes The field means to send the session trace log file every file every~ minutes. interval minutes. The value range is 5 to 1440 (minutes). R-300NP...

  • Page 42: Snmp

    The default setting for the community of entry 1 is “public” and for the entry 2 is “private” and others are empty. NMS Address The address of the NMS. The default settings for the NMS Networking are “ANY”. R-300NP...

  • Page 43: Wireless

    Chosen “Valid” or “Invalid”. The default setting of entry 1, 2 are Status Valid/Invalid valid and others are invalid. 3-2-11 Wireless Figure 40 Wireless Setting Screen Item Default Description General Settings Choose one： -802.11n+802.11g+802.11b -802.11n+802.11g 802.11n+802.11 802.11 Mode -802.11g+802.11b g+802.11b -802.11n only -802.11g only -802.11b only R-300NP...
  • Page 44 R-300NP, or in areas where the clients are far apart and can detect only the R-300NP and not each other. This setting determines the size at which packets are Fragmentation fragmented.
  • Page 45 The R-300NP supports 64-bit or 128 bit WEP encryption. Options: HEX (Hexadecimal) and ASCII (American Standard Mode Code for Information Interchange). This selects which of the Keys that R-300NP uses when it WEP Key transmits. You can change the selected encryption key any R-300NP...
  • Page 46 15. Enter the authentication port number. The allowed numbers Authentication Port 1812 are from 0 to 65535. Share Secret Key Empty Enter the RADIUS secret key Click “Apply” button to save the new settings. R-300NP...

  • Page 47: Firewall

    Item Default Description Block IP Options Enable The R-300NP will ignore any IP packets with IP option Attack WAN/LAN field in the datagram header. The reason for limitation is IP option appears to be a vulnerability of the security because it will carry significant information, such as security, closed user group parameters, a series of Internet addresses, routing messages...etc.
  • Page 48 TCP SYN packets. Interface: WAN/LAN, WAN, LAN Block UDP Flood Enable Once the UDP packets exceeded the defined value, And Fraggle the R-300NP will start to discard the subsequent UDP packets/ per sec Attack WAN/LAN packets. Interface: WAN/LAN, WAN, LAN...

  • Page 49: System Status

    3-3 System Status Display R-300NP system basic status, including, System Current User DHCP Clients Session List Figure 43 System Status Item Screen 3-3-1 System The System Information Menu displays current system basic information including the service connection message, host name, LAN, WAN, DHCP Configuration, DNS, E-mail Redirection, SSL Certificate, network traffic Information and the system firmware version.
  • Page 50 Figure 45 System Status Screen R-300NP...

  • Page 51: Current User

    R-300NP connect to Coolbee WiFi service If you R-300NP have registered on Coolbee WiFi and have been switch to Coolbee WiFi mode(Social Media Authentication enable), you will see the status of Coolbee WiFi on the top of the system page as below.

  • Page 52: Dhcp Clients

    The DHCP client table shows the current DHCP users for both Public DHCP and Private DHCP. Figure 48 Current User Screen 3-3-4 Session List The administrator could remote monitor the real time usage status of R-300NP via this page. Figure 49 Session List Screen 3-4 System Tools This allows service provider or administrator to process Firmware upgrade, change password and backup or restore configuration.

  • Page 53: Configuration

    3-4-1 Configuration Use the Configuration item to save, restore or reset configuration parameters of the R-300NP. Figure 51 Configuration Setting Screen Item Default Description Backup Click it to save the system configuration to your computer. (The default file name is “export.cfg” ) or it could be save to the TFTP you assigned.

  • Page 54: Firmware

    3-4-2 Firmware This function allows you to upgrade the firmware of your R-300NP.  Manual Firmware Upgrade Figure 52 Manual Firmware Upgrade Setting Screen Item Default Description This allow administrator to upgrade the firmware via local file. Local PC File Path Empty Select the file from local PC.
  • Page 55 Enter the file name and location in the File Synchronization field. Click the button to display synchronization file example. Frequency Weekly Set the firmware upgrade time. The default value is “Weekly”. Note: Do not turn the power off during the upgrade process. This will damage the unit. R-300NP...

  • Page 56: System Account

    5 minutes, the account will logout automatically. 3-4-4 PING Command The Ping function can check the R-300NP networking connect status. Figure 55 Ping Command Screen Item Description IP or URL Enter the IP address or the URL link of the unit that you would like to check.

  • Page 57: Restart

    3-4-5 Restart If your R-300NP is not running normally, you can choose this option to restart R-300NP. Click the “Apply” button to restart the R-300NP with all of your settings remaining the same. Figure 56 Restart Screen 3-4-6 Logout If you would like to leave the configuration page, please click “Apply” to exit.

  • Page 58: Appendix A Regulations/Emi Compliance

    This Transmitter must not be co‐located or operating in conjunction with any other antenna or transmitter. This equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20 centimeters between the radiator and your body. R-300NP...
  • Page 59 NCC Statement 低功率射頻電機設備警語 依據低功率電波輻射性電機管理辦法 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者均不得擅自變更頻率、加大功 率或變更原設計之特性及功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通信；經發現有干擾現象時，應立即停用，並 改善至無干擾時方得繼續使用。 前項合法通信，指依電信法規定作業之無線電通信。 低功率射頻電機須忍受合法通信或工業、科學及醫療用電波輻射性電機設備之干擾。 NTC Thailand: “This telecommunication equipment conforms to NTC technical requirement.” R-300NP...

  • Page 60: Appendix D Limited Warranty

    Causes external to the product, such as electric power fluctuations or failure. f. Use of supplies or parts not meeting our specifications. g. Normal wears and tear. h. Any other cause that does not relate to a product defect. 3. Removal, installation, and set-up service charges. R-300NP...
  • Page 61 TIME, LOSS OF PROFITS, LOSS OF BUSINESS OPPORTUNITY, LOSS OF GOODWILL, INTERFERENCE WITH BUSINESS RELATIONSHIPS, OR OTHER COMMERCIAL LOSS, EVEN IF ADVISED OF THE POSSIBLITY OF SUCH DAMAGES. 2. ANY OTHER DAMAGES, WHETHER INCIDENTAL, CONSEQUENTIAL OR OTHERWISE. 3. ANY CLAIM AGAINST THE CUSTOMER BY ANY OTHER PARTY. R-300NP...
