BetaDyne Power RSP-1500-5 Manual

Dimension
L * W * H
278 * 127 * 83.5 (2U) mm
10.9 * * 3.29 (2U) inch
5
■ Features
Universal AC input / Full range
Built-in active PFC function
High efficiency up to 91%
Forced air cooling by built-in DC fan
Output voltage programmable
Active current sharing up to 6000W (3+1)
Built-in remote ON-OFF control / remote sense /
/
auxiliary power power OK signal
Protections: Short circuit / Overload / Over voltage
/ Over temperature
Optional conformal coating
5 years warranty
■ Description
RSP-1500 is a 1.5KW single output enclosed type AC/DC power supply. This series operates for 90~264VAC
input voltage and offers the models with the DC output mostly demanded from the industry. Each model is
cooled by the built-in fan with fan speed control, working for the temperature up to 70 . Moreover, RSP-1500
provides vast design flexibility by equipping various built-in functions such as the output programming,
active current sharing, remote ON-OFF control, auxiliary power, etc.
■ Model Encoding / Order Information
RSP - 1500 - 48
Output voltage (5V/12V/15V/24V/27V/48V)
Output wattage
Series name
MEAN WELL RSP-1500 SERIES
1500W Single Output with PFC Function
■ Certificates
Safety: UL/EN/IEC 60950-1
EMC: EN 55022 / 55024
■ Applications
Factory control or automation apparatus
Test and measurement instrument
Laser related machine
Burn-in facility
Digital broadcasting
RF application
, ℃
