- Page 1 POE Fibre Switch User Manual V1.02...
- Page 2 1. Precautions Please read the manual carefully before installing and using the switch. Disassembling any parts of the product without authorization is strictly prohibited. Please put the product into the standard cabinet, placed in ventilated and dry place when using.
-
Page 3: Product Introduction
1 POE Switch; ② 1 Power Adaptor(DC48V); ③ 1 User Manual; ④ 1 Warranty Card; ⑤ 1 Conformity Certificate If any shortage or damage found, please contact us in time. 4. Appearance Description ①AOM-1400P/AOM-1400T Front Panel ❶❷❸❹❺❻ ❼ ❽ ②AOM-1400P-T/AOM-1400T-T Front Panel ③AOM-1800P/AOM-1800T Front Panel... - Page 4 ❶ ❷❸ ❹❺ ❻ ❼ ❽ ④AOM-1800P-T/AOM-1800T-T Front Panel ⑤POE Fibre switch patch panel description Explanation “ON” Signal input through FX/TX ❶ “ON” Fibre link is in correct connection. ❷ LINK “Blink” Packet goes through Fx end. ❸ Power is on and normal. “ON”...
- Page 5 switch through twisted-pair CAT5. ② Fibre interface: Connect the 10/100Base-TX PD device to the Fibre interface of POE switch through SC/FC/ST optical Fibre. Note: Optical Fibre connecting is in pair, when single A-B, dual TX-RX. ③Connect the power cord, plug it in, turn on the power. When turn on, the switch will automatically initialize, and RJ45 port LED lights will be off after bright, which means the restoration is successful.
