Allwins AWU511N User Manual

802.11b/g/n wireless usb adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
AWU511N
(AWU511N-W)
User's Manual
Part Name：802.11b/g/n Wireless USB Adapter
Part No.：AWU511N(AWU511N-W)
Version：V1.0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AWU511N and is the answer not in the manual?

Questions and answers

Summary of Contents for Allwins AWU511N

  • Page 1 AWU511N (AWU511N-W) User’s Manual Part Name：802.11b/g/n Wireless USB Adapter Part No.：AWU511N(AWU511N-W) Version：V1.0...

  • Page 2: Revision History

    AWU511N User’s Manual ( AWU511N-W) Revision History Release Date Revision Initials 2009-10-22 Initial release Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...

  • Page 3: Table Of Contents

    4. INSTALL THE DRIVER 5. CONNECT 6. MAKE INFRASTRUCTURE CONNECTION 7. HELP INFORMATION IN RAUI 8. MAKE AD-HOC MODE CONNECTION APPENDIX A: TERMINOLOGY APPENDIX B: IMPORTANT NOTICES Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...

  • Page 4: Important Note

    RF Exposure Statement This device has been evaluate to meet general RF exposure requirement The device can be used in portable exposure condition without restriction. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...

  • Page 5: Product Overview

    ( AWU511N-W) AWU511N(AWU511N-W) User’s Manual 1. Product Overview AWU511N(AWU511N-W) is a 150Mbps USB Wireless Adapter that Compliant with IEEE 802.11b/g/n. It supports WEP, WPA, IEEE802.1x, CCK, and TKIP encryption and authentication mechanisms. Wireless transmission rates of up to 150Mbps. Built-in omni- directional smart antenna can adapt to different working environment .So that the desktop, as...

  • Page 6: Install The Driver

    Win 98 / ME / 2000 / XP / 64-bitXP/2003 /Linux Supported OS 70mm x25mm x12mm Dimension (L*W *H) Temperature Humidity Environment Operating: 0～40℃ Operating: 10%-90% Specification Storage:-10℃～70℃ Storage: 5%-90% 4. Install the driver Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 7 Step2 Choose I accept the terms of the license agreement and click next to go on. Step3 Choose Install driver and Ralink WLAN Utility and click next to go on. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...
  • Page 8 AWU511N User’s Manual ( AWU511N-W) Step4 Choose Ralink Configuration Tool and click next to go on. Step5 Click Install to begin the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 9 AWU511N User’s Manual ( AWU511N-W) Step6 Click Finish to end the setup. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...

  • Page 10: Connect

    Plug in your usb wireless LAN adapter, it will be recognized and auto installed. Just confirmed it like below: 6. Make infrastructure connection Double click the icon in red circle You will see: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 11 Choice one you want to connect, and click the button connect to finish the connection. An infrastructure connection is completed. Note: please choose correct channel setting up to your law, otherwiseyou will never find the Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...

  • Page 12: Help Information In Raui

    How to find out which WIFI environment you are inside and your IP address : 8. Make Ad-Hoc mode connection 8.1 Make an Ad-Hoc SSID Step1 Click the button Add to make the Ad-Hoc SSID: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 13 Step2 Choose the SSID and Network Type as blew,and click OK to go on. Step3 Clilk the PROF1 in the window，and you can see the information of Ad-Hoc SSID. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...
  • Page 14 ( AWU511N-W) 8.2 Setup static IP address for the Ad-Hoc link Step1 At its property page, double click item Internet Protocol (TCP/IP) Step2 You will get: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 15 AWU511N User’s Manual ( AWU511N-W) Step3 Fill the IP address blank, example as below: Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672 Http://www.allwins.com.cn...
  • Page 16 Note: To make an Ad-Hoc mode link, we should choice the same channel. Its static IP address should be in the same subnet, and the SSID should be the same too. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...

  • Page 17: Appendix A: Terminology

    WPA (Wi-Fi Protected Access) A specification of standards-based, interoperable security enhancements that strongly increase the level of data protection and access control for existing and future wireless LAN systems. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...

  • Page 18: Federal Communications Commission Interference Statement

    FCC Caution: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. Shenzhen Allwins Technology Corporation Add:9/F,Block A,Tsinghua Hi-tech Park,Nanshan,Shenzhen,China. Tel:+86-755-26030800 26030361 26030362 260630363 Fax:+86-755-33300672...
