Summary of Contents for IOT RF Series

  • Page 1 IoT Smart Home Series User’s Manual...

  • Page 2: Table Of Contents

    Table of Contents 1. Product Introduction ............................3 1.1 8810S ................................ 3 2. Connecting the Camera to the Internet ...................... - 4 -4 2.1 Downloading APP - “ALLCAM” ......................- 4 -4 2.2 Power on the Camera ..........................5 2.3 First Time Setup ..........................- 5 -5 2.4 Adding a Camera (Multiple Cameras) ......................
  • Page 3 Smart Home System is the wisdom of life, and through the IoT ★ Camera allows the users to check, to confirm and to feel relieved /at ease / reassured. System Features： ★ Structured on an intelligent application of the Internet, low operating costs.

  • Page 4: Product Introduction

    1. Product Introduction 1.1 8810S – RF IoT Camera Photoresistor Infrared lights Lens Indicator Light Speaker Reset Button Microphone USB Power SD Card Slot - 3 -...

  • Page 5: Connecting The Camera To The Internet

    2. Connecting the Camera to the Internet 2.1 Download “ALLCAM” APP Search for the keyword "AllCam” in Google Play/Apple Store. Please download it and install it on your smart phone/tablet. “AllCam” APP Welcome Screen (As Shown Below)- - 4 -...

  • Page 6: Power On The Camera

    2.2 Power on the Camera Connect the power supply to the IoT Camera and plug it into the power outlet. The indicator light on IoT camera will turn red. Please wait 15 seconds for the startup test.，When the indicator light flashes green and orange, camera will be in AP-mode.
  • Page 7 Quick Reminders.. 1. Wi-Fi SSID is the name of the wireless network, set by the router administrator. 2. If the Camera can not find the Wi-Fi network you wish to connect to, please make sure the camera is within the Wi-Fi router’s effective range. 3.

  • Page 8: Adding A Camera (Multiple Cameras)

    Quick Reminders.. Only follow the steps for moving the Camera to another Wireless Network. There’s no need to reset the camera if it will be on the same network. 2. The previously paired sensors should remain after the relocation. In the rare occurance and it dissappears, please re-pair the sensors.
  • Page 9 Quick Reminder.. If you entered the wrong password, simply click on the Camera Icon from the Camera List and it will ask you to re-enter the password. 2.4.2 Adding a Remote Camera 1. Make sure your smartphone/tablet is connected to the internet. 2.

  • Page 10: Resetting The Camera

    2. Snapshot Folder : Click the icon to enter the folder (pictured on the right) 3. Video Record / Stop Video Record（SD card required.） 4. Mute, Listen and Speak Toggle Button 5. Smart Home（IoT Devices） 6. Video Resolution： HD：1280*720、VGA：640*360、QVGA：320*180 7. Pan Cruise (Left and Right), Tilt Cruise (Up and Down).

  • Page 11: Camera Settings

    10. Return: Return to Camera List -Android- -iOS- 3.2 Camera Settings In the Camera List, click the icon to enter Camera Settings. 1. Camera Name 2. Delete Camera 3. Event Viewer – logs all events, for example motion detection. 4. Motion Detection (pictured below) When motion detection is triggered, the Camera will take the snapshot an send it to your preconfigured email, and alert you by push notifications to your smartphone/tablet.
  • Page 12 (1) Enable the Motion Detection (2) Drag your fingers to set your area of motion detection. (3) There are three sensitivity settings to choose from. Sensitivity：Low-Medium-High Quick Reminder.. To record video, the SD card must be inserted beforehand. 5. Video Settings/Configuration – Video (1) Power Frequency: 50Hz, 60Hz.
  • Page 13 password immediately after installation, for security concerns. 7. Email SettingsEmail setting examples: -Gmail SMTP Server Name: stmp.gmail.com Port Number: 465 SMTP Account: Your Gmail. XXX@gmail.com SMTP Password: Your Gmail Password Receiver Email: Who will receive this mail Security Type = SSL/TLS -Yahoo SMTP Server Name: smtp.mail.yahoo.com Port Number: 465...

  • Page 14: Sensors' Diagram

    8. SD Card Safety Remove Please do not remove the SD card while the recording functions are engaged, or the video files may be lost. 9. Video Playback-Replay a recorded video file. (1) Play /Pause (2) Mute On/Off 3.3 Sensors’ Diagram - RF Sensors / Pairing Buttons Indicator Light Indicator Light...
  • Page 15 -LED Smart Bulb -LED Smart Bulb Remote Control Up to 8 of the same sensor can be paired to one of our IoT Camera system; if you need a 9 sensor of the same type you will need a second IoT Camera. Some sensors come with an adhesive tape on the back, simply remove the release liner and install it wherever you’d like to.

  • Page 16: Sensor Pairing

    - Select an online Camera from the Camera List and enter the Live View, then select the “IOT DEVICES” icon (pictured below), to enter the IoT Devices interface. - Press the “Pair” icon and hold the Pairing Button on the sensor for 3 seconds, the indicator light will flash red.
  • Page 17 - Hold the Pairing Button on the Smart Plug for three seconds and then release the button, it will automatically be added to IoT devices if pairing was successful. Pairing Button Pairing Button Pairing Button Pairing Button 3.4.1 Sensor Pairing / Other Devices.

  • Page 18: Sensor Alarm Settings And Applications

    3.5 Sensor Alarm Settings and Applications 3.5.1 PIR Sensor - After pairing the sensor, click “PIR” to enter the settings interface. - Unit: Sensor number, First one is 1，second one is 2, and so on. - Nickname: Modify the name of the sensor; press “set” after you Control Area have renamed the sensor.
  • Page 19 3.5.3 Thermal/Humidity Sensor - After pairing the sensor, click “Thermal/Humidity” to enter the settings interface. - Unit: Sensor number, First one is 1，second one is 2, and so on. - Nickname: Modify the name of the sensor; press “set” after you have renamed the sensor. - Alarm: Enable or Disable the sensor.
  • Page 20 3.5.5 Remote Key After pairing the Key, simply press the center button to turn the alarm system ON/OFF. Pairing ON/OFF Button 3.5.6 LED Smart Bulb Employs “Grouping” concept, easy to use. - After pairing the Smart LED Bulb, enter the settings menu. (Pictured below on left) ○...
  • Page 21 ○ ○ ○ Full White Mode Reading Mode Movie Mode ○ ○ ○ the desired mood Night Light Mode Custom Mode - Preset Mood Light Modes: ○ ○ 5 - are preset modes to choose from. ○ 6 Custom Mode – First double click Custom Mode Button to enter the Custom Mode Menu. (Pictured below, on the left) 3.
  • Page 22 Save Custom Mode Custom Mode Button Custom Mode Setting Successful - Schedule: Time table to choose when to turn LED ON or OFF. 1. Press the Schedule Setting Button to enter the interface. 2. User use the Time Setting Zone to choose when to turn LED ON/OFF 3.
  • Page 23 Quick Reminder.. Maximum number of Smart Bulbs is 8 bulbs, when pairing to one Camera through the APP, with ◆ two groups available for assignment. Maximum number of Smart Bulbs is 16 bulbs, when pairing directly to the Remote Control, with ◆...
  • Page 24 Quick Reminder.. ◆ If an elderly person has fallen down and is unable to move for more than 10 seconds. At this point it is recommended for the person to simply lie down in the detection zone and not move. In order to trigger the sensor and result in a push notification alert.
  • Page 25 Sensor Area of Effectiveness Illustration ▲ ★ Please make sure to pair the sensor within 2m of camera, place the sensor elsewhere after you have finished pairing the sensor. ★ Please remember the sensor must be paired before installation. - 24 -...

  • Page 26: Faq

    4. FAQ (1) Unable to connect to the Camera under the same Router/Network. ● Please ensure the power supply has been plugged in. ● Please ensure the Camera is up and running, and the indicator light is green. ● Please ensure the Camera and the Smartphone/Tablet is within the effective range of each other. ●...
  • Page 27 ● Avoid dropping the camera, as the impact will damage both the enclosure and the circuits. ● Operate using only the accessories and power supply that came with the original packaging. ● Do not overload the power outlets or extension cords, it will become an electric-shock hazard or fire hazard. - 26 -...
