- Page 1 M1 User Manual Rev. 1.0 Updated on 28th August, 2009 megascan M1 User Manual Rev. 1.0 Model: megascan M1 Technical Contacts and Enquiry: sales@scanmega.com Website: www.scanmega.com (This user manual / product specification is subjected to be changed without prior notice)
-
Page 2: Table Of Contents
Updated on 28th August, 2009 Table of Content FCC statement..................... 3 CE statement ....................... 3 Chapter 1 Introduction of megascan M1 ............4 Overview of megascan M1 ..............4 Ports Description ................5 Indicators LEDs in megascan M1 ............. 6 Antenna for megascan M1 .............. -
Page 3: Fcc Statement
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 FCC statement FCC NOTICE: To comply with FCC part 15 rules in the United States, the system must be professionally installed to ensure compliance with the Part 15 certification. It is the responsibility of the operator and professional installer to ensure that only certified systems are deployed in the United States. -
Page 4: Chapter 1 Introduction Of Megascan M1
Chapter 1 Introduction of megascan M1 1.1 Overview of megascan M1 The Megabyte Ltd., megascan M1 RFID reader does more than simply read and acts as a data conduit, they need processing speed and ample memory. is an UHF RFID reader,... -
Page 5: Ports Description
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 1.2 Ports Description The megascan M1 has several types of input/output port: Items Name Description Ethernet Port, RJ-45 10BaseTx/100BaseTx port that connects the reader to your Ethernet network, which is embedded with Power over Ethernet (PoE) Technology. -
Page 6: Indicators Leds In Megascan M1
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 1.3 Indicators LEDs in megascan M1 The megascan M1 has different LEDs to indicate the reader status. Name Label Description LAN Status, 10BaseTx Turn ON when 10Mbps network detected... -
Page 7: Antenna For Megascan M1
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 1.4 Antenna for megascan M1 There is no antenna shipped with megascan M1. The following antenna model is used for megascan M1: MRD E42 Technical Contacts and Enquiry: sales@scanmega.com Website: www.scanmega.com... -
Page 8: Product Features
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 1.5 Product Features Excellent RFID monostatic RF performance with 17 external SMA antenna ports, • 1 Watt (30dBm) Tx output levels and -80dBm Rx read sensitivity, • Consistently supports read ranges up to 30 feet, •... -
Page 9: Specification
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 1.6 Specification: Compliant with EPC global C1G2/ISO 18000-6C, Dense Reader Mode Capability, Adjustable Output Power (up to +30dBm Max), Features Exceptional Performance and Reliability, Low Power Consumption, Read Distance up to 30 feet(9m),... -
Page 10: Chapter 2 Installation Of Megascan M1
Updated on 28th August, 2009 Chapter 2 Installation of megascan M1 2.1 Power up megascan M1 This section explains how to set-up megascan M1 and connect the megascan M1 to your network and antenna: Choose the PoE feature router/switch and compliance with IEEE std. -
Page 11: Start Up Procedures
5. Please make sure the antenna port is connected an UHF antenna before turn on the RF power for testing. Caution: Each port must have either an antenna or a terminator connected. Do not apply power to the megascan M1 unless an antenna or terminator is installed on each antenna port. 2.4 Caution... -
Page 12: Professional Installation Instructions
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 Professional Installation Instructions Safety and Regulatory Compliance Information This document contains important safety and regulatory compliance information for the following products: Please read this document before installing and using your product and see the following sections for more information: •... - Page 13 M1 User Manual Rev. 1.0 Updated on 28th August, 2009 Federal Communications Commission (FCC) Compliance These products operate at the following frequencies in compliance with Part 15 of the FCC rules: RFID; 902 MHz - 928 MHz, Operation is subject to the following two conditions: 1) this device may not cause harmful interference, and 2) this device must accept any interference received, including interference that may cause undesired operation.
- Page 14 User Manual Rev. 1.0 Updated on 28th August, 2009 FCC criteria. The megascan M1 shall be installed & used such that parts of the user’s body ther than the hands should be maintained at a comfortable distance of approximately 25 cm or more.
-
Page 15: Chapter 3 Demonstration Of Rfid Applications
Chapter 3 Demonstration of RFID Applications 3.1 Creating RFID Application with megascan M1 Megabyte Ltd. megascan M1 is an intelligent reader and compliance with EPC global C1G2/ISO 18000-6C , Users can develop own UHF RFID application on this platform. 3.1.1 Delivering Application to megascan M1 When the user wants to deliver applications to the megascan M1, they just simply install the program in Windows XP and Linux platform. -
Page 16: Chapter 4 Regulatory Information
(such as co-located antennas transmitting the same information) is expressly forbidden. WARNING: DO NOT ATTEMPT TO SERVICE THE WIRELESS COMMUNICATION DEVICE YOURSELF. SUCH ACTION MAY VOID THE WARRANTY. THE MEGASCAN M1 IS FACTORY TUNED. NO CUSTOMER CALIBRATION OR TUNING IS REQUIRED. CONTACT MEGABYTE LTD. TECHNICAL... -
Page 17: Radio Frequency Radiation Exposure
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 4.1.1 Radio Frequency Radiation Exposure The highest RF output power of the unit was measured at 29.60dBm at 902.75 MHz. According to §1.1310 of the FCC rules, the power density limit for General Population/Uncontrolled Exposure at 902.75 MHz is f... -
Page 18: Ce Compliance
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 4.2 CE Compliance This device has been tested to and conforms to the regulatory requirements of the European Union and has attained CE Marking. The CE Mark is a conformity marking consisting of the letters "CE". -
Page 19: Chapter 5 Disclaimer Notice
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 Chapter 5 Disclaimer Notice Disclaimer Notice The manufacturer shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance or use of this material. -
Page 20: Chapter 6 Warranty
The Warranty Period shall not be extended by reason of any repair or replacement. Megabyte Ltd shall have no liability to the User for any damage to or defects in any of the Products caused by fair wear and tear, improper use, negligent handling, failure to observe... -
Page 21: Chapter 7 Support
M1 User Manual Rev. 1.0 Updated on 28th August, 2009 Chapter 7 Support Technical support/sales enquiry can be obtained from Megabyte Ltd. Please email to: sales@scanmega.com Technical Contacts and Enquiry: sales@scanmega.com Website: www.scanmega.com (This user manual / product specification is subjected to be changed without prior notice)
