- Page 1 Palladia® Manuale utente User manual Benutzerhandbuch Manuel utilisateur Manual del usuario 05146 20.05.2013...
- Page 2 Risk of explosion if the battery is replaced with a model (red is working) downwards different from that specified. Dispose of the used battery in the appropriate containers. Keep out of reach of children CORRADI SPA - USER MANUAL - PALLADIA 28 of 121 20.05.2013...
- Page 3 (433,92 MHz) with 2 channel emitter. Required for a 4 runner awning, tilted version, which guarantees constant correct tension despite changes in fabric properties caused by differing environmental circumstances. 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 29 of 121...
- Page 4 Fixing plate lower bracket Runner kit Lower bracket Pillar Pillar foot ELECTRIC DRIVE TYPE 1 ELECTRIC DRIVE TYPE 2 00775-1 PLAN Motor reducer 00775-2 SLOPE Motor reducer 00749 MONO Exchange CORRADI SPA - USER MANUAL - PALLADIA 30 of 121 20.05.2013...
- Page 5 Fixing plate lower bracket Lower bracket Runner kit Foot Pillar foot ELECTRIC DRIVE TYPE 1 ELECTRIC DRIVE TYPE 2 00775-1PLAN Motor reducer 00775-2 SLOPE Motor reducer 00749 MONO Exchange 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 31 of 121...
- Page 6 Lower bracket Runner kit Pillar ELECTRIC DRIVE TYPE 1 ELECTRIC DRIVE TYPE 3 Pillar foot 00775-1 PLAN Motor reducer 00775-2 SLOPE Motor reducer 00775-3 SLOPE Motor reducer 00757 TANDEM Exchange CORRADI SPA - USER MANUAL - PALLADIA 32 of 121 20.05.2013...
-
Page 7: Troubleshooting
Possibly broken belts, or disconnection from drive shaft. Contact dealer. The awning moves erratically. Dirty runners, runners not properly aligned. Clean the runners (see instructions in chapter on maintenance). Realign the runners. 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 33 of 121... -
Page 8: Products Features
Thank you for choosing a Corradi product. We invite you to look at the table below, which shows the characteristics of components and materials used in Corradi Group products: Pergotenda®, sail awnings, outdoor furniture. These features identify the materials’ peculiarities and shouldn’t be considered as manufacturing imperfections. - Page 9 In case of very heavy rainfall it is possible that the gutter is not able to drain the water. This may cause water infiltrations. The water-conducting to the ground may not be controlled by Corradi SpA, but by the final customer. The installation conditions, slopes and any collection wells, are the sole responsibility of the final customer.
- Page 10 Posting - Veneer: the coating film lifts from the substrate in form of small flakes CORRADI SPA - USER MANUAL - PALLADIA 36 of 121 20.05.2013...
- Page 11 After some time from the installation and if no periodic maintenance is performed on the runners, as indicated in the manual, Noise on the runners soon after the installation is is considered there may be noise in the runners and sliders. a default. 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 37 of 121...
-
Page 12: Maintenance
1. Warning: the runners should never be lubricated under any circumstances. CORRADI SPA - USER MANUAL - PALLADIA 38 of 121 20.05.2013... - Page 13 Width (cm) runners 400~500 550~600 650~700 750~900 950~1050 PALLADIA flat 2 runners 3 runners 4 runners 1050 PALLADIA tilted 1300 Values in cm for the maximum size of single canvases 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 39 of 121...
- Page 14 TABLE 6 - MINIMUM SLOPE (minimum values in cm for single canvas tilted Palladia) Width (cm) 1000 1050 1100 1150 1200 1250 1300 2 runners 3 runners 4 runners CORRADI SPA - USER MANUAL - PALLADIA 40 of 121 20.05.2013...
-
Page 15: Warranty
The warranty starts from the date on which work ends with delivery PALLADIA FLAT VERSION must be fixed to a suitable supporting wall of the User Manual and, in any case, from the date on which Corradi According to art. 1495 sub-section 1 and 1511 sub-section 1 of the... - Page 16 Products directly or indirectly sold, installed or granted for commodate to customers outside the client’s domicile ar e specifically excluded from warranty unless agreed in writing by Corradi Srl. CORRADI SPA - USER MANUAL - PALLADIA 42 of 121...
- Page 17 CE MARKING CE MARKING PALLADIA 2-3-4-5 RUNNERS VERSIONS Corradi Srl - Via G. Brini, 39 - 40128 Bologna Italy Model: PALLADIA 2-3-4-5 runners Serial nr: 00000/00 Year of production: 0000 Power supply: 230 V ~ Power: 218 W Number of phases: 2...
-
Page 18: Ce Declaration Of Conformity
The Installer fills out and signs the DECLARATION OF CORRECT INSTALLATION AND CLASSIFICATION OF WIND RESISTANCE, in accordance with the model in the USER HANDBOOK. The person authorised to draw up technical documentation is: EngineerGianmarco Biagi C/o sede Corradi via Brini, 39 40128 Bologna THE MANUFACTURER I declare that the above described product conforms to the indications and requirements in the above mentioned Directives. - Page 19 B with a screwdriver and turn slightly to release, to store the limit switch position and quit the procedure. Insulated extend Insulated retract button 230 V button 230 V WIRE TYPE FG70R 3X1,5 mmq 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 45 of 121...
- Page 20 Press push-button B* on the motor body with a screwdriver, turning it slightly in order to secure the push-button. Insulated extend Insulated retract button 230 V button 230 V WIRE TYPE FG70R 3X1,5 mmq 46 of 121 CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013...
- Page 21 You can cancel all the remote control codes by pressing the CANC button (6) and waiting for the LED (5) to stay permanently red. Push-button panel maintained, supplied and installed by an electrician. Positioned within the awning’s operating field 20.05.2013 CORRADI SPA - USER MANUAL - PALLADIA 47 of 121...
- Page 22 You can cancel all the remote control codes by pressing the CANC supplied and installed by an electrician. button (6) and waiting for the LED (5) to stay permanently red. Positioned within the awning’s operating field 48 of 121 CORRADI SPA - USER MANUAL - PALLADIA 20.05.2013...
- Page 23 Voiles d’ombrage T +39 0543 796617 F +39 0543 794339 Sonnensegel E velombra@corradi.eu Velas de sombra Corradi Arredi Srl Arredamento per esterni e complementi 28/30, Via Jesi Outdoor furniture and accessories 61122 Pesaro Italy Ameublement d’extérieur et accessoires T +39 0721 287503 F +39 0721 220354 Außenausstattung und Komplemente...
