NetEngine
6000 and 7000 Family
TM

User Guide

Version 3.5
Verilink Corporation
127 Jetplex Circle
Madison, Alabama 35758
http://www.verilink.com
Copyright 2003 Polycom, Inc. All rights reserved.
NetEngine
7000 Family, ACOS
, Advanced Communications Engine
, and Atlas Communication Engines, Inc., are trademarks of Polycom, Inc. All other brand or
TM
TM
TM
product names are trademarks or registered trademarks of their respective companies or organizations. The information in this document is believed to be accurate.
No responsibility is assumed for errors or omissions. Verilink Corporation reserves the right to make changes without notice.
Part #: 3150-30626-001 Rev F
