INSTALLATION INSTRUCTIONS DMX-512 CONTROL CONNECTION DMX-512 CONNECTION WITH DMX TERMINATOR DEVICE DMX START ADDRESS SELECTION OPERTING INSTRUCTIONS OF THE INTERNAL DMX WIRELESS SYSTEM 10. DISPLAY 10. DMX PROTOCOL 11. ERROR MESSAGES 12. CLEANING AND MAINTENANCE MAGICBLADE FX User Manual XM1398-V1.0-NR...
• Make sure the power cord is never crushed or damaged by sharp edges. Should the power cord suffer If this should be the case, replacement of the cable must be done by an MAGICBLADE FX User Manual XM1398-V1.0-NR...
If this device is operated in any way different to the ones described in this manual, the product may suffer damage and the warranty becomes void. Furthermore, any other operation may lead to short-circuits, burns, electric shocks etc. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Upgrades: fast and convenient through DMX cable Reset DMX address, remote lamp switch, reset can all be done by the controller OTHER SPEC Input signal isolation: guarantees stable signal transmission without interference Advanced RDM function WHIGHT Net weight: 13 kg MAGICBLADE FX User Manual XM1398-V1.0-NR...
5) Down-button 6) Enter-button 7) Right-button 8) Up-button 9) Antenna – Wireless DMX 10) 5-Pin DMX out 11) 5-Pin DMX in 12) RJ45 out 13) RJ45 in 14) Fuse 15) Power out 16) Power in MAGICBLADE FX User Manual XM1398-V1.0-NR...
Improper installation/ rigging can result in serious bodily injury. • Before rigging make sure that the installation area can hold a minimum point load of 10 times the device’s weight. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 9
• Pull the safety cable through the holes on the bottom of the base and over the trussing system or another suitable rigging point. Insert the end into the carabiner and tighten the safety screw. Important: This step is very important to ensure safe rigging of the fixture. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 10
If you lack these qualifications, do not attempt the rigging of this device yourself. Improper installation/ rigging can result in serious bodily injury. MAGICBLADE FX User Manual XM1398-V1.0-NR...
“listen” to the digital control information sent out from the DMX controller. The allocation of this starting address is achieved by setting the correct address number on the display located on the base of the device. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Initially, the indicator on the receiver fixture should be in Solid red b) Press and hold the configuration button on transmitter for less than 3 seconds the red/green LEDs on the transmitter and the receiver fixture will flash rapidly for about 5~ 10 MAGICBLADE FX User Manual XM1398-V1.0-NR...
The Display does not need external power to operate. Hold down the -button for 3 seconds and the Display will turn on by using the unit’s battery built in battery. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 14
Act & Data Out Act&Data Out Reset Wireless DMX Mem Rest WDMX DMX value display Trigger DMX Value Disp. PAN…… Slave setting Set To Slave Slave1,Slave2,Slave3 Auto program Auto Program Master / Alone ResetDefault ON/OFF Restore factory set. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 15
2.The display shows “User Mode” , Press <Up/Down> button, then you can choose “Edit User Mode A”, “Edit User Mode B” and “Edit User Mode C”. 3.Press <ENTER> to confirm or press <MODE/ESC> to exit MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 16
5. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. Tilt Reverse With this function you can reverse the Tilt-movement. 1. Access the main menu. 2. Press <Up/Down>, the display will show“Tilt Reverse”. 3. Press< ENTER>, the display will show“Tilt Reverse”. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 17
This device is RDM ready. RDM stands for "remote device management" and makes remote control of devices connected to the DMX-bus. ANSI E1.20-2006 by ESTA specifies the RDM standard as an extension of the DMX512 protocol. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 18
1.Tap <MODE/ESC> button,access the main menu,Tap the <Up/Down> button until “Personality” is displayed. Press < ENTER>, the display will show “Personality”. Tap the <Up/Down> button until the display will show “Display Setting”. Press ENTER, the MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 19
2.Press <Up/Down>, the display will show“Temp. C/F”. 3.Press< ENTER>, the display will show“Temp. C/F”. 4.The display show “Fahrenheit”,Press <Up/Down>, the display will show “Celsius”. 5.Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 20
2. Tap the <Up/Down>button until“Auto Program”is displayed. 3. Press ENTER, the display will show“Auto Program”. 4. Tap the <Up/Down>button,the display will show “Master1”, ” Alone”. 5. Press ENTER to confirm or press <MODE/ESC> to return to the main menu. 9.3.12. ResetDefault MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 21
4. Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. Clr Last Run With this function, you can clear last run time of the fixture. The display shows “ON” or “OFF”, Press “Enter” to confirm. 1. Access the main menu. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 22
2.Press <Up/Down>, the display will show “Test Channel”. 3.Press< ENTER>, the display will show “Test Channel”. 4.The display show “Pan Moving”frist channel, Press <Up/Down>, can choose other channel. 5.Press <ENTER> to confirm or press <MODE/ESC> to return to the main menu. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 23
6.The editor of the scene, there are as many as 250 scenario editors, and every scene can have a program connection of 10. Note: Part 2, Part 3 repeat in accordance with the Part1’s repeat. For example: When Part 1 MAGICBLADE FX User Manual XM1398-V1.0-NR...
No rotation 194-255 Backwards Pan rotation from slow to fast Tilt Motor continuous rotation no function 0-127 128-189 Forwards Tilt rotation from fast to slow 190-193 No rotation 194-255 Backwards Tilt rotation from slow to fast MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 25
Led trun off 32-63 Led turn on 64-95 Strobe effect slow to fast 96-127 Led turn on 128-159 Pulse-effect in sequences 160-191 Led turn on 192-223 Random strobe effect slow to fast 224-255 Led turn on MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 26
65-69 Steel Blue 70-74 Orange 75-79 Straw 80-84 Pale Lavander 85-89 Pink 90-94 95-99 Green 100-104 Blue 105-109 Rainbow1 110-114 Rainbow2 115-119 Rainbow3 120-124 Rainbow4 125-129 Rainbow5 130-134 Rainbow6 135-139 Rainbow7 140-144 Rainbow8 145-149 Rainbow9 MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 27
Slow to Fast Forward Chase Fade: 0-255 Fade Chase Zoom : 0-255 Zoom adjustment from 15 to 60 Zoom Fine : 0-255 Fine control for Zoom adjustment Reset, internal programs: 0-79 Normal 80-84 All motor reset MAGICBLADE FX User Manual XM1398-V1.0-NR...
2) There must not be any deformations to the housing, lenses, rigging and installation points (ceiling, suspension, trussing). 3) Motorized parts must not show any signs of wear and must move smoothly without issue. MAGICBLADE FX User Manual XM1398-V1.0-NR...
Page 29
Should you need any spare parts, please order genuine parts from your local dealer. Remark: Errors and omissions for all information given in this manual are excepted. All information is subject to change without prior notice. MAGICBLADE FX User Manual XM1398-V1.0-NR...
