- Page 1 USER MANUAL WIDE AREA iP 2WAY RADIO MODEL: TA-388...
- Page 2 FRONT LEFT • W ith the radio switched off and charger 1. Antenna connected via the micro USB port, the 2. Speaker LED will turn Red while charging. 3. Microphone • When fully charged the LED will turn blue. 4. LED Flashlight 6. Power Switch and Volume Control 5. Indicator Lamp 7. LCD Indicator • W hen first powered on: LED will flash Blue while radio powers up. 8. MENU Key Displays the menu or functions select. • A rapid Blue flash will start once a valid network is detected and radio ‘Logs In’. 9. BACK Key B ack to the previous menu or Cancel • O nce logged into the network, blue flash will to stop the current operation.
- Page 3 RIGHT BACK 13. P1 Key 17. Orange Key Short press – Toggles on/off LED flashlight. 14. P2 Key 18. PTT (Push-to-Talk) Switch 15. P3 Key 19. Up Key 16. P4 Key S hort press – Moves cursor in some • P 1 to P4 are programmable quick access menu options to top of list. preselects for group or individual member calls. 20. Down Key /Key Pad Lock S hort press -- Moves cursor in some • A long press can store the current menu options to bottom of list. chosen group or group members in the corresponding key. A short press of the Long Press toggles Key Pad lock on/off. key will recall the group or group members 21. Speaker jack stored in the keys. 22. Microphone jack •...
- Page 4 Basic Operations Power on Group Switching Turn on/off volume switch clockwise to power 1. P ress the ‘MENU’ key and then push ‘OK’ on. to select ‘Choose Group’. 1. L ed will flash blue as the TA-388 2. S hort press G or H, to choose the group powers up you want to use. 2. L CD will display Logo and 3. Push ‘MENU’ (Add) to select Startup p Welcome message 4. T he LCD display will now indicate the 3. L CD will display ‘Landing’ text once a group the radio will transmit to when network is identified (This can take 20 pushing the PTT.
- Page 5 Advanced Functions SMS Function Backlight Mode The radio can receive SMS text messages. The backlight can be set in ‘Setting’ Menu. On receipt of a text message an icon (Double It can be set to: Envelope) will display the top blue status line of Auto: B acklight will turn on automatically the LCD. To read message:- when any key is pressed or if radio 1. Press ‘MENU’ key. receives a transmission. If there is no operation for 10 seconds, Backlight will 2. S hort press G or H, and choose the turn off automatically. ‘Dispatcher MSG’ from list. Press ‘OK’ Keys: B acklight will not turn on when the 3. S hort press G or H, choose the message you PTT is pressed or radio receives a want to read then press ‘OK’ key to read. transmission. Backlight will turn on if any other key is used and remain on for 4. P ress the “BACK” key to return to the 10 seconds.
- Page 6 Warranty Product type warranty This warranty against defects is given by Tooo Air Pty Ltd ABN 58 615 252 536 2.3 T o the extent permitted by law, our sole liability for breach of a condition, 1. Consumer guarantees warranty or other obligation implied 1.1 O ur goods come with guarantees by law is limited that cannot be excluded under (a) i n the case of goods we supply, to any the Australian Consumer Law. one of the following as we decide - You are entitled to a replacement or refund for a major failure and ( i) the replacement of the goods or for compensation for any other the supply of equivalent goods; reasonably foreseeable loss or (ii) the repair of the goods; damage. You are also entitled to have the goods repaired or replaced if the ( iii) the cost of repairing the goods or goods fail to be of acceptable quality of acquiring equivalent goods;...
- Page 7 Tooo Air Pty. Ltd. (d) g oods improperly installed or used Suit 2, Level 2 in a manner contrary to the relevant 175 Macquarie Street instruction manual; or Sydney NSW 2000. (e) g oods where the serial number has been Tel: (02) 9157 0540 removed or made illegal. Email: info@toooair.com.au 4. Warranty period The warranty on the ToooAir TA-388 Wide Area iP 2 Way Radio and Power Adapter is 12 Months. No repair or replacement during the warranty period will renew or extend the warranty period past the period from the original date of purchase. Important Notice READ ALL INSTRUCTIONS carefully and completely before operating your radio and retain this manual for future reference. NEVER connect the radio to a power source other than the supplied battery and charge via supplied charger. DO NOT place your radio in front of a vehicle airbag. DO NOT attempt to modify your radio in any way. ALWAYS charge your radio at normal room temperature.
- Page 8 Tooo Air Pty. Ltd. S uite 2, Level 2 175 Macquarie Street Sydney NSW 2000 Phone: +61 2 9157 0540 Web: www.toooair.com.au Email: info@toooair.com.au...
