  • Page 1 PolyVision ēno play ® ® Installation and Operation Guide Part number 2002480-001 Rev C ©2012 PolyVision Corporation All rights reserved...
  • Page 2: Table Of Contents

    ēno play Table of contents Overview ................................ 3 What is ēno play? ............................3 Register your PolyVision product ........................ 3 Install ēno play ............................... 4 Important considerations ..........................4 Driver pack positioning ..........................4 Amplifier positioning ..........................4 Power and audio input cable length considerations ................. 4 Cable routing options to the amplifier .......................
  • Page 3: Overview

    ēno classic 2610/2810 or ēno classic 2615/2815 with all ēno one products (i.e. adjustable mobile stand, adjustable wall mount, or fixed wall mount) The PolyVision driver version 2.2.2 or higher is required on the computer you use for ēno play and interactive whiteboard features. Refer to “Install the PolyVision driver”.
  • Page 4: Install Ēno Play

    Power and audio input cable length considerations PolyVision provides a audio input cable with ēno play. Determine the cable path from the ēno play amplifier to the audio source. If the distance to your audio source is longer or considerably shorter, obtain alternate audio input cables from a third party.
  • Page 5: Adjustable Height Mobile Stand And Wall Mount Considerations

    Adjustable height mobile stand and wall mount considerations If the ēno classic whiteboard is mounted using some older adjustable height solutions, PolyVision provides a driver pack offset kit that must be added to the driver packs before they are fastened to the whiteboard.
  • Page 6: What Comes In The Box

    ēno play What comes in the box 1 Driver pack mounting template 2 ēno play Quick Reference Guide 3 #10 x 1/2” fasteners (x6) 4 #8 x 1/2” fasteners (x6) 5 Upper whiteboard bracket extender 6 Lower whiteboard bracket extender 7 Foam pads 8 Cable tie holders (x10) 9 Power cable and adapters...
  • Page 7: Prepare The Ēno Classic Whiteboard

    Note: Cable management is important. The cables between the driver packs and the amplifier and any other cables routed against the back of the whiteboard must be secured by cable ties as described in “Add cable ties and tape”. PolyVision 2002480-001 Rev C 7 of 38...
  • Page 8: Cable Routing For Whiteboards Mounted Directly To The Wall

    Before beginning to install the ēno play components, measure and plan cable routing for the ēno play amplifier power source and audio input. PolyVision provides a 25 ft (7629 mm) audio input cable, and a power connector with a 6 ft (1829mm) cable plus a 10 ft (3048mm) power cable extension.
  • Page 9: Cable Routing For Adjustable Height Mobile Stand Or Wall Mount Options

    ēno 2610 requires 27” (685mm) audio and power service loop • ēno 2810 requires 35” (889mm) audio and power service loop Note: For details, refer to “Option: Cable management for adjustable height systems”. PolyVision 2002480-001 Rev C 9 of 38...
  • Page 10: Install The Driver Packs

    Note: If your ēno classic whiteboard is mounted using some older adjustable height mobile stands and adjustable height wall mounts, PolyVision provides driver pack offset kit. If ēno play components include the driver pack offset kit, skip to “Install the driver pack with driver pack offset kit ”.
  • Page 11 7. While holding the driver pack tabs against the template notches, rotate the drive pack adhesive into contact with the whiteboard. 8. Press hard on the driver pack for 15 seconds. PolyVision 2002480-001 Rev C 11 of 38...
  • Page 12: Install The Driver Pack With Driver Pack Offset Kit

    Note: If your ēno classic whiteboard is mounted using some older adjustable height mobile stands and adjustable height wall mounts, PolyVision provides driver pack offset kit. If ēno play components include the driver pack offset kit, use the steps below to install the driver packs.
  • Page 13 2. Slide the driver pack adapter mounting template to the upper left corner of the back of the whiteboard and tape it in place. Note: The template has a front and back side. Be sure to use the template front in the upper left corner. PolyVision 2002480-001 Rev C 13 of 38...
  • Page 14 ēno play 3. Select the template location that is appropriate for your installation based on the instructions you see on the template. 4. Using an alcohol wipe, clean the area about 3” (76mm) below the correct template location. 5. Orient the driver pack with the wires facing the floor. Note: Use care when mounting the amplifier and driver packs to the back of the whiteboard.
  • Page 15 9. Press hard on the driver pack for 15 seconds. 10. Reverse the template and tape it to the upper right corner of the whiteboard. 11. Repeat steps 1 through 9 to install the second driver pack. PolyVision 2002480-001 Rev C 15 of 38...
  • Page 16: Install The Amplifier

    ēno play Install the amplifier Important Note: The location of the amplifier is important. Install the amplifier in either the lower left or the lower right corner of the whiteboard and no other location. To install the amplifier: 1. Determine which side of the whiteboard provides the best access for audio input and power to the amplifier.
  • Page 17: Add Cable Ties And Tape

    Cable management for adjustable height systems”. Install cable ties for the driver pack cables To secure the driver pack cables, add one cable tie below each driver pack: 1. Remove self-adhesive back from a tie holder. PolyVision 2002480-001 Rev C 17 of 38...
  • Page 18: Install The Amplifier Cable Tie

    ēno play 2. Position the tie holder one inch below a driver pack and one inch towards the center of the board so the tie holder holes to run approximately vertical and horizontal with the board. 3. Press the tie holder to the board. 4.
  • Page 19: Install A Cable Tie At The Center Of The Whiteboard

    2. Position the tie holder about one inch below the horizontal line created by the two driver pack tie holders so the tie holder holes to run approximately vertical and horizontal with the board. 3. Press the tie holder to the board. PolyVision 2002480-001 Rev C 19 of 38...
  • Page 20: Install A Cable Tie Between The Center And Bottom Of The Board

    ēno play 4. Install a tie wrap through the horizontal holes in the holder and capture both driver pack cables (and the power supply and permanent audio input cables if appropriate for your installation). Refer to “Plan power and audio input cable routing”. center cable tie 5.
  • Page 21: Install Cable Ties For Power Or Audio Cable Routing Options

    Note: To install optional cable ties for your adjustable height mobile stand or wall mount, refer to “Cable routing for adjustable height mobile stand or wall mount options” and “Option: Cable management for adjustable height systems”. PolyVision 2002480-001 Rev C 21 of 38...
  • Page 22: Tape Cables To The Back Of The Whiteboard

    ēno play Tape cables to the back of the whiteboard To prevent any interference with ēno play audio from unwanted vibrations, tape cables to the back of the whiteboard. To tape cables to the back of the whiteboard: 1. Use tape provided to attach cables to the board. Tape can be torn with fingers or cut with scissors.
  • Page 23: Option: Cable Management For Adjustable Height Systems

    Note: Choose cable paths to avoid pinch points. 4. Cover cables below the turret base using the split corrugated conduit that is provided with the adjustable height system. PolyVision 2002480-001 Rev C 23 of 38...
  • Page 24 ēno play 5. Mount the whiteboard to the adjustable height system and fasten it to the brackets using two #10 x 1/2” fasteners, provided. 6. Lower the lift system to its lowest position. 7. Route the cable down to the amplifier, making sure that the cable passes between the lift system tubular support structure and the whiteboard, as shown below.
  • Page 25 To route power or permanent audio input to the amplifier from below the adjustable height lift system: 1. Assure that the cable is long enough to allow for raising and lowering the adjustable height system. PolyVision 2002480-001 Rev C 25 of 38...
  • Page 26 ēno play 2. Mount the whiteboard to the adjustable height system and fasten it to the brackets using two #10 x 1/2” fasteners, provided. 3. Lower the lift system to its lowest position. 26 of 38 2002480-001 Rev C Installation and Operation Guide...
  • Page 27: Option: Install Whiteboard Wall Bracket Extenders For Fixed Wall Mounts

    Option: Install whiteboard wall bracket extenders for fixed wall mounts Important Note: Do not install the wall bracket extenders if the whiteboard mounts to an adjustable height mobile stand or adjustable height wall mount. PolyVision 2002480-001 Rev C 27 of 38...
  • Page 28 ēno play To install wall bracket extenders: 1. Assure that the whiteboard wall brackets are already fastened to the wall using instructions provided with your whiteboard mounting solution. 2. Back out each of the screws that fasten the wall bracket to the wall by 1/8”. 3.
  • Page 29: Connect Cables And Verify Amplifier Operation

    6. Assure that vibrations from loose components do not interfere with the audio. Add foam strips to prevent unwanted vibrations Test the sound from your system. If you detect unwanted vibrations, PolyVision provides four foam strips for sound damping. To damp unwanted vibrations using the foam strips provided: 1.
  • Page 30: Removing And Replacing The Cable Tie Holders, Driver Packs Or Amplifier

    ēno play Removing and replacing the cable tie holders, driver packs or amplifier The adhesive backing on the driver packs and amplifier create a tight bond to the whiteboard. Additional self-adhesive strips are provided in case you need to remove and replace a component. To remove and replace a driver pack, amplifier or cable tie holder: 1.
  • Page 31: Install The Polyvision Driver

    ēno play Install the PolyVision driver NOTE: Install the PolyVision driver version 2.2.2 or higher to control ēno play audio from the whiteboard. System requirements Your Windows-based computer must have: • 500 MHz Pentium processor • 512 MB Ram •...
  • Page 32 9. Follow the prompts you see on the screen to complete the installation. To install the PolyVision driver on a Macintosh: 1. Insert the PolyVision Getting Started CD in your computer. 2. Double-click “My Computer” on your desktop. 3. Double-click the disk Macintosh folder to open it.
  • Page 33: Operating Ēno Play

    ēno play amplifier. Software options PolyVision driver (version 2.2.2 or higher) enables the ēno interactive whiteboard computer to pass microphone input directly to ēno play, bypassing the need to use the input device’s software. To enable or disable the computer’s mic for ēno play: 1.
  • Page 34: Using The Guest Audio Input Connector

    ēno play Using the guest audio input connector The ēno play amplifier provides two audio input connectors: permanent and guest. The permanent audio input connector is located facing the center of the whiteboard. The guest audio input connector is located at the edge of the whiteboard for easy access to temporary connections.
  • Page 35: Warranty

    During the warranty period, and upon proof of purchase, the product will be repaired or replaced (with the same or similar model) at PolyVision’s option, without charge for either parts or repair labor. Shipping costs will apply. Please keep your original sales receipt or delivery invoice for proof of purchase.
  • Page 36: Limitation Of Damages And Implied Warranties

    Software, the application, customer data, and operator control of products are considered to be compatible with many systems. The specific suitability of a product for a specific purpose or application must be determined by the customer and is not warranted by PolyVision Corporation.
  • Page 37: Specifications

    Amplifier Power supply • Output power: 24VDC; 1.88A • Input power: 100-240 VAC; 50/60Hz • PolyVision Replacement# 2002532-001 • Mfg# K-Tec KSAS0452400188D5 Driver Pack • Size: 5.9" L x 2.4" W x 0.9" D (152.0mm L x 60.0mm W x 22.9mm D) •...
  • Page 38: Index

    ēno play Index adjustable height system cable management, 21 on-line registration, 3 amplifier cable tie, 18 PolyVision driver installation, 27 amplifier installation, 15 register with PolyVision, 3 amplifier status LED, 29 removing driver packs or amp, 25 audio input devices, 29...
