- Page 1 PTV Coax Pro IPTV Coax Pro ™ USER MANUAL 20584/ 20131021 • IPTV Coax Pro ™ ALL RIGHTS RESERVED MARMITEK ©...
-
Page 3: Safety Warnings
Never connect an adapter or power cord when it is damaged. In that case, contact your supplier. 1. INTRODUCTION Congratulations on the purchase of your IPTV Coax Pro™. It helps you create an additional network connection (IP/internet) on your (existing) coaxial network, in any room with a coaxial connection. It provides a guaranteed stable high-bandwidth connection for the most demanding HD video streaming equipment. -
Page 4: Operation
3. OPERATION Position the IPTV Coax Pro™ 1P-node where your internet and coaxial cable enters the house. The 1P-node combines the two signals and distributes them across your entire coaxial network. Position an IPTV Coax Pro™ 4P-node at the location where you require a network connection to connect your devices to the internet/IP. - Page 5 Compared to an IEC connector, the F-connector has lower signal loss. To avoid/reduce signal loss, IPTV Coax Pro™ nodes use an F-connector socket. Use IEC- connectors preferably only for loose cables, for example, to connect to your No two coaxial home networks are the same, so in practice, there is an infinite number of different connectivity options.
-
Page 6: Installation
4.3 Connecting the 1P-node (in the meter cupboard) With the exception of the built-in 4-port Ethernet Switch, there are no technical differences between the IPTV Coax Pro™ 1P-node and the 4P- node. In most cases, the 1P-node will be placed in the meter cupboard or at the Demarcation Point (DMARC) where your coaxial cable and internet connection enter your home. - Page 7 (not supplied) with an F-connector. 3. Please note that the (active) signal amplifier does not transfer the signal from the IPTV Coax Pro™ nodes. Therefore, never position it between the 1P-node and the 4P-node. You can leave the To TV unused because the IP/internet signals are also sent to your coaxial network via the 1P-node's COAX IN connector.
- Page 8 LAN ports of the 4P-node. The built-in 4-port switch requires no further configuration. Then connect the power cable to the 4P-node and plug the adapter into the wall outlet. TIP: After installation, use a spanner to check if the F-connectors are sufficiently tightened until finger tight. © MARMITEK...
-
Page 9: Checking The Installation
(security) and reflects the signal back into the coaxial network, improving the signal quality. This filter does not affect your existing coaxial signals such as TV, radio and telephony. Position the coaxial filter directly at the point where the coaxial cable enters your home. IPTV Coax Pro™... -
Page 10: Frequently Asked Questions
5. FREQUENTLY ASKED QUESTIONS Link and Signal Quality lights are not lit The IPTV Coax Pro™ node is unable to make a proper connection with another node on the coaxial network. Make sure the POWER light is lit on all IPTV Coax Pro™ nodes. -
Page 11: Technical Information
6. TECHNICAL INFORMATION IPTV Coax Pro™ node Power adapter: 100~240VAC@50/60Hz, 5VDC 2A Range: max. 100m for RG-59 coaxial cable Coaxial input: F-connector, 75ohm Coaxial output: F-connector, 75ohm RF output level: E-Band, -3dBm D-Band, -10dBm Network connection: 1P-node: 1x 10/100Mbps Ethernet (RJ45) -
Page 12: Optionally Available
7. OPTIONALLY AVAILABLE Additional IPTV Coax Pro™ 4P-node (art. nr. 08185 / 08186) Use your coaxial network to create additional network connections (IP/internet) in multiple rooms of the house (living room, bedroom, office, loft). You can connect up to 16 additional 4P-nodes to your coaxial network.
