Instruction Manual
Electric Patio Heater
VITG008
Thank you for choosing our electric halogen patio heater. This
Instructions Manual will provide you with valuable information
necessary for the proper care and maintenance of your new product.
Please take a few moments to thoroughly read the instructions and
familiarize yourself with all the operational aspects of your new heater.
•
Unpack the electric halogen heater marking sure that all the items
are present and that there are no components left in the box and
that the heater is free from any packing material.
•
Using detailed drawing, follow the steps for assembling your
heater.
•
Do not connect the heater to electrical supply until the assembly is
complete.
•
Do not connect the heater to electrical supply if any of the
components or the power cord is damaged in any way.
•
If in doubt contact your supplier.
Advertisement
Table of Contents
Related Manuals for Heinner VITG008
Summary of Contents for Heinner VITG008
- Page 1 Instruction Manual Electric Patio Heater VITG008 Thank you for choosing our electric halogen patio heater. This Instructions Manual will provide you with valuable information necessary for the proper care and maintenance of your new product. Please take a few moments to thoroughly read the instructions and familiarize yourself with all the operational aspects of your new heater.
- Page 2 9. This heater is not intended for use in bathrooms, laundry IMPORTANT INSTRUCTIONS: areas and similar Indoor locations. Never locate heater When using electrical appliances, basic precautions should where it may fall into a bathtub or other water container. always be followed to reduce the risk of fire, electric shock, 10.
- Page 3 18. Always plug heaters directly into a wall outlet/receptacle. Assembling Process Never use with an extension cord or relocatable power tap To properly assemble this heater, you need the supplied assembly (outlet/power strip). wrench (or one of your own). 19. This unit is designed for a 220V-240V AC electrical outlet STEP 1: connection ONLY.
- Page 4 STEP 4: Connect the top pole with the middle pole by screwing together. . STEP 5: Fix the Table on the Pole by screwing the plastic fixation part. STEP 9: Place the heater head assembly onto the top pole. Secure it with two φ4*8mm screws.
- Page 5 STEP 11: Fix the power cord on the rubber base by using four M4 screws. The electric halogen patio heater is equipped with 3 heating setting: Low, Medium and High. To operate the heater on low (900W), press the switch on the right. ...
-
Page 6: Trouble Shooting
This icon shows that WEEE should not be collected with STORAGE household waste but separately. When not in use, store this unit in a cool, dry location. To We recommend you to consider the following: prevent dust and dirt build-up, use the original packaging to - Materials and components used when manufacturing repack this unit.
