Silent Witness SW002 Manual

SW002
2-CH HD MOBOIL DVR
Digital Video Recorder for CCTV system

Attention:

1. Please don't insert or remove the SDcard, when DVR is working
2. Please use the original power adapter
3. The first time you use an SDcard, first format on a computer, then format it by DVR
4. Keep the device in a dry, well-ventilated place
5. Please use a genuine original high-speed SDcard
7. The device operating temperature range: -20-60 degree

Product Description:

SW002 SD card DVR is a high-performance digital video module, which adopts MPEG-4 video compression
technology, dual-channel simultaneous resolution of up to 640*480/576*30 frames. Low power consumption,
easy operation, ultra-compact professional digital video. This unit supports boot recording , motion
detection recording, manual recording/photo, and other recording/photo mode. The SW002 supports up to
128GB SDcards, recorded video files stored directly in the SDcard. The user can at any time view on a TV,
monitor or computer the files on the SDcard. These files can be stored on the computer.
In addition the SW002 has UART (TTL) serial，ALARM alarm interface and other functions. Built-in power
protection battery, (never lost data). Built-in "electronic watchdog"function, do not crash

Features:

MPEG-4 compression format
