ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE INTENDED FOR RESIDENTIAL USE ONLY.
Warning: If the information in this manual is not followed exactly, a fire or explosion may
!
result causing property damage, personal injury, or loss of life.
• Do not store or use gasoline or other flammable vapors and liquids in the vicinity
of this or any other appliance.
• An LP-cylinder not connected for use shall not be stored in the vicinity of this or
any other appliance.
DANGER: If you smell gas:
!
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. If odor continues, keep away from the appliance and immediately call your gas
supplier or fire department.
• Installation and service must be performed by a qualified installer, service agent,
or gas supplier.
Warning:
Improper installation, adjustment, alteration, service, or maintenance can cause
!
injury or property damage. Read the installation, operating, and maintenance
instructions thoroughly before installing or servicing this equipment.
DANGER
!
Use the correct bolts as indicated. Do not tighten any of the bolts until the table is completely assembled.
Do not sit or stand on this table.
Keep children away during assembly. This item contains small parts that can be swallowed by children.
Do not use indoors or inside any enclosure.
Retain these assembly instructions for future reference.
Installer - Please leave these instructions with the owner.
Quote the following FQC NO. when contacting the service center.
E-2
TRS42GE
CARBON MONOXIDE HAZARD
This appliance can produce carbon monoxide
which has no odor.
Using it in an enclosed space can kill you.
Never use this appliance in an enclosed space
such as a camper, tent, car, or home.
SERVICE CENTER TOLL FREE NO.
TEL: 1-877-539-7436
FAX: 1-877-539-7439
PAGE 1 OF 9
WARNING: For Outdoor Use Only
!
COURTYARD CREATIONS INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TRS42GE and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Courtyard Creations TRS42GE

Summary of Contents for Courtyard Creations TRS42GE

  • Page 1 Retain these assembly instructions for future reference. Installer - Please leave these instructions with the owner. Quote the following FQC NO. when contacting the service center. SERVICE CENTER TOLL FREE NO. TEL: 1-877-539-7436 FAX: 1-877-539-7439 COURTYARD CREATIONS INC. PAGE 1 OF 9...
  • Page 2 This appliance has been tested to and complies WARNING with the ANSIZ21.97 and CSA 2.41-2014. The installation must conform to local codes or in If the appliance is not in use, the gas must be turned the absence of local codes to the National Fuel off at the supply cylinder.

  • Page 3: Parts List

    PARTS LIST PART PART MATERIAL CODE PART Q’TY MATERIAL CODE PART Q’TY TRS42GE-CS04-3 17XY9701------- REAR FRAME FUEL SUPPLY HOSE TRS42GE-CS04-2 67XA4916 RIGHT FRAME COVER TRS42GE-CS04-1 17C40A0714001YX LEFT FRAME BOLT M6*40 62TRS42GEI101 17C40A0705001YX CROSS BRACE BOLT M6*15 TRS42GE-CS10-3 17FA05040301-YX FRONT DOOR WASHER d6.5*D13*1.0...
  • Page 4 FIGURE 2 FIGURE 3 The tab #14 BOLT M6*15 #14 BOLT M6*15 Step 2: Step 3: Insert both ends of the cross brace (#4) into the bottom Fasten the tank support assembly (#7) to the front door grooves of the right and left frames (#2 and #3) from top (#5) by using bolts (#14).
  • Page 5 FIGURE 6 FIGURE 7 Igniter Valve #14 BOLT M6*15 Step 6: Step 7: Place the table top (#6) onto the frame assembly. Open the front door (#5), place the tank into the tank Fasten them together by using bolts (#14). Make sure support assembly (#7) and through the tank fastener that all of the bolts have been tightened completely.

  • Page 6: Specific Warnings

    FIGURE 10 FIGURE 11 fire shield Note: Note: The glass cannot be The fire shield on the exposed over top of the steel burner system must be cover surface. exposed. Step 10: Step 11: Place the glass (#19) into the steel cover. Place the cover (#12) onto the table top (#6) to cover See Figure 10.

  • Page 7: Care And Maintenance

    Read the following switch usage instructions for lighting and to extinguish: Control Knob Usage Main Flame PILOT Step 1 Lighting : 1- While making sure the control knob is in the off the position, open the gas valve on the LP tank by slowly turning the handle counter-clockwise until fully open.

  • Page 8: Liquid Propane

    12.Never allow children to play near your appliance. Warranty • This product is covered by Courtyard Creations Inc.'s. one–year limited warranty. • Proof of purchase (dated register receipt) is required for warranty claims. • It remains the customer’s responsibility for freight and packing charges to and from the service center.

  • Page 9: Care Instructions

    INSTRUCTIONS FOR REMOVING THE TANK FIGURE A FIGURE B Counterclockwise Note: Step B: Close the valve tightly before removing the tank. To remove the fuel supply hose from the tank, rotate counterclockwise. See Figure B. Step A: Loosen the fuel supply hose from the igniter valve.
