Instruction Manual
Bed Frame Accessory
Model BDSHLF-1
Due to the presence of small parts during assembly, keep
out of reach of children until assembly is complete.
Model BDSHLF-1 Bed Frame Accessory
Read all instructions before assembly and use.
Keep instructions for future use.
ADULT ASSEMBLY REQUIRED
Lancaster, PA 17601
tradecraftspecialties@gmail.com
www.tradecraftspecialties.com
Revised 10/05/2017
1900 Alfa Drive
(717) 269-8934
Page
1 of 6
Advertisement
Table of Contents
Related Manuals for Tradecraft Specialties BDSHLF-1
Summary of Contents for Tradecraft Specialties BDSHLF-1
- Page 1 Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. 1900 Alfa Drive Lancaster, PA 17601 (717) 269-8934 tradecraftspecialties@gmail.com www.tradecraftspecialties.com Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 1 of 6...
-
Page 2: Care And Maintenance
● We recommend that any cleaning materials first be tested on a surface that would not be visible during the course of normal use. ● Use of a vaporizer close to this product may cause the surface to swell and the surface to peel. Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 2 of 6... - Page 3 If using power tools to aid in assembly, use caution. Power tools may over-tighten fasteners and split or damage the material. Tools required (not included): Phillips head screw driver 7/16” wrench or adjustable wrench Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 3 of 6...
-
Page 4: Parts List
Part #: Quantity: Description: Reference image only (not to scale): ¼” Lag screw ¼” Metal flat washer 1/4” Lag screw (long) Top shelf Lower shelf Support bar Side panel Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 4 of 6... - Page 5 --Fasten front of lower shelf [F] to side panel with lag screws [A] using (1) washer [B] on each lag screw. --Fasten rear of lower shelf to side panel through pre-drilled hole in support bar [G] with lag screws [D] using (1) washer [B] on each lag screw. Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 5 of 6...
- Page 6 If desired, the footboard may be fastened to the bed frame by screws through the bed slats into the footboard support bars. Bed slats should be pre-drilled to prevent splitting. Step 4: Tighten all hardware. Make sure all assembled parts are tight and secure. Page Model BDSHLF-1 Bed Frame Accessory Revised 10/05/2017 6 of 6...
