Summary of Contents for Avnera AV6200
- Page 1 Manual for Wireless Audio Module December 15, 2011 Confidential © 2008 Avnera Corporation...
-
Page 2: Revision History
Avnera Corporation Samsung Module Manual REVISION HISTORY Version Purpose \ Changes Date Initial release December 15, 2011 Samsung Module PRD page 2 of 10 AVNERA CONFIDENTIAL... -
Page 3: Hardware Architecture
Avnera Corporation Samsung Module Manual 1. Introduction This features is a highly integrated, single-chip, wireless audio solution. This integrates the following: a complete 2.4 GHz RF transceiver, the VMI™ wireless communication system PHY & MAC, advanced power management, audio DSP, I2S interfaces and a full complement of programmable digital interfaces to support a wide range of end-product user communication requirements. - Page 4 Avnera Corporation Samsung Module Manual - Time base of the RF frequency For Zero IF and RF frequency, a crystal (16MHz) is a clock reference. - Synthesizer Synthesizer inside transceiver internal voltage controlled oscillator (VCO) provides the desired LO Signal base on the phase-locked loop (PLL) with a relatively wide tuning range for this application.
-
Page 5: Pin Description
Avnera Corporation Samsung Module Manual 5. Pin description Samsung Module PRD page 5 of 10 AVNERA CONFIDENTIAL... -
Page 6: Installation
Avnera Corporation Samsung Module Manual 6. Pairing Algorithm The system has both “auto-pairing” and manual pairing capabilities. Auto-pairing can be used at the factory for testing purposes but all units are shipped from the factory with “auto-pairing” enabled. This means the user can unpack the sound bar and sub woofer and they will link immediately without user interaction. - Page 7 Avnera Corporation Samsung Module Manual 8. Brief system block diagram This radios system block diagram is ad follows figure Samsung Module PRD page 7 of 10 AVNERA CONFIDENTIAL...
-
Page 8: Important Note
Avnera Corporation Samsung Module Manual Notice FCC Statement Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. -
Page 9: Label Of The End Product
Avnera Corporation Samsung Module Manual USERS MANUAL OF THE END PRODUCT: In the user manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated. The end user has to be informed that the FCC radio-frequency exposure guidelines for an uncontrolled environment can be satisfied. - Page 10 Avnera Corporation Samsung Module Manual IMPORTANT NOTE: This module is intended for OEM integrator. The OEM integrator is still responsible for the IC compliance requirement of the end product, which integrates this module. 20cm minimum distance has to be able to be maintained between the antenna and the users for the host this module is integrated into.
