Summary of Contents for Tinkerbots Wheeler Set
- Page 1 ROADSTER Wheeler Set Wheeler MANUAL WHAT‘S YOUR NEXT ANDROID L3O CREATION?
- Page 2 Tinkerbots is designed and manufactured by Kinematics GmbH in Bernau in Germany Kinematics GmbH Zepernicker Chaussee 1 16321 Bernau Germany Patent 8,851,953 B2 © 2015 Kinematics GmbH WWW.TINKERBOTS.COM...
- Page 3 STANDARD GET STARTED ANDROID L3O ROADSTER APP CONTROL CONTROL RECORD AND PLAY LED MODES SUPPORT BACK...
- Page 4 GET STARTED TINKERBOTS Hello! I am Professor Cubie, inventor of Tinkerbots. I will give you some helpful tips while you are building your first robots. Charge your Powerbrain first and follow this manual to build the Android L3O and the roadster. Then unleash your creativity and build your own creations.
- Page 5 charging fully charged Charge your Powerbrain...
- Page 6 ANDROID L3O TINKERBOTS...
- Page 8 ANDROID L3O TINKERBOTS do NOT twist or turn...
- Page 10 STANDARD CONTROL TINKERBOTS Press Press Powerbrain on Play mode...
- Page 11 Press Press Speed up Slow down...
- Page 12 ROADSTER TINKERBOTS...
- Page 14 ROADSTER TINKERBOTS...
- Page 16 APP CONTROL TINKERBOTS Start the Tinkerbots app and select the Roadster from the Menu Press Powerbrain on...
- Page 17 Follow the instructions in the app Ready to control...
- Page 18 RECORD AND PLAYBACK TINKERBOTS Press Powerbrain on...
- Page 19 Press Motor is NOT teachable Recording Move your Pivot...
- Page 20 RECORD AND PLAYBACK TINKERBOTS Press Press Stop recording Playback motion...
- Page 21 Press Press Speed up Slow down...
- Page 22 LED MODES TINKERBOTS LED on Powerbrain LED blinking Battery full Record Start/ Stop Battery charging Powerbrain on Slow down Speed up Play back mode Recording Mini-USB Recording stopped Bluetooth connection (established) Connected to Computer...
- Page 23 LED on Motion modules LED blinking Overload, modules switches off for some seconds The module’s Firmware needs to be updated using your computer...
- Page 24 SUPPORT TINKERBOTS support.tinkerbots.com...
- Page 25 Power Brain Pivot Motor Double Cubie II Brick Adapter Axle Short Axle Long Wheel 1IM.1PB.3020 1OM.1PI.7047 1OM.1M1.7047 1CM.1X1.1023 1CM.1LM.7047 1CM.1A1.9005 1CM.1A2.9005 1CM.1WH.7047 Charging Adapter USB Cable Power Supply ZKT.1UK.9005 ZKT.1NT.9005 LA01...
