User Guide Contents Welcome………………………………………………………………………………… …………………………….2 Package Contents: ........................3 Keypad Layout and Display Indicator Lamps ................4 Preparing to Use the Product: ....................4 Charging the Device: ......................... 4 About this Device ........................5 Reset to Factory Defaults ......................5 Powering the Device On/Off ..................... -
Page 2: Welcome
Congratulations on the purchase of your new Hotspot! This User Guide is to welcome and familiarize you with the features of this device. -
Page 3: Package Contents
Please also keep this manual in a proper place. Please confirm the contents of the package. Please keep the product guaranty certificate in a safe place. 1. Package Contents: 1 - L5 Hotspot devices 1 - 5v, 1000mA Wall Charger 1 - MicroUSB Charging Cable... -
Page 4: Keypad Layout And Display Indicator Lamps
2. Keypad Layout and Display Indicator Lamps 3. Preparing to Use the Product: The Li-ion battery in the device is not fully charged. Please charge the device before using. 4. Charging the Device: a.Connect the USB end of the cable to the charger or a personal computer. -
Page 5: About This Device
5. About this Device This product acts as a Wi-Fi access point for portable devices like a notebook/netbook/tablet PC, Ipad, Android devices, Windows devices, etc. to provide Internet access. It can support up to 7 simultaneous Wi-Fi connections from portable devices*. -
Page 6: Connecting To The Device
Turn on that it one by one from right to left. Wi-Fi Sleep Mode: When the L5 is on, press and hold the power button for 2 seconds that will being Sleep Mode. The Wi-Fi will be not discovered. -
Page 7: Setup Of The Device
9. Setup of the Device A newly purchased L5 requires the customer to set up the device for use after powering on the device and connecting to it. - Launch a web browser, such as Internet Explorer, Chrome, Safari or Firefox, and type 192.168.1.1/index.asp in the address bar. -
Page 8: Managing The Device
10. Managing the Device Connect to the device in the procedure outlined in step 8. A. Login into the website will turn to Home page B. Change and View the Wi-Fi Setting... - Page 9 C. Viewing the LAN page and change it D. Updating the L5's Internal Web pages...
- Page 10 E. Change and Viewing the Advanced settings F. Successful page if Device success to Configure Any of the Settings Changes...
-
Page 11: Example Of Connecting A Tablet To The Device
Turn on the Tablet. b. Tap settings. c. Tap Wi-Fi from the setting menu. d. Find the SSID of the L5 from the AP list and tap it. e. Enter the security key (default or user modified) in the key input window. -
Page 12: Side Keys
Two white lamp: signal strength is better. One white lamp: signal is weak . No one lamp: no signal, or network obstacle. c. Battery Lamp Green: battery is enough (100-60%) Yellow: battery is low (60-30%) Red: need to be charged (30-0%) 13. -
Page 13: Product Specifications
C. Reset button - press and hold reset button for 3 seconds 14. Product Specifications Size: 75X75X13.2 mm Weight: about 80g (including battery) Communication spec: CDMA 2000 1X EVDO Rev. A \LTE B25\B26\B41 Frequency bands: 800MHz/1900MHz/2500MHZ Wi-Fi spec: IEEE802.11b/g/n Battery for continuous use: about 4 hours. - Page 14 FCC Statement 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received, including interference that may cause undesired operation. 2.
