rafiki duonet User Manual

Fire detection & alarm system control panel v1.000
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version
Fire Detection & Alarm System Control Panel V1.000
User Guide
(TO BE RETAINED BY USER)
26-0810 Issue1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the duonet and is the answer not in the manual?

Questions and answers

Summary of Contents for rafiki duonet

  • Page 1 Fire Detection & Alarm System Control Panel V1.000 User Guide (TO BE RETAINED BY USER) 26-0810 Issue1...
  • Page 2 Rafiki policy is one of continual improvement and the right to change a specification at any time without notice is reserved. Whilst every care has been taken to ensure that the contents of this document are correct at time of publication, Rafiki shall be under no liability whatsoever in respect of such contents.

  • Page 3: Table Of Contents

    Duonet User Instructions Contents Introduction Purpose of the guide Definitions Understanding the equipment System configuration What to do if!!! . User Responsibilities . Introduction Routine testing . General Operation Normal Control Panel Front Fire Alarm Controls System Controls Access Levels and Codes...

  • Page 4: Introduction

    Understanding the Equipment What is Duonet? Duonet is the name of the range of fire alarm control panels that use the associated Sita 200 plus devices which together form the fire alarm system installed in the premises, and is derived from the type of system, whereby up to four addressable device loops may be connected to each control panel, and up to 32 control panels may be networked together.

  • Page 5: System Configuration

    Duonet User Instructions System Configuration The detectors and call-points are arranged in zones to enable the location of a fire alarm to be identified. The number of zones depends on the size and the layout of the premises, and is limited to 128 zones per control panel (there may be more than one).

  • Page 6: User Responsibilities

    Duonet User Instructions User Responsibilities Introduction The responsible person is required under BS5839 to undertake certain tasks with respect to the testing and maintenance of the fire alarm system. The responsible person should also ensure that written procedures are in place for the actions to be taken by the occupants in a fire condition, and that staff required to operate the system have received adequate training.
  • Page 7 Duonet User Instructions Any defects should be recorded in the log book and reported to the responsible person. A certificate of testing should also be completed and given to the responsible person. Annual The requirements of the annual test are similar to the quarterly test except that each device on the system should be tested.

  • Page 8: General Operation

    Duonet User Instructions General Operation Normal In the normal operating mode only the green POWER LED is lit. If any other LEDs are lit and/or the buzzer is sounding there is an abnormal condition present. Control Panel Front FIRE FAULT...

  • Page 9: Fire Alarm Controls

    Duonet User Instructions Fire Alarm Controls The main Fire Alarm Controls may be enabled by turning the key switch to the controls enabled position, or by entering a valid Access code Fire alarm controls – turn key to enable controls...

  • Page 10: Fire Alarm

    Duonet User Instructions Fire Alarm When the panel enters the fire state, the alarms will sound, the fire LEDs will illuminate, the buzzer will pulse quickly and the display will show the location and type of alarm. On Hearing the Alarm The responsible person should have already prepared written procedures for the action to be taken in the event of a fire alarm.

  • Page 11: Sound Alarms (Evacuate)

    Duonet User Instructions Sound Alarms To sound the alarms at any time after they have been silenced, proceed as follows: The alarm sounders will activate. The buzzer and the Press ’SOUND ALARMS’ fire indication lights will also switch on. Silence Buzzer To silence the buzzer press the [SILENCE BUZZER] button at access level two as above .

  • Page 12: Troubleshooting

    Duonet User Instructions Troubleshooting Problem Possible Cause Remedial Action Unable to silence Panel not in Access Level 2A (User) Enter Access Level 2A (User) or Access alarms or Access Level 2B (Supervisor) Level 2B (Supervisor) - see section on operation...

  • Page 13: Advanced Operation

    Duonet User Instructions Advanced Operation Access Level 1 (Normal): Controls Enabled LED off At Access Level 1 (Normal), the main Fire Alarm Controls are disabled and the Controls Enabled LED is switched off. A valid access level code must be entered in order access any of the menus.

  • Page 14: Access Level 2B (Supervisor)

    Duonet User Instructions Access Level 2B (Supervisor) ): Controls Enabled LED flashing slowly At Access Level 2B (Supervisor), the main Fire Alarm Controls are enabled, and the following System Controls are accessible: 1. Test Display 2. View Logs 1. Current Warnings 2.
  • Page 15 Duonet User Instructions View Logs: Current Tests The Active Tests Log will display any current disablement. These are displayed in text format and may be scrolled through by pressing the UP and DOWN keys. View Logs: Event Log The Event Log stores 1000 fire and fault events which may be displayed in entirety, or displayed by category.
  • Page 16 Duonet User Instructions This function allows the disablement or enablement of programmed Network operation at that control panel. The transmission and / or the receipt of signals may be disabled as required. The control panel will indicate that disablements are present and a disablement event will be recorded to log.
  • Page 17 Duonet User Instructions Day / Night Mode: Override into Day Mode This function allows the user to override any pre-programmed Day / Night timing information and force the system into the less sensitive Day Mode. This will cause the buzzer to sound and a disablement to be written to log.

  • Page 18: Led Indication

    Duonet User Instructions LED Indication The operation of the LED indication on the front of the control panel is described below. Description Colour State Reason FIRE Flashing The control panel is in the fire state. Other indicators will show the origin...
  • Page 19 Duonet User Instructions state. Continuous A monitored output programmed to operate as a Fire or Fault Signal Transmission Output has been disabled. Amber Flashing The system Day / Night mode timing has been over ridden, and forced into the less sensitive day mode.

  • Page 20: Log Book

    Duonet User Instructions Log Book Record all fire and fault events, whether or not an engineer was called Event Log Time Zone/Device Event Action Initials...
  • Page 21 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 22 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 23 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 24 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 25 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 26 Duonet User Instructions Time Zone/Device Event Action Initials...
  • Page 27 Duonet User Instructions Time Zone/Device Event Action Initials...

  • Page 28: Installation Details

    Duonet User Instructions Installation Details This section should be completed by the commissioning engineer at handover. Name of Responsible Person: ……….….………………………………………………………..…………. Name and address of installation: …………………..……………...………………………………………. .…………………………………………………………….………………………………………………………. Ref. No. (if applicable): ……….………………………………………………………………………………… Date of Handover: ……….………………………………………………………………………………… Name and address of installer: …………...………...…………………………………………………………...
