Summary of Contents for SOS GUARDIAN S200
-
Page 1: User Manual
S200 User Manual... - Page 2 Indemnity The lawful owner or any other user of this tracker device indemnifies SOS GUARDIAN and any of its employees or distributors from any responsibility, liability, loss or damages, of any nature which results as a direct or indirect consequence of this product being used by its lawful owner or any other user.
- Page 3 Product Specifications Tracker Device Size 67x40x18mm Tracker Device Weight Network GSM / GPRS Band 850/900/1800/1900MHz GPRS Standard class 12, TCP/IP Battery Lithium Ion 1700mAh 3.7V GPS Accuracy 10-15m GPS Start-up Time: Cold – 30seconds Warm – 29seconds – 5seconds Working -20℃...
- Page 4 Main Features Built in GPS SOS alarm with GPS location Outside perimeter alarm Speed Alarm Fall Alarm Speed dials Two-way communication Hands-free communication On-demand tracking Standby time of up to 10 days Low battery alarm SIM change alarm Small & light-weight...
- Page 5 Get Device Started Step 1: Prepare SIM card Buy a pre-paid STANDARD SIM card from a cell phone service provider that has good quality gsm & gprs reception over most of the country. Activate SIM with service provider. ...
- Page 6 Slide SIM into tracker device. Once fully inside device, ensure to push it even further, until you It is suggested that you hear a “click” sound. use the included plastic key to push the SIM into position. Close the SIM card slot cover. Note If you power-on the device before inserting a SIM card, all device lights will be on without any flashing...
- Page 7 Step 4: Set SOS numbers Step 4.1: Set PRIMARY guardian numbers This cell phone number will configure the tracker device. From MASTER cell phone, send the following sms to the tracker device passwordA1,number Example: 123456A1,+27821002000 Tracker device will reply with an sms that includes the MASTER number that has been set.
-
Page 8: Step 5: Register Your Device
Tracker device will reply with an sms to confirm the setup for each number. Continue the above two steps for the other 2 numbers that are associated with the 2 speed dial numbers. Call button 1: 123456A4,number Call button 2: 123456A5,number Suggestion Create a contact on all guardian cell phones, for the tracker device’s inserted SIM, and name the contact accordingly (e.g. - Page 9 List of tracker device SMS commands Note All commands must be uppercase. Sending sms command and subsequent sms reply by tracker device may take a few minutes due to external factors. SMS command Description Total of 5 guardians: 123456A1,+27xxyyyzzzz 123456A2,+27xxyyyzzzz 123456A3,+27xxyyyzzzz Set guardian numbers Guardians linked to speed dials:...
- Page 10 Incoming Calls 2-way voice with 123456S1 ringtone (default) 2-way voice with NO 123456U0 ringing – auto pickup 1-way voice with NO ringtone – auto 123456U1 pickup (listen-in mode) SOS Calling 1-way voice with speaker set to MUTE. 123456U2 (listen-in mode) 2-way voice 123456U3 SOS Type...
- Page 11 List of tracker device features Action Description Press and hold Device will send SMS to all SOS SOS button for numbers that have been set up. If 3 seconds. your GPS location was acquired, the SMS will include your GPS location via a Google Maps link.
- Page 12 Support For any support queries, feel free to get in touch: http://www.sosguardian.co.za/technical- support/ Email support@sosguardian.co.za Phone +27 (0) 72 363 2228 Use of this product is subject to our terms & conditions. Please visit www.sosguardian .co.za...
