Manual Ver. 1.2
PCI Adaptors
Reference and Installation Guide
Model : ASI-100 / ASO-102 / ASA-105 / LVI-110
/ LVO-112 / LVD-115
The Company Based on Technology and Reliability
LUMANTEK
www.lumantek.com
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASI-100 and is the answer not in the manual?

Questions and answers

Related Manuals for Lumantek ASI-100

Summary of Contents for Lumantek ASI-100

  • Page 1 Manual Ver. 1.2 PCI Adaptors Reference and Installation Guide Model : ASI-100 / ASO-102 / ASA-105 / LVI-110 / LVO-112 / LVD-115 The Company Based on Technology and Reliability LUMANTEK www.lumantek.com...
  • Page 2 “This manual is Installation Guide for LUMANTEK PCI Adaptor Users” 1 All specifications and features are subject to change without notice. 2 For the Device Driver, you may download on the web. 3 Others: Written on: Jan, 2004 Revised on: Nov 2 2004 (1’st) Revised on: Feb 2 2005 (2’nd)
  • Page 3 Index PCI Adaptor Installation (Page 04) [Hardware Installation] (Page 04) [Driver Installation] (Page 05) [Verification of Device Driver] (Page 10) PCI ADAPTER Main Features (Page 11) 1. ASI – 100 (ASI Input PCI ADAPTER) (Page 11) 2. ASO – 102 (ASI Output PCI ADAPTER) (Page 12) 3.

  • Page 4: Pci Adaptor Installation

    PCI Adaptor Installation Mount PCI Adaptor (ASI-100 / ASO-102 / ASA-105 / LVI-110 / LVO-112 / LVD-115) on computer and install Device Driver provided with PCI Adaptor to operate. Just insert CD (provided with PCI Adaptor) into CD-ROM driver and then you may install device driver easily to follow the request of computer dialogue box.

  • Page 5: Driver Installation]

    [Driver Installation] 1. Computer recognizes new device driver as Window starts after PCI Adaptor plug in. 2. Hardware Wizard will operate after the Adaptor is recognized on computer. To install, push “Next” menu box.
  • Page 6 3. To install the driver provided with the Adaptor, select ‘Search for a suitable driver for my device (recommended)’ menu, then push ‘Next’ button. 4. Device Driver is in CD-ROM provided with Adaptor, so, select ‘CD-ROM drivers’ and push ‘Next’ button.
  • Page 7 . Select the driver location in CD-ROM using ‘Browse…’ button. (Egg: if the CD-ROM driver is assigned on ‘G’ Driver, then you may make “G:₩asi directory” and push ‘OK’ button. 6. You already found out the driver on above paragraph #5 action, push ‘Next’ button on ‘Driver Files Search Results’...
  • Page 8 7. Device Driver will be installed as you push ‘Yes’ button on ’Digital Signature Not Found’ window. 8. This means ‘IMK-DVB Input/Output Adapter Device’ was installed. Push ‘Finish’ button to complete installation.

  • Page 10: Verification Of Device Driver]

    [Verification of Device Driver] If Device Driver is installed successfully doing above action, you can see on ‘Device Manager window’ that ‘IMK-DVB Input/Output Adapter Device’ is installed. (You may select ‘Device manager’ through ‘Start’ → ’Settings’ → ’Control Panel’ → ’System’ → ’Hardware’ → ’Device Manager.’) If Device Manager is not assigned or collision and protection, etc.

  • Page 11: Pci Adapter Main Features

    PCI ADAPTER Main Features 1. ASI – 100 (ASI Input PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Input bit rate : ~ 216Mbps 3) Hardware based Input rate monitoring 4) Packet Size Conversion (188 <-> 204) 5) Time Stamp Insertion.

  • Page 12: Aso – 102 (Asi Output Pci Adapter)

    2. ASO – 102 (ASI Output PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Output bit rate : ~ 108Mbps 3) Packet Size Conversion (188 <-> 204) 4) Hardware based rate conversion (Only Advanced Version) : NULL packet Insertion and PCR restampping.

  • Page 13: Asa – 105 (Asi In/Out Pci Adapter)

    3. ASA – 105 (ASI In/Out PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Input bit rate : ~ 216Mbps 3) Output bit rate : ~ 108Mbps 4) Hardware based Input rate monitoring 5) Time Stamp Insertion.

  • Page 14: Lvi – 110 (Spi Input Pci Adapter)

    4. LVI – 110 (SPI Input PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Input bit rate : ~ 216Mbps 3) Hardware based Input rate monitoring 4) Time Stamp Insertion. 5) PID Filtering (Only Advanced Version). 6) PID Remapping (Only Advanced Version).

  • Page 15: Lvo – 112 (Spi Output Pci Adapter)

    5. LVO – 112 (SPI Output PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Output bit rate : ~ 108Mbps 3) Hardware based rate conversion (Only Advanced Version) : NULL packet Insertion and PCR restampping, 4) PID Filtering (Only Advanced Version) 5) PID Remapping (Only Advanced Version) 6) PID Checking (Only Advanced Version)

  • Page 16: Lvd – 115 (Spi Combo Pci Adapter)

    6. LVD – 115 (SPI Combo PCI ADAPTER) • Features 1) Compliant to DVB document A010 rev 1 and EN50083 2) Output bit rate : ~ 108Mbps 3) Packet Size Conversion (188 <-> 204). 4) Hardware based rate conversion (Only Advanced Version) : NULL packet Insertion and PCR restampping 5) PID Filtering (Only Advanced Version) 6) PID Remapping (Only Advanced Version)

This manual is also suitable for:

Aso-102Asa-105Lvi-110Lvo-112Lvd-115
