2024F Neon Bore Hole Telemetry Module
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC
Rules in the U.S.A. These limits are designed to provide reasonable protection against harmful interference when the equipment
is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be required to
correct the interference at his own expense.
This equipment has been tested for compliance with European regulations as follows:
Application of Council Directive:
2004/108/EC
Standards to which Conformity is declared:
EN-61000-6-1:2001
EN-61000-4-2:1995
EN-61000-4-3:1995
EN-61000-4-4:1995
EN-61000-4-6:1996
ENV-50204:1995
Any changes or modifications to this equipment not expressly approved by the manufacturer Unidata Pty Ltd could void the
user's authority to operate this equipment.
Revision History
File name/Revision
Unidata Manual - Neon 2000 Family Remote Terminals and
Modules issue 4.0
Unidata Manual - 2024F Neon Bore Hole Telemetry Module -
28 05 2015.docx
Unidata Manual - 2024F Neon Bore Hole Telemetry Module -
09 06 2015.docx
Unidata Manual - 2024F Neon Bore Hole Telemetry Module -
22 07 2015.docx
Unidata Manual - 2024F Neon Bore Hole Telemetry Module -
20 04 2016.docx
Manual
Neon 2000 Family
Date
25/09/2013
28 05 2015
09 06 2015
22 07 2015
20 04 2016
Author & Change Details
MP – Reformat for web site
PC – Major Update
PC – Reviewed
DM – Add info on reed switch
alignment and hex tool
DM – Update
Assembly/Disassembly
procedure, added jumper
settings
Checked/
approved
CB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Neon 2000 Family and is the answer not in the manual?

Questions and answers

Summary of Contents for UniData Communication Systems Neon 2000 Family

  • Page 1 File name/Revision Date Author & Change Details Checked/ approved Unidata Manual - Neon 2000 Family Remote Terminals and 25/09/2013 MP – Reformat for web site Modules issue 4.0 PC – Major Update Unidata Manual - 2024F Neon Bore Hole Telemetry Module - 28 05 2015 28 05 2015.docx...
  • Page 2 Copyright © Unidata Pty Ltd 2000-2016. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any spoken or computer language, in any form or by any means. Electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without prior written permission of Unidata Pty Ltd 40 Ladner St, O’Connor Western Australia 6163.

  • Page 3: Table Of Contents

    Manual – 2024F Neon Bore Hole Telemetry Module TABLE OF CONTENTS 1.0  Summary of Neon Bole Hole Telemetry Modules ............3      2024 Neon Bore Hole Metering Module – 3G ..............3 2.0  NBHTM LED indicatorS ...................... 4  3.0  Terrestrial NBHTM Setup and Test ..................
  • Page 4 Manual – 2024F Neon Bore Hole Telemetry Module References This manual should be read in conjunction with the associated StarlogV4 User Manual which describes the setting up of logging schemes for NBHTM terminals as well as all other Unidata Data loggers. This manual should also be read in conjunction with the Neon Server Documentation which is available in PDF form from the Unidata web site and is also available as help screens within the Neon Server system.

  • Page 5: Summary Of Neon Bole Hole Telemetry Modules

    Manual – 2024F Neon Bore Hole Telemetry Module SUMMARY OF NEON BOLE HOLE TELEMETRY MODULES The 2024F NBHTM (Neon Bore Hole Telemetry Module) is a small self-contained unit in a tubular housing which connects to downhole sensors in bore holes, collects readings from those sensors, and transmits the collected data to a central server via a cellular telephone network.

  • Page 6: Nbhtm Led Indicators

    Manual – 2024F Neon Bore Hole Telemetry Module NBHTM LED INDICATORS The simplest indicator is the Red LED which is located on the top endcap The Green LED indicator is used to show if the NBHTM has a scheme program currently running.

  • Page 7: Terrestrial Nbhtm Setup And Test

    Manual – 2024F Neon Bore Hole Telemetry Module TERRESTRIAL NBHTM SETUP AND TEST The Neon Bore Hole Metering Module uses a SIM card which needs to be installed. It should then connect to the Cellular network within a few seconds of powering on. Note the SIM card must have the security PIN number switched off or disabled.

  • Page 8: Nbhtm Installation

    Manual – 2024F Neon Bore Hole Telemetry Module NBHTM INSTALLATION The following section describes the NBHTM installation procedure. SIM Card Recommendations It is highly recommended that the SIM is installed in the NBHTM before going to site. Refer to sections 7.5 for detailed SIM setup installation. It is also recommended that the contents of the NBHTM installation kit are checked, and that the NBHTM is tested and confirmed as working before going to site.

  • Page 9: Sql Instrument Connector Pinout

    Manual – 2024F Neon Bore Hole Telemetry Module Position the enclosure to ensure cables from NBHTM to field devices are as short as practical. If the NBHTM is to be used for real-time communication or for a higher than usual download schedule (refer to Table 1), an external power supply may be required to avoid frequent battery replacement.

  • Page 10: Instrument Connection

    Manual – 2024F Neon Bore Hole Telemetry Module Instrument Connection SQL 7-Pin Female Connector Pinouts (viewed from pins) Unidata Manual - 2024F Neon Bore Hole Telemetry Module - 20 04 2016.docx Page 8...
  • Page 11 Manual – 2024F Neon Bore Hole Telemetry Module 5.5.1 SDI-12 Connections Pin Number  Colour  Function  1  Black  Ground (Power and Signal)  2  Brown  SDI‐12  6  Blue  External Power (Optional)  5.5.2 Modbus Connections Pin Number  Colour  Function  1  Black  Ground (Power and Signal)  3  Red  Modbus B+  7  Orange  Modbus A‐  6  Blue  External Power (Optional) ...

  • Page 12: Nbhtm Commissioning

    Manual – 2024F Neon Bore Hole Telemetry Module NBHTM COMMISSIONING Once the NBHTM has been installed and all connections made, field commissioning can be conducted. Ensure that a SIM card has been installed (see next section). Commissioning tests may be performed as follows. NBHTM Powered On Confirm that the status LED, visible through the transparent window on the front of the unit, is flashing.

  • Page 13: Nbhtm Signal Strength Verification

    Manual – 2024F Neon Bore Hole Telemetry Module NBHTM Signal Strength Verification  Connect a laptop computer to the NBHTM.  Launch the STARLOGV4 application.  Press the ‘Select’ icon and select the scheme corresponding to the NBHTM.  Click on the ‘Configure/Initialise’ button to open the “NRT/NMM Configuration Tool” dialog ...

  • Page 14: Reset Switch

    Manual – 2024F Neon Bore Hole Telemetry Module  Press the ‘Initialise’ button  The NBHTM will attempt to communicate with the Neon server and initialise itself. Once communications have been established, the NBHTM will download any required scheme and configuration files and complete the initialisation process. The NBHTM should respond with a PASS message after 1 to 3 minutes.

  • Page 15: Jumper Settings

    Manual – 2024F Neon Bore Hole Telemetry Module Jumper Settings There are two jumper settings available. These should be installed during the commission process, if required. The jumpers are located on the circuit board, inside the instrument enclosure. Refer to section 7.3 and 7.6 to disassemble and reassemble the instrument. JP1 sets the modbus termination resistor.

  • Page 16: Battery Testing

    Manual – 2024F Neon Bore Hole Telemetry Module BATTERY TESTING Battery Check The presence of a battery can be verified without opening the NBHTM. Look for the flashing LED through the window on the front of the NBHTM unit. If the NBHTM is in an idle state, the LED will flash faintly once every second. If the LED is not flashing, you will need to open the NBHTM and verify the presence of a battery.

  • Page 17: Instrument Disassembly

    Manual – 2024F Neon Bore Hole Telemetry Module Instrument Disassembly NOTE: There are static sensitive parts inside the metal housing. Discharge yourself to a grounded metal object before opening the housing 1) Disconnect depth instrument from SQL connector (if fitted) 2) Remove the locating screw in the top endcap 3) Remove the two screws from the stainless steel bottom end plate Unidata Manual - 2024F Neon Bore Hole Telemetry Module - 20 04 2016.docx...
  • Page 18 Manual – 2024F Neon Bore Hole Telemetry Module 4) Remove the stainless steel bottom end plate and neoprene sealing washer, taking care not to damage it 5) Gently push the SQL connector into the tube. The whole instrument assembly will slide out the top of the stainless steel tube.

  • Page 19: Battery Connection

    Manual – 2024F Neon Bore Hole Telemetry Module Battery Connection For safety reasons the NBHTM is shipped without the internal lithium battery pack connected. It must be connected during commissioning of the instrument. The battery can also be replaced when depleted. Perform the following steps to connect or change the battery: 1) Locate the battery connector on the circuit board.

  • Page 20: Sim Card Installation

    Manual – 2024F Neon Bore Hole Telemetry Module 3) Remove the depleted battery then insert the new battery. The battery is held in place with double sided tape. 4) Plug the fresh battery into the socket. SIM Card Installation 1) Locate the SIM Card holder on the circuit board. 2) Slide the cover back and open the holder.

  • Page 21: Instrument Reassembly

    Manual – 2024F Neon Bore Hole Telemetry Module Instrument Reassembly 1) Gently slide the instrument assembly into the stainless steel tube, instrument connection end first 2) Align hole in endcap with the hole in the stainless steel strap and tighten the screw. Caution: only do up finger tight, DO NOT use an electric screwdriver.
  • Page 22 Manual – 2024F Neon Bore Hole Telemetry Module 3) Insert the neoprene washer around the instrument connector, taking care to position the screw holes correctly. Make sure the washer is not kinked or twisted. 4) Attach the stainless steel bottom plate. Align the notch in the plate with the stainless steel strap.

  • Page 23: Nbhtm - 3G External Antenna

    Manual – 2024F Neon Bore Hole Telemetry Module NBHTM - 3G EXTERNAL ANTENNA This section describes fitting of an external antenna to the NBHTM. Unscrew the ¼ wave helical stub antenna from the NBHTM unit. Find a suitable location for the external antenna and secure it firmly in place. Note that some antennas require a ground plane mount (refer antenna information).

This manual is also suitable for:
