Summary of Contents for Siter GS901
- Page 1 Wireless pepper spray system GS901 Installation Guide Please read this guide carefully and keep it in a safe place...
-
Page 2: Product Description
PRODUCT DESCRIPTION 1、Product working priciple The system use the PIR as the first sensor,use the active infra-red transmission module.As the second sensor to control the surveillance place.the maximum inductive distance of the first sensor is 10 meters, the f a r t h e st i n d u cti ve di sta n ce o f t h e se co n d se n so r i s 1 me t e r s . 2、... -
Page 3: Package Contents
PACKAGE CONTENTS 1 Wireless pepper spray system 2 remote controller 1 instruction manual 1 AC adaptor 4 3.5×25 screws 6 4×15 screws 4 swelled screws Self-attachments: door magnet ATTENTION 1、Although the crust is made from ABS plastic,please take care while in Carrying and installing,don’t let the unit fall down or kick down. - Page 4 PRODUCT INTRODUCTION CHART (Figure 1) (Figure 2)
- Page 5 INSTALLTION Connections Insert the positive wire into the battery positive head Attention:before connected to the battery,please put the 2 remote controllers in a safety place to avoid to open the system while in installing. (Figure 3) Optional function before installation ( Figure 4)
- Page 6 1、Chosing the operation mode of the system 1.1 Mode description The system have 2 operation mode,it is master mode and slaver mode.in master mode under surveillance,if the people enter into the first sensor surveillance place,it will automatically alarm,if the people enter into the second sensor surveillance place,it will also automatically spray the pepper.
- Page 7 Attention:After all the remote controllers finish to study,please put the remote controllers in a safety place to avoid to open the system while in installing. Tips:The system can study with other wireless equipments like door magnet,etc.once the door magnet send the wireless signal to the system,the system will alarm.
-
Page 8: Operation Test
OPERATION TEST The operation on the system are the same no matter whether in master mode or slaver mode.please take care when operation. 1、 Open the system and pepper spray test Press “ON”button remote controller,it will beep times,meantime,the working light will flash red every 4 seconds.it indicate the system is open.the system need 30 seconds to warm-up after the system is open,within this period,if the people stand in front of the system,the system will not alarm and spray the pepper,After 30 seconds,the working light went... - Page 9 SYSTEM OPERATION STATUS DESCRIPTION 1、Close status The working light will light on. 2、Warm-up status The working light flash every 4 seconds,in this status,the first sensor is just opened,it need the time to warm-up,but at this time,the sytem can receive the wireless alarm signal from the other slaver system,it will alarm but will not spray pepper.the whole process of warm-up need about 30 seconds,it will automatically turn into surveillance mode.
- Page 10 IF LOST THE REMOTE CONTROLLERS，HOW CAN WE DO？ If you lost the remote controller,you can use the memory to erase its control right.But it will erase all the others remote controllers’s control right.therefore,after erased,All the remote controllers need study again.we suggest if lost one remote controller,please erase the memory of all the remote controllers,of course,if you think it is complicated,you just don’t do this,the other remote controllers also can use.Please see below how to erase...
- Page 11 TECHNIQUAL SPECIFICATIONS Model GS401 The inductive distance of the first ≤10m sensor The inductive distance of the second ≤1m sensor remote control working distance ≤50m alert power ≤100 dB Detection way Digital infra-red pluse and PIR Operation temperature -30℃~60℃ The spray distance of the pepper ≥3m canister The spray speed of the pepper...
